Sharp DV-RW550U - Page 81

1-14-24
E9656PD
DVD MAIN
CN401 PIN DESCRIPTION CN601 PIN DESCRIPTION
PIN NO. Signal Name Name Function PIN NO. Signal Name Name Function
1 VH- Hall Sensor Bias 1 VIDEO-Y(1) Luminance Video Signal (lnterlace)
2 HW- Hall Sensor 2 GND Ground
3 HW+ Hall Sensor 3 VIDEO-Cr/Pr Component Video Signal
4 HV- Hall Sensor 4 GND Ground
5 HV+ Hall Sensor 5 VIDEO-Cb/Pb Component Video Signal
6 HU- Hall Sensor 6 GND Ground
7 HU+ Hall Sensor 7 VIDEO-Y(I/P) Luminance Video Signal
8 VCC +5v Power Supply 8 GND Ground
9 U Spindle Motor Drive 9 VIDEO-C Chrominance Video Signal
10 V Spindle Motor Drive 10 GND Ground
11 W Spindle Motor Drive 11 AUDIO(R)-IN R-ch Audio Signal
12 T-SCN3 LED 12 GND Ground
13 T-SCN2 Encoder Input 13 AUDIO(L)-IN L-ch Audio Signal
14 GND Ground 14 GND Ground
15 SL+ Sled Control Signal(+) 15 AUDIO(R)-OUT Audio R ch Signal
16 SL- Sled Control Signal(-) 16 GND Ground
17 SW1 Tray open switch 17 AUDIO(L)-OUT Audio L ch Signal
18 GND Ground
19 DVD-AUDIO-M
U
DVD Audio Mute Signal
CN501 PIN DESCRIPTION 20 AUDIO+5V +5V Power Supply
PIN NO. Signal Name Name Function 21 VIDEO-Y/CVBS Luminance Video Signal
1 SPDIF Digital Audio Signal 22 GND Ground
2 GND Ground 23 VIDEO-C Chrominance Video Signal
3 GND Ground 24 GND Ground
4 EV+10.5V +10.5V Power Supply 25 SUB-SCLK Serial Bus Clock
5 EV+10.5V +10.5V Power Supply 26 REG-CONT2 Power Regulator Control Signal
6 EV+10.5V +10.5V Power Supply 27 SUB-TXD Transmission Data to Main Microcontroller
7 GND Ground 28 RDY Submicon Ready/Busy
8 GND Ground 29 SUB-RXD Reception Data from Main Microcontroller
9 GND Ground 30 SYS-RESET System Reset Signal
10 GND Ground
11 P-ON+5V +5V Power Supply
12 P-ON+5V +5V Power Supply
13 P-ON+5V +5V Power Supply
14 EV+2.4V +2.4V Power Supply
15 EV+2.4V +2.4V Power Supply
16 EV+2.4V +2.4V Power Supply
17 EV+2.4V +2.4V Power Supply
18 GND Ground
19 GND Ground
20 P-ON+2.5V +2.5V Power Supply
21 P-ON+2.5V +2.5V Power Supply
22 P-ON+2.5V +2.5V Power Supply
23 GND Ground
24 GND Ground
25 P-ON+3.3V +3.3V Power Supply
26 P-ON+3.3V +3.3V Power Supply
27 P-ON+3.3V +3.3V Power Supply
28 GND Ground
29 GND Ground
30 GND Ground
