ER-A520/A530 Dealer Knowledge Book
Page 96 of 266 Specifications subject to change without notice: Revision date 10/07
Quick Steps – Scanner (Barcode Reader)
To quickly setup the ER-A520/ER-A530 to interface with a Scanner, please refer to the outlined
procedures below:
No. Description Comments/Procedure
Step–1 Connect the Scanner CH–1 or CH–2
Step–2
SRV Job#906-A
906 Æ [.] Æ [@] Æ 0xxx Æ [CA/AT]
Allow Stock Function Unconditionally
906 Æ [.] Æ [@] Æ 1xxx Æ [CA/AT]
Allow Stock Function Despite Error Message
906 Æ [.] Æ [@] Æ 2xxx Æ [CA/AT]
Inhibit PLU/UPC (EAN) item when Stock goes Negative
Step-3 SRV Job#906-D
906 Æ [.] Æ [@] Æ xxx0 Æ [CA/AT]
UPC Price Look Up at Refund Entry
Step-4 SRV Job#907-B 907 Æ [.] Æ [@] Æ x2xx Æ [CA/AT]
UPC (EAN) Codes printing on Receipt and Journal
Step-5 SRV Job#907-C 907 Æ [.] Æ [@] Æ xx1x Æ [CA/AT]
Enable Negative UPC
Step-6 SRV Job#909-B 909 Æ [.] Æ [@] Æ x0xx Æ [CA/AT]
Printing of UPC Data when Resetting
Step-7 SRV Job#911-B 911 Æ [.] Æ [@] Æ x4xx Æ [CA/AT]
C/D Check of UPC (EAN)
Step-8 SRV Job#921-A 921 Æ [.] Æ [@] Æ 4xxx Æ [CA/AT]
Convert UPC-E Codes to UPC-A Codes
Step-9 SRV Job#971
971 File Groups 14-22, 23, 24 and 26 -
Optional
Step-10
SRV Job#950 (Optional)
• Place the [DEPT#] Key (Function #106) on the keyboard
• Place the [AMT] Key (Function #109) on the keyboard
• Place the [REPEAT] Key (Function #110) on the keyboard
• Place the [INQ] Key (Function #111) on the keyboard
• Place the [NO DEL] Key (Function #112) on the keyboard
• Place the [PRCHNG] Key (Function #113) on the keyboard
Step-11
PGM Job #2690
2690 Æ [.] Æ [@] Æ 2 Æ @ Æ 1000 [SBTL] Æ [CA/AT] for CH–1)
or
2690 Æ [.] Æ [@] Æ 2 Æ @ Æ 2000 [SBTL] Æ [CA/AT] for CH–2)
Note: Must match the physical connection
Step-12
Program Reset
• Place the SRV-Key counter-clockwise to 6 o’clock position
(SRV’ position)
• Count 5 seconds
• Turn SRV-Key clockwise to 7o’clock position (SRV position)
• Verify”***PROGRAM RESET has printed on the journal-side
tape.
Step-13
PGM Job #2691
2691 Æ [.] Æ [@] Æ WXYZ Æ [SBTL] Æ [CA/AT]-
W: Data Bit 7bits/8 bits = 1/0
X: Parity Bit Non/Odd/Even = 2/1/0
Y: Stop Bit 1 bit/2 bits = 1/0
Z: Transmission Speed 19200bps/9600bps/4800 bps = 2/1/0
To Next Page
