LC-19D1E/S-BK/WH
3 – 19
6. Adjustment process mode menu
Page Line Item Description Remarks (adjustment detail, etc.)
11
1 MODEL C165EA Model name display
B882E E002-0
2 INCH SIZE 19 Inch number display
3 ERROR NO RESET 0 Lamp Error count and Reset
4 PUBLIC MODE OFF Setting of Hotel Mode
5 EXT CONTROL OFF Bus and uart opening
6 DTV CLEAR OFF
7 SYSCON VER ROM 1.13A GAIBU-.---- ROM and GAIBU version Number of Syscon are displayed.
8 M2 VER ROM 1.05A GAIBU-.---- ROM version of the M2 micon is displayed.
9 D SOFT VER 1.09 Digital processor soft version
10 D LOAD VER 2.8 Digital processor loader version
11 TERMINAL OK
"OK" at being suitable for software of inducing information by AD
of the substrate is displayed.
22
1 I2C DATA 000000000000 Write and read of data in I2C BUS control IC
2 I2C DATA WAIT Execution of write and read
3 SOUND Setting of SOUND item. Page4 (S1>S4)
4 TUNER Setting of TUNER item. Page2 (TU1>TU2)
5 DVP Setting of DVP item. Page5 (DVP1>DVP5)
6 DVP-M2 Setting of DVP-M2 item. Page27 (DVPM2 1>27)
7 OTHERS Setting of Others item. Page1
8 HOTEL POWERFIX ON Use setting of hotel mode power supply on fixation
9
S1 SOUND1
1VOLUME 0 Volume
\HDMI-D ANALOG
2 LOUT1VOL HP 48 48 For Headphone L-CH output GAIN adjustment
3 ROUT1VOL HP 48 48 For Headphone R-CH output GAIN adjustment
4 LOUT2VOL SP 56 56 For Speaker L-CH output GAIN adjustment
5 ROUT2VOL SP 56 56 For Speaker R-CH output GAIN adjustment
S2 SOUND2
1 PRESCALE FM/AM-B 29 PRESCALE setting (ATV-A2-BG)
2 PRESCALE FM/AM-D 29 PRESCALE setting (ATV-A2-DK)
3 PRESCALE FM/AM-DA 29 PRESCALE setting (ATV-A2-DK 300% modulation)
4 PRESCALE FM/AM-I 29 PRESCALE setting (ATV-A2-I)
5 PRESCALE FM/AM-M 29 PRESCALE setting (ATV-A2-M)
6 PRESCALE FM/AM-L 29 PRESCALE setting (ATV-A2-L)
7 PRESCALE NICAM 29 PRESCALE setting (ATV-A2-NICAM)
8 PRESCALE DTV 16 PRESCALE setting (ATV-A2-DTV)
9 PRESCALE SCART 16 PRESCALE setting (ATV-A2-SCART)
10 PRESCALE HDMI 16 PRESCALE setting (ATV-A2-HDMI)
11 PRESCALE PC 16 PRESCALE setting (ATV-A2-PC)
12 PRESCAKLE AV 16 PRESCALE setting (ATV-A2-AV)
13 DEPTH3D SP WON 15 3D sound setting (SP <FmSdata>[amp ] sound wide on)
S3 SOUND3
1 EQ1G 12 Equaliser setting
2 EQ2G 12 Equaliser setting
3 EQ3G 12 Equaliser setting
4 EQ4G 12 Equaliser setting
5 EQ5G 12 Equaliser setting
6 EQ1C 1 Equaliser setting
7 EQ2C 0 Equaliser setting
8 EQ3C 1 Equaliser setting
9 EQ4C 2 Equaliser setting
10 EQ5C 2 Equaliser setting
11 EQ3D MODE 1 Equaliser setting
12 EQ2BW 0 Equaliser setting
13 EQ3BW 0 Equaliser setting
14 EQ4BW 0 Equaliser setting
15 EQ offset OFF OFF Equaliser offset ON/OFF setting
