Sharp HT-SBW460 User Manual

E-3
Controls and indicators
Sound bar
Wireless subwoofer
1. Display window – Show the current status.
2. Remote Control Sensor – Receive signal
from the remote control.
3. Wall bracket screws
4. (ON/OFF) button – Switch the unit
between ON and Standby mode.
5. (SOURCE) button – Select the play
function.
6. button – Play/pause/resume playback
in Bluetooth/USB mode. Press and hold to
activate the pairing function in Bluetooth mode
or disconnect the existing paired Bluetooth
device.
7. VOL+ / VOL- buttons – Increase/decrease the
volume level.
8. AC~ Socket
9. COAXIAL Socket
10. OPTICAL Socket
11. USB Socket – Insert the USB device to play
music.
12. AUX Socket – Connect to an external audio
device.
13. HDMI (1/2/ARC) Sockets – Connect to a TV
via HDMI cable.
1. AC~ Socket – Connect to power.
2. PAIR button – Press activate the pairing
function between the sound bar and the
subwoofer.
3. PAIR Indicator – Light up solidly when the
pairing succeed.
aux
123
4 5 6 7
8 9 10 11 12 13
1 2 3
HT-SBW460 asean.indd 3 20/2/2020 11:42:14 AM

Sharp HT-SBW460 Specifications

General

Audio decoders	Dolby Atmos, Dolby Digital, Dolby Digital Plus, Dolby TrueHD
RMS rated power	440 W
Audio output channels	3.1 channels
Audio Return Channel (ARC)	Yes
Wi-Fi	No
Bluetooth version	4.2
HDMI ports quantity	3
Connectivity technology	Wired & Wireless
Digital audio coaxial in	1
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Soundbar power consumption	25 W
Power consumption (standby)	0.5 W
Subwoofer power consumption	20 W
Soundbar speaker RMS power	100 W
Subwoofer connectivity	Wireless
Subwoofer frequency range	50 - 130 Hz
Display type	LED
Product color	Metallic
Package type	Box
Package depth	273 mm
Package width	1023 mm
Package height	395 mm
Package weight	10300 g
Cables included	AC, AUX, HDMI
Soundbar frequency range	120 - 20000 Hz
Remote control battery type	AAA
Number of remote control batteries	2
Master (outer) case width	1040 mm
Master (outer) case height	535 mm
Master (outer) case length	285 mm
Master (outer) case weight	22800 g
Quantity per master (outer) case	2 pc(s)
Master (outer) case GTIN (EAN/UPC)	8586018085502

Weight and Dimensions

Depth	105 mm
Width	950 mm
Height	70 mm
Soundbar weight	2500 g
Subwoofer width	240 mm
Subwoofer height	415 mm
Subwoofer weight	5400 g
