CHAPTER 2. OPERATION INSTRUCTION
[1] PART NAMES
1. Front view
2. Rear view
Air Outlet
Vertical louvers
Horizontal louvers
PLASMACLUSTER Lamp (blue)
Remote control signal receiver
window
AUX. Button
OPERATION Lamp (red
)
TIMER Lamp (orange
)
TURBO COOL Lamp (green )
Air inlet
Exhaust air outlet
Exhaust adapter
Exhaust hose
Remote control hook
Air filters
Drainage nozzle and stopcock
Power supply cord hooks
Drainpipe nozzle and stopcock
Power s upply cord
Power plug
Casters (4)

Sharp CV-P09FR Specifications

General

Cooling capacity (max)	- BTU/h
Dehumidifying capacity	1.167 l/h
Cooling capacity in watts (max)	2120 W

Weight and Dimensions

Weight	36000 g
