1-12-1
E9656FIS
< VCR Section >
Note:
If a mechanical malfunction occurs, the power is turned off. When the power comes on again after that by pressing
[POWER] button, an error message is displayed on the TV screen for 5 seconds.
FUNCTION INDICATOR SYMBOLS
LED MODE INDICATOR ACTIVE
When the drum is not working properly
When cassette loading mechanism is not
functioning correctly
When tape loading mechanism is not
functioning correctly
When reel and capstan mechanism is not
functioning correctly
" P" is displayed on a TV screen. (Refer to Fig. 5.)
" D" is displayed on a TV screen. (Refer to Fig. 4.)
" C" is displayed on a TV screen. (Refer to Fig. 3.)
" T" is displayed on a TV screen. (Refer to Fig. 2.)
" R" is displayed on a TV screen. (Refer to Fig. 1.)
P-ON;5V Power safety detection
TV screen
When reel and capstan mechanism is not functioning
correctly
A
R
SP 0:00:00
Fig. 1
When tape loading mechanism is not functioning
correctly
A
T
SP 0:00:00
Fig. 2
When cassette loading mechanism is not functioning
correctly
A
C
SP 0:00:00
Fig. 3
When the drum is not working properly
A
D
SP 0:00:00
Fig. 4
P-ON+5V Power safety detection
A
P
SP 0:00:00
Fig. 5
