Sharp HT-SBW460 User Manual

E-6
System preparation
BA
A: Normal Placement (place Sound bar on levelled
surface in front of TV)
B: Wall Mounting
Make sure to unplug the AC power lead before
installing the sound bar or changing the
position.
Wall mounting
Cautions:
● Be very careful to prevent the sound bar [1.5 kg
(3.3 lbs.)] from falling when mounting on the
wall.
● Before mounting, check the wall strength. (Do
not put on the veneer plaster or whitewashed
wall. The sound bar may fall.) If unsure, consult
a qualified service technician.
● Check all wall mount angle screws for looseness.
● Select a good location. If not, accidents may
occur or the sound bar may get damaged.
● SHARP is not responsible for accidents
resulting from improper installation.
1. Drill 4 parallel holes (Ø 5.5 mm - 6 mm each
according to wall type) in the wall. The distance
between the holes should be 893 mm. Firmly fix
1 dowel into each hole in the wall if necessary.
2. If it is a solid brick, first insert the expansion
rubber into the hole. Tighten the wall mount
brackets on the wall with screws and
screwdriver (not included). Make sure that they
are securely installed.
3. Remove the screws at the back of the unit.
Install the wall mounting screws into the back
of the unit.
4. Lift the unit onto the wall mount brackets and
slot into place.
Notes:
● Installation must be carried out by qualified
personnel only. Incorrect assembly can result
in severe personal injury and property damage
(if you intend to install this product yourself, you
must check for installations such as electrical
wiring and plumbing that may be buried inside
the wall). It is the installer’s responsibility to
verify that the wall will safely support the total
load of the sound bar and wall brackets.
● Additional tools (not included) are required for
the installation.
● Do not overtightened screws.
● Keep this instruction manual for future reference.
● Use an electronic stud finder to check the wall
type before drilling and mounting.
893 mm
893 mm
Remove the
screws
Install the
wall mounting
screws
Ø5.5~6mm
32mm
1 3
4
2
HT-SBW460 asean.indd 6 20/2/2020 11:42:16 AM
2.6
5.73

Sharp HT-SBW460 Specifications

General

Audio decoders	Dolby Atmos, Dolby Digital, Dolby Digital Plus, Dolby TrueHD
RMS rated power	440 W
Audio output channels	3.1 channels
Audio Return Channel (ARC)	Yes
Wi-Fi	No
Bluetooth version	4.2
HDMI ports quantity	3
Connectivity technology	Wired & Wireless
Digital audio coaxial in	1
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Soundbar power consumption	25 W
Power consumption (standby)	0.5 W
Subwoofer power consumption	20 W
Soundbar speaker RMS power	100 W
Subwoofer connectivity	Wireless
Subwoofer frequency range	50 - 130 Hz
Display type	LED
Product color	Metallic
Package type	Box
Package depth	273 mm
Package width	1023 mm
Package height	395 mm
Package weight	10300 g
Cables included	AC, AUX, HDMI
Soundbar frequency range	120 - 20000 Hz
Remote control battery type	AAA
Number of remote control batteries	2
Master (outer) case width	1040 mm
Master (outer) case height	535 mm
Master (outer) case length	285 mm
Master (outer) case weight	22800 g
Quantity per master (outer) case	2 pc(s)
Master (outer) case GTIN (EAN/UPC)	8586018085502

Weight and Dimensions

Depth	105 mm
Width	950 mm
Height	70 mm
Soundbar weight	2500 g
Subwoofer width	240 mm
Subwoofer height	415 mm
Subwoofer weight	5400 g
