Sharp DV-RW550U - Mechanical Parts List

1-21-1
E9656CA
PRODUCT SAFETY NOTE: Products marked with a # have special characteristics important to safety. Before
replacing any of these components, read carefully the product safety notice in this service manual. Don't degrade
the safety of the product through improper servicing.
MECHANICAL PARTS LIST
Ref. No. Description Part No.
A1X FRONT ASSY E9656UD 9HS1VM220893
A2 TOP COVER E9400UD 9HS0VM101356C
A3 MAIN CHASSIS E9400UD 9HS0VM101353E
A4 REAR PANEL H9620UD 9HS1VM220395
A10# RATING LABEL E9620UD ----------
A14 BARCODE LABEL E9620UD ----------
A34 FOOT H5100UD 9HS0VM406940
1B1 DECK ASSEMBLY CZD014/VM2460 9HSN246SFL
2B1 DECK PEDESTAL E9600UD 9HS1VM120055
2B2 FRONT BRACKET E9400UD 9HS0VM204534A
2B3 FRONT BRACKET R E9400UD 9HS0VM416269A
2B4 EARTH PLATE E9600UD 9HS1VM421163
2B9 MECHA EARTH PLATE E9600UD 9HS1VM421129
2B10 HOLDER PCB E9400UD 9HS0VM101354C
2B11 BRACKET R E9600UD 9HS1VM421062
2B13 JACK BRACKET E9400UD 9HS0VM416273
2B14 CUSHION RUBBER E9400UD 9HS0VM416664
2B19 RADIATION SHEET E9610UD 9HS1VM320666
2B20# CAUTION LABEL ----------
2B31 TAPE HIMELON H9206JD 9HS0VM413956
2B59 JACK EARTH PLATE E9600UD 9HS1VM320623
2B61 EARTH PLATE (TOP) E9610UD 9HS1VM320888
2B65 DUST SHEET(CHASSIS) E9656UD 9HS1VM422475
2B66 DUST SHEET (TOP) E9656UD 9HS1VM422279
2B67 FIBER TOP CASE HC460ED 9HS0VM412906
2L011 SCREW C-TIGHT M3X5 BIND HEAD + 9HSGBCC3050
2L013 SCREW S-TIGHT M3X6 BIND HEAD+ 9HSGBMS3060
2L014 SCREW S-TIGHT M3X6 BIND HEAD+ 9HSGBMS3060
2L015 SCREW S-TIGHT M3X5 BIND HEAD+ 9HSGBMS3050
2L017 SCREW S-TIGHT M3X8 BIND HEAD+ 9HSGBMS3080
2L021 SCREW P-TIGHT M3X8 BIND HEAD+ 9HSGBCP3080
2L022 SCREW S-TIGHT M3X6 BIND HEAD+ 9HSGBMS3060
2L030 P-TIGHT SCREW 3X8 BIND + 9HSGBMP3080
2L033 SCREW S-TIGHT M3X6 BIND HEAD+ 9HSGBMS3060
2L043 P-TIGHT SCREW 3X8 BIND + 9HSGBMP3080
2L044 P-TIGHT SCREW 3X8 BIND + 9HSGBMP3080
2L045 P-TIGHT SCREW 3X8 BIND + 9HSGBMP3080
2L052 SCREW P-TIGHT M3X6 BIND HEAD+ 9HSGBMP3060
2L054 SCREW P-TIGHT M3X6 BIND HEAD+ 9HSGBMP3060
2L060 P-TIGHT SCREW 3X8 BIND + 9HSGBMP3080
2L061 SCREW P-TIGHT M3X6 BIND HEAD+ 9HSGBMP3060
2L062 SCREW B-TIGHT M3X8 BIND HEAD + 9HSGBKB3080
2L071 SCREW P-TIGHT M3X10 WASHER HEAD+ 9HSGCMP3100
2L081 SCREW S-TIGHT M3X5 BIND HEAD + 9HSGBKS3050
2L082 SCREW S-TIGHT M3X5 BIND HEAD + 9HSGBKS3050
2L100 P-TIGHT SCREW M3X34 E9400UD 9HS1VM420034A
2L110 SCREW S-TIGHT M3X10 BIND HEAD+ 9HSGBMS3100
2L111 SCREW P-TIGHT 3X12 BIND HEAD+ 9HSGBMP3120
S1 GIFT BOX CARTON E9656UD 9HS1VM321212
S2 STYROFOAM E9430JD 9HS0VM101386
S3 SET BAG E7708UA 9HS0DM400731A
S8 REMOCON PAD H9645JD 9HS1VM420375
S9 TOP PAD E9650JD 9HS1VM321105
S14 PROTECTION SHEET E9656UD 9HS1VM422459
S15 YAMATO TAPE NO.550 W12MM 9HS0RZZ00113
X1 REMOTE CONTROL UNIT NB130UD 9HSNB130UD
X2 DRY BATTERY R6P/2S 9HSB0M451T0001
X3 RF CABLE WPZ0901TM003 9HSPZ0901TM003
X4 ACCESSORY BAG E5700UD 9HS0VM415576
