Sharp CV-P09FR Service Manual

CVP09FR
3
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
RANK
DESCRIPTION
[1] OUTSIDE PARTS
CABINET AND UNIT PARTS
1-1 CCAB-A395JBKZ BH Cabinet ass'y
1-2 GCAB-A292JBFB BQ Cabinet
1-3 LHLD-A735JBFB AD Cord holder
1-4 TLAB-C748JBRZ Caution label
1-5 TLAB-C804JBRZ Caution label
1-6 TLAB-C805JBRZ Label
1-7 TLAB-C806JBRZ Label
1-30 HDEC-B196JBEZ AQ Display panel
1-33 TLAB-C747JBEZ Energy label
1-35 PSPA-A180JBEZ Louver spacer
1-36 CPNL-A530JBKZ BD Front panel ass'y
1-37 HBDG-A002KKEA AE Al badge
1-38 HDEC-B192JBFA AF Cluster display
1-39 HPNL-A726JBFB AW Center panel
1-40 HPNL-A727JBFA AZ Display panel
1-41 HPNL-A746JBRB Front panel
1-42 PGID-A124JBFB AF Filter guide A
1-43 PGID-A125JBFB AF Filter guide B
1-55 CKITTA071AKKZ BD Plasmacluster unit
1-56 DLOV-A014JBKZ AZ H louver ass'y
1-57 MLOV-A427JBTA AU Horizontal louver C
1-58 MLOV-A428JBTA AU Horizontal louver B
1-59 GWAKPA173JBFA BC Top duct
1-60 LANG-A623JBPZ AG Top angle
1-61 LHLD-A737JBFA AZ Cluster holder
1-62 LSTP-A027JBFA AM Stopper
1-63 MLOV-A425JBTA AU Horizontal louver A
1-64 PCOV-B108JBFA AZ Cluster cover
1-65 PFPFPC769JBFZ AF Insulator A
1-66 PFPFPC770JBFZ AF Insulator B
1-67 PFPFPC771JBEZ AF Insulator C
1-68 PFPFPC772JBEZ AF Insulator D
1-69 PFPFPC773JBEZ AF Insulator E
1-70 PFPFPC774JBEZ AF Insulator F
1-71 PFPFPC775JBEZ AF Insulator G
1-72 PFPFPC830JBEZ AC Cl.cover insulator B
1-73 PFPFPC831JBEZ AC Cl.cover insulator D
1-74 PFPFPC832JBEZ AC Insulator H
1-75 PFPFPC862JBEZ AC Insulator I
1-76 PSEL-C876JBEZ AC Cluster insulator
1-77 PSEL-C877JBEZ AC Cl.cover insulator A
1-78 PSEL-C879JBEZ AC Cl.cover insulator C
1-79 PSPRCA010JBE0 AD Spring
1-80 QW-VZE971JBZZ AL Lead wire
1-81 RMOT-A061JBE0 AS Louver motor
1-83 DFILMA001JBEB AM Ply filter A
1-84 DFILMA002JBEB AM Ply filter B
1-115 HPNL-A728JBFB AW Side panel L
1-116 HPNL-A729JBFB AW Side panel R
1-134 TSPC-F091JBRZ Name badge
1-137 TLAB-C823JBRZ Caution label
SCREWS AND NUTS
6-16 XTPS730P10000 AC Tapping screw
6-19 XTTS740P12000 AC Tapping screw
6-22 XUPS740P08000 AC Tapping screw
6-24 XTTS740P10000 AC Tapping screw
6-25 XCPS730P12XS0 Tapping screw

Sharp CV-P09FR Specifications

General

Cooling capacity (max)	- BTU/h
Dehumidifying capacity	1.167 l/h
Cooling capacity in watts (max)	2120 W

Weight and Dimensions

Weight	36000 g
