ER-A520/A530 Dealer Knowledge Book
Page 82 of 266 Specifications subject to change without notice: Revision date 10/07
Quick Steps – Remote Kitchen Printer
To quickly setup the ER-A520/ER-A530 to interface with a Remote Kitchen Printer, please refer to
the outlined procedures below:
No. Description Comments/Procedures
Step–1 Connect the Remote Printers KP#1 on CH–1 or KP#2 on CH–2
Step–2 SRV Job#918-A 918 Æ [.] Æ [@] Æ 4xxx Æ [CA/AT]
Output of Set PLU to KP
Step-3 SRV Job#918-B 918 Æ [.] Æ [@] Æ x2xx Æ [CA/AT]
Red Color Print on KP when PLU/UPC’s are ZERO price items
Step-4 SRV Job#918-C 918 Æ [.] Æ [@] Æ x0xx Æ [CA/AT]
Like Items Consolidation on KP
Step-5
SRV Job#918-C
918 Æ [.] Æ [@] Æ x1xx Æ [CA/AT]
Dept/PLU and UPC (EAN) Text Print on KP in Double Size
Character
Step-6 SRV Job#926-A 926 Æ [.] Æ [@] Æ 3xxx Æ [CA/AT]
Sending Direct VOID and Past Item VOID Data to the KP
Step–6 SRV Job#926-B 926 Æ [.] Æ [@] Æ x0xx Æ [CA/AT]
Sending Refund Data to the KP
Step-7 SRV Job#929-A 926 Æ [.] Æ [@] Æ 1xxx Æ [CA/AT]
Detail KP Print Format when Finalizing (Expediter Print Format)
Step-8
SRV Job#950
• Place the [RP Send] Key (Function #114) on the keyboard if
required.
Note: The RP Send Key can send an item to the remote KP before
finalizing the transaction.
Step-9 SRV Job#971 Create #37 KP Buffer
Step-10
PGM Job #2690
KP#1: 2690 Æ [.] Æ [@] Æ 2 Æ @ Æ 0100 [SBTL] Æ [CA/AT] for CH–1)
or
KP#2: 2690 Æ [.] Æ [@] Æ 2 Æ @ Æ 0020 [SBTL] Æ [CA/AT] for CH–2)
Note: Must match the physical connection
Step-11
PGM Job #2692
2692 Æ [.] Æ [@] Æ X Æ @ Æ ABC [SBTL] Æ [CA/AT]
X: KP No. KP2/KP1 =2/1
A: Logo Text Print Yes/No =1/0
B: Auto Cut Yes/No =1/0
C: Type of Printer
TM-T88III+Logo /TM-T88III/TM-U230/TM-U220 = 3/2/1/0
Step-12
Program Reset
• Place the SRV-Key counter-clockwise to 6 o’clock position
(SRV’ position)
• Count 5 seconds
• Turn SRV-Key clockwise to 7o’clock position (SRV position)
• Verify”***PROGRAM RESET has printed on the journal-side
tape.
Step-13
Other PGM2 Mode Programming
3653 Æ [.] Æ [@] Æ X Æ @ Æ Y Æ [SBTL] Æ [CA/AT]
X: KP No. KP2/KP1 = 2/1
Y: Back Up Printer KP2/KP1/Nothing = 2/1/0
3654Æ [.] Æ [@] Æ X Æ @ Æ Name (12 Max) Æ [SBTL] Æ [CA/AT
X: KP No. KP2/KP1 = 2/1
Characters can be entered by using the character keys or numeric
keys.
XXX Æ 00 Key XXX: Character Code (Digits)
To Next Page
