ER-A520/A530 Dealer Knowledge Book
Page 210 of 266 Specifications subject to change without notice: Revision date 10/07
CAT Function Setting - 7112
A: Food Stamp Mode Disable/Enable =1/0
B: PIN Pad is connected to CAT (Data Tran SL) for Debit Cards – Not Available
No/Yes = 1/0
C: Key Type PIN Pad – Not Available Index/Dukpt/Static = 2/1/0
D: Dial Mode for Dialing Out Pulse/Tone =1/0
Note: The “B” bit MUST be set to [NO] if the PIN Pad is not connected or else the Data
Tran SL will not initialize.
MRS = 0000, Change to 0100.
Note: The encryption of the Verifone PIN Pad (Not Available) must match the merchant
parameters set in the Data Tran SL. This will correspond with the setting programmed in
PGM Job#7112.
CAT Time Out #1 - 7113
XXX: Time Out Value (1- 255 sec.)
MRS = 030, Change to 010.
Notes: Time limit for reading of the card data.
The time out value for the Data Tran should be between “5~60” seconds.
