[4] PERFORMANCE CURVES
NOTE: 1) Use this data only as a guide to check the running condition.
2) The running conditions of this data is as follows.
Remote control setting .................... High cool, 18ºC
Drain pump ........................................ OFF
Exhaust hose .................................... Shortest
3) This data will be changed by operation conditions such as: a drain pump operation or an exhaust hose configuration.
Especially, pomp operation will decrease the line current and power input value significantly.
4.4
4.2
4.0
3.8
3.6
3.4
950
900
850
800
750
25 30 35
25 30 35
25 30 35
Room t emperat ure
Line current (A)
Room t emperat ure
Power input(W)
10
20
30
Room temper ature
Outlet air
temperature
40%RH
70%RH
40%RH
70%RH
70%RH
40%RH

Sharp CV-P09FR Specifications

General

Cooling capacity (max)	- BTU/h
Dehumidifying capacity	1.167 l/h
Cooling capacity in watts (max)	2120 W

Weight and Dimensions

Weight	36000 g
