ER-A520/A530 Dealer Knowledge Book
Page 260 of 266 Specifications subject to change without notice: Revision date 10/07
Quick Start Procedures
For a quick reference procedure for using the LogoLoader utility with the ER-A520/530, please use the
sequential steps outlined in the chart below.
Step PC Side Step ER-A520/530 Side
2
Set SRV Job #912-D: 1, 2, or 5"
PGM2 Mode
Set Job #2690
2690 . @ 1 @ 1000 SBTL CASH for CH-1
2690 . @ 1 @ 2000 SBTL CASH for CH-2
Baud Rate Setting - Job #6112
6112 . @ 7 CASH
1 Connect the PC to the ER-A520/530 (CH-2).
3 Launch the LogoLoader.exe at the PC.
4
Select the option to change the communication details; specify:
Baud Rate: 38,400
Full-Duplex
Com Port: based on your PC configuration
Click [OK]
6
From the Main window, choose the option to send the graphic
logo. Select the previously created logo image and click [Open ].
7 View the image to verify that it is the correct one and click [Send].
8
You must make the Send to Header or Footer selection, but go to
the ER-A520/530 prior to clicking [Yes] or [No].
9
At the ER-A520/530, place the key to the
REG position.
10
Click [Yes] or [No].
The PC will display the Communication Status to indicate the
progress of the transmission.
11
The ER-A520/530 will displayCC2 while
communications is in session.
12 Perform the PGM (SRV) Reset
