LC-19D1E/S-BK/WH
2
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
[1] PRINTED WIRING BOARD ASSEMBLY
N DUNTKE683FM07 CG N V MAIN Unit
N DUNTKE243FM02 BK N V DIGITAL TUNER Unit
N DUNTKE523FM01 BP N V SUB Unit
N DUNTKE248WE01 AQ N V R/C LED Unit
N DUNTKE249WE01 AL N V SW Unit
N RDENCA242WJQ1 BC N S POWEWR Unit (Unit Replacement Item
[2] LCD PANEL
R1LK185T3GW10W CH N J 18.5" WXGA LCD Panel Module
[3] MAIN Unit (DUNTKE683FM07)
C301 VCKYCZ1AB104KY AB J Capacitor 0.1 10V Ceramic
C302 VCKYCZ1AB104KY AB J Capacitor 0.1 10V Ceramic
C303 VCKYCZ1AB104KY AB J Capacitor 0.1 10V Ceramic
C304 VCKYCZ1AB104KY AB J Capacitor 0.1 10V Ceramic
C305 VCKYCZ1AB104KY AB J Capacitor 0.1 10V Ceramic
C306 VCKYCZ1AB104KY AB J Capacitor 0.1 10V Ceramic
C307 VCKYCY1AB105KY AB J Capacitor 1 10V Ceramic
C308 VCKYCY1AB105KY AB J Capacitor 1 10V Ceramic
C309 VCKYCY1AB105KY AB J Capacitor 1 10V Ceramic
C310 VCKYCY1AB105KY AB J Capacitor 1 10V Ceramic
C311 VCKYCZ1EB103KY AA J Capacitor 0.01 25V Ceramic
C312 RC-KZA237WJZZY AB J Capacitor 10 16V Ceramic
C313 RC-KZA237WJZZY AB J Capacitor 10 16V Ceramic
C314 RC-KZA067WJZZY AB J Capacitor 4.7 Ceramic
C315 VCKYCZ1AB104KY AB J Capacitor 0.1 10V Ceramic
C316 VCKYCZ1AB104KY AB J Capacitor 0.1 10V Ceramic
C317 RC-KZA067WJZZY AB J Capacitor 4.7 Ceramic
C318 RC-KZA067WJZZY AB J Capacitor 4.7 Ceramic
C330 VCKYCY1AB105KY AB J Capacitor 1 10V Ceramic
C331 VCKYCY1AB105KY AB J Capacitor 1 10V Ceramic
C333 RC-KZA237WJZZY AB J Capacitor 10 16V Ceramic
C334 VCKYCY1AB105KY AB J Capacitor 1 10V Ceramic
C335 VCKYCY1AB105KY AB J Capacitor 1 10V Ceramic
C337 VCKYCZ1HB102KY AB J Capacitor 1000p 50V Ceramic
C338 VCKYCZ1HB102KY AB J Capacitor 1000p 50V Ceramic
C341 RC-KZA114WJZZY AB J Capacitor 1 25V Ceramic
C342 VCKYCY1AB105KY AB J Capacitor 1 10V Ceramic
C343 VCKYCY1AB105KY AB J Capacitor 1 10V Ceramic
C344 RC-KZA529WJQZY AA J Capacitor 0.1 16V Ceramic
C345 VCKYTV1CB105KY AC J Capacitor 1 16V Ceramic
C346 RC-KZA114WJZZY AB J Capacitor 1 25V Ceramic
C347 RC-KZA114WJZZY AB J Capacitor 1 25V Ceramic
C348 VCKYTV1CB105KY AC J Capacitor 1 16V Ceramic
C349 VCKYCY1EB334KY AB J
Capacitor 0.33 25V Ceramic
C350 VCKYCY1CB683KY AC J Capacitor 0.068 16V Ceramic
C351 VCKYCY1CB683KY AC J Capacitor 0.068 16V Ceramic
C352 VCKYCZ1AB104KY AB J Capacitor 0.1 10V Ceramic
C353 RC-KZA154WJZZY AB J Capacitor 4.7 16V Ceramic
C354 VCKYTV1CB105KY AC J Capacitor 1 16V Ceramic
C355 VCKYTV1CB105KY AC J Capacitor 1 16V Ceramic
C357 RC-KZA114WJZZY AB J Capacitor 1 25V Ceramic
C358 VCKYCZ1AB104KY AB J Capacitor 0.1 10V Ceramic
C359 VCCCCZ1HH150JY AB J Capacitor 15p 50V Ceramic
C360 VCCCCZ1HH150JY AB J Capacitor 15p 50V Ceramic
C361 VCKYCZ1AB104KY AB J Capacitor 0.1 10V Ceramic
C362 RC-KZA114WJZZY AB J Capacitor 1 25V Ceramic
C363 VCKYCY1CB683KY AC J Capacitor 0.068 16V Ceramic
C364 VCKYCY1CB683KY AC J Capacitor 0.068 16V Ceramic
C365 VCKYCY1EB334KY AB J Capacitor 0.33 25V Ceramic
C366 VCKYCZ1AB104KY AB J Capacitor 0.1 10V Ceramic
C367 VCEASY1CN227MY AC J Capacitor 220 16V Electrolytic
C368 VCKYCZ1HB102KY AB J Capacitor 1000p 50V Ceramic
C369 VCKYCZ1HB102KY AB J Capacitor 1000p 50V Ceramic
C370 VCKYCZ1HB102KY AB J Capacitor 1000p 50V Ceramic
C371 VCKYCZ1HB102KY AB J Capacitor 1000p 50V Ceramic
C401 RC-KZA237WJZZY AB J Capacitor 10 16V Ceramic
C402 VCKYCZ1EB103KY AA J Capacitor 0.01 25V Ceramic
C403 VCCCCZ1HH330JY AB J Capacitor 33p 50V Ceramic
C404 VCCCCZ1HH330JY AB J Capacitor 33p 50V Ceramic
C405 VCKYCZ1AB104KY AB J Capacitor 0.1 10V Ceramic
C406 RC-KZA237WJZZY AB J Capacitor 10 16V Ceramic
C407 VCKYCZ1EB103KY AA J Capacitor 0.01 25V Ceramic
C408 VCCCCY1HH560JY AB J Capacitor 56p 50V Ceramic
C409 VCCCCY1HH560JY AB J Capacitor 56p 50V Ceramic
C410 VCKYCZ1AB104KY AB J Capacitor 0.1 10V Ceramic
C411 VCKYCY1HB102KY AA J Capacitor 1000p 50V Ceramic
C412 VCKYCY1HB102KY AA J Capacitor 1000p 50V Ceramic
C701
VCKYCZ1EB103KY AA J Capacitor 0.01 25V Ceramic
C702 RC-KZA237WJZZY AB J Capacitor 10 16V Ceramic
C703 RC-KZA529WJQZY AA J Capacitor 0.1 16V Ceramic
C704 VCKYCZ1EB103KY AA J Capacitor 0.01 25V Ceramic
C705 VCKYCZ1CB333KY AA J Capacitor 0.033 16V Ceramic
C706 RC-KZA114WJZZY AB J Capacitor 1 25V Ceramic
C707 VCKYCY1EB104KY AB J Capacitor 0.1 25V Ceramic
