1-18-7
E9656PIN
16 NC Not Used
17 PILOT DET PILOT DET
18 PLL Stereo PLL Filter
19 VCC Power Supply
20 NC Not Used
21 INPUT SIF/BaseBand Input
22 SIFREF SIFREF
23 STEREO REF STEREO REF
24 SDA/SAPID SDA/SAPID
25 GND GND
26 PE PE
27 SCL/STID SCL/STID
28 AGC DET AGC DET
29 Rout Rout
30 Lout Lout
31 NC Not Used
32 L-R REF L-R REF
Pin
No.
Signal
Name
Function
IC1404 (VIDEO DRIVER)
Pin
No.
Signal
Name
Function
1
C IN Chrominance Signal Input
2 BIAS BIAS
3 Y IN
Luminance Signal(Interlace)
Input
4 VCC VCC
5 Y OUT Luminance Signal Output
6 CVBS OUT
Composite Video Signal
Output
7 C OUT Chrominance Signal Output
8 GND GND
IC1405 (VIDEO DRIVER)
Pin
No.
Signal
Name
Function
1
NU Not Used
2 BIAS BIAS
3 Y IN
Luminance Signal(Interlace/
Progressive) Input
4 VCC VCC
5 MUTE Mute Signal Input
6 Cb IN
Component Video Signal
Input
7 GND GND
8 Cr IN
Component Video Signal
Input
9 GND GND
10 Cr OUT
Component Video Signal
Output
11 Cb OUT
Component Video Signal
Output
12 VCC VCC
13 Y OUT
Luminance Signal (Interlace/
Progressive) Output
14 NU Not Used
15 NU Not Used
16 GND GND
IC1406 (OUTPUT SELECT)
Pin
No.
Signal
Name
Function
1
0Y Signal Input
2 2Y Signal Input
3 Y-COM Signal Output
4 3Y Signal Input
5 1Y Signal Input
6 INH Not Used
7 VEE Not Used
8 VSS Not Used
9 B Switching Control
10 A Switching Control
11 3X Signal Input
12 0X Signal Input
13 X-COM Signal Output
14 1X Signal Input
15 2X Signal Input
16 VCC Power Supply
