1-22-11
E9656EL
JACK CBA ----------
Consists of the following
CONNECTOR
CN1605 FE CONNECTOR TOP 8P 08FE-BT-VK-N 9HSCFEJ08JG001
RESISTORS
R804 CHIP RES.(1608) 1/10W J 75 Ω 9HSRXAJR5Z0750
R812 CHIP RES.(1608) 1/10W J 75 Ω 9HSRXAJR5Z0750
R815 CHIP RES.(1608) 1/10W J 75 Ω 9HSRXAJR5Z0750
MISCELLANEOUS
JK800 RCA JACK(RED) MTJ-032-11A-31 FE01 9HSYRL010LY024
JK801 RCA JACK(WHITE) MTJ-032-11B-41 FE01 9HSXRL010LY102
JK803 RCA JACK(YELLOW) MTJ-032-11B-40 FE01 9HSXRL010LY101
JK806 S TYPE JACK MDC-050V-2.4 9HSXEL040LY001
W03 FFC CABLE 8P FFC/P1.25/105 9HSX1E9600-002
JACK CBA
Ref. No. Description Part No.
FUNCTION CBA ---------
Consists of the following
SWITCHES
SW615 TACT SWITCH KSM0614B 9HSST0101HH013
SW617 TACT SWITCH KSM0614B 9HSST0101HH013
MISCELLANEOUS
W001 PARALLEL WIRE 4P AWG26#2651/P2.0/100 9HSX1E9600-003
W002 PARALLEL WIRE 3P AWG26#2651/P2.0/80 9HSX1E9400-003
FUNCTION CBA
Ref. No. Description Part No.
POWER SW CBA ---------
Consists of the following
DIODE
D571 LED(RED) 204HD/E 9HSPQZ00204HDE
SWITCH
SW601 TACT SWITCH KSM0614B 9HSST0101HH013
POWER SW CBA
Ref. No. Description Part No.
SENSOR CBA 9HS1VSA10080
Consists of the following
TRANSISTORS
Q503 PHOTO TRANSISTOR PT204-6B-12 9HSPWZT2046B12
Q504 PHOTO TRANSISTOR PT204-6B-12 9HSPWZT2046B12
SENSOR CBA
Ref. No. Description Part No.
Ref. No. Description Part No.
POWER SUPPLY CBA + JUNCTION CBA
POWER SUPPLY CBA + JUNCTION CBA 9HS1VSA11308
Consists of the following
POWER SUPPLY CBA ----------
JUNCTION CBA ----------
POWER SUPPLY CBA
Ref. No. Description Part No.
POWER SUPPLY CBA ----------
Consists of the following
CAPACITORS
C012 ELECTROLYTIC CAP. 470µF/16V M 9HSE1CMASDL471
C013 ELECTROLYTIC CAP. 10µF/50V M H7 9HSE1JMASSL100
C014 ELECTROLYTIC CAP. 470µF/16V M 9HSE1CMASDL471
C015 ELECTROLYTIC CAP. 1000µF/16V M 9HSE1CMASDL102
C017 ELECTROLYTIC CAP. 4700µF/6.3V SL 9HSE0KMZADL472
To Next Page
