LC-19D1E/S-BK/WH
1 – 1
LC19D1E-BK
Service Manual
CHAPTER 1. OPERATION MANUAL
[1] SPECIFICATIONS
Item
Video Colour System PAL/SECAM/NTSC 3.58/NTSC 4.43/PAL 60
TV
Function
ITU-R (B/G, I, D/K, L, L')
TV-Standard
LCD panel
Resolution 1,049,088 pixels (1366 X 768)
As a part of policy of continuous improvement, SHARP reserves the right to make design and specification changes for product
improvement without prior notice. The performance specification figures indicated are nominal values of production units. There may
be some deviations from these values in individual units.
VHF/UHF
E2-E69ch, F2-F10ch, I21-I69ch, IR A-IR Jch, (Digital: E5-E69ch)
CATV
Hyper-band, S1-S41ch
TV-Tuning System
Auto Preset 999 ch: non-Nordic / 9999 ch: Nordic (ATV: 99 ch), Auto Label, Auto Sort
STEREO/BILINGUAL NICAM/A2
Receiving
Channel
Brightness 300 cd/m
2
Viewing angles H : 176 V : 176
Audio amplifier 2W X 2
Speaker 75 mm X 30 mm
Terminals
9 pin D-sub male connector
EXT 2
EXT 3
RCA pin (Audio input), Component in (480I, 576I, 480P, 576P, 720P/50Hz, 720P/60Hz, 1080I/50Hz, 1080I/60Hz)
RS-232C
UHF/VHF 75Ω Din type (Analogue & Digital)
S-VIDEO (Y/C input), RCA pin (AV input)
Antenna input
EXT 5 3.5 mm jack (Audio input), 15 pin mini D-sub (PC)
OSD language
Czech/Dutch/English/Finnish/French/German/Greek/Hungarian/Italian/Polish/Portuguese/
Russian/Slovak/Spanish/Swedish/Turkish
Power Requirement
AC 220-240 V, 50 Hz
Power Consumption
Weight
18.5" LCD COLOUR TV, Model: LC-19D1E/LC-19D1S
18.5" Advanced Super View & Black TFT LCD
4.9 kg (Display only), 5.4 kg (Display with stand)
42 W (0.9 W Standby) (Method IEC60107)
Headphones
3.5 mm jack (Audio output)
EXT 1 SCART (AV input, Y/C input, RGB input, TV output)
EXT 4
HDMI (VGA, 480P, 576P, 720P/50Hz, 720P/60Hz, 1080I/50Hz, 1080I/60Hz), RCA pin (Audio input)
Operating temperature
Analogue
Digital DVB-T (2K/8K OFDM)
C. I. (Common Interface) EN50221, R206001
