Sharp LC-19D1E/S-BK/WH User Manual

LC-19D1E/S-BK/WH
3 – 20
S4 SOUND4
SP HP
1 HPFEN 1 1 Setting of HPF ON/OFF except a HDMI input. Turn ON at 1.
2 HPFAPP 1 0
Setting of HPF 1st order IIR or 2nd order IIR except a HDMI input.
1st at 0. 2nd at 1.
3HPFCUT 2 0
Setting of cutoff frequency of HPF except a HDMI input. 245Hz at
3, the larger number has big Fc. The 1st is only 3.7Hz.
4 LIMEN 1 0 Setting of ON/OFF of auto level control on the DAC side. ON at 1.
5 LIMDCY 11 3
Setting of decay (release) time of auto level control on the DAC
side. The larger number is longer.
6LIMATK 11 2
Setting of attack time of auto level control on the DAC side. The
larger number is longer.
7LIMLVL 5 0
Setting of limit level of the auto level control. -6dBFS at 5. -1dBFS
at 0.
8 LIMBOOST 4 6 Setting of Boost level. 2dBUP at 2.
9 ALCSEL 0 0
Setting of ON/OFF of auto level control on the ADC side. The
ADC side does not use it now because ALC (LIMEN) is used at
the DAC side.
10 ALCMAX 7 7 This is not used now.
11 ALCMIN 0 0 This is not used now.
12 ALCHDL 0 0 This is not used now.
13 ALCLVL 10 10 This is not used now.
14 ALCMOD 1 1 This is not used now.
15 ALCDCY 3 3 This is not used now.
16 ALCATK 3 3 This is not used now.
17 NGEN 0 0
Setting of ON/OFF of the noise gate on the ADC side. This is not
used now.
18 NGTH 0 0
TU TUNER1
1 AFT UP 1.80 AFT Voltage initial level (ALL BAND)
2 AFT DOWN 1.20 AFT Voltage initial level (ALL BAND)
3 LSYNC 150 AFT Voltage initial level (HIGH BAND)
4 HSYNC 162 AFT Voltage initial level (HIGH BAND)
5 LSYNC2 150 AFT Voltage initial level (HIGH BAND)
6 HSYNC2 162 AFT Voltage initial level (HIGH BAND)
7 AVSYNC 1 AFT Voltage initial level (HIGH BAND)
TU TUNER2
1 AFT FARTIME 50 Channel preset time adjustment 1
2 AFT NEARTIME 30 Channel preset time adjustment 2
3 AFT NEARTIME 10 Channel preset time adjustment 3
4 AFT 1STEPTIME 10 Channel preset time adjustment 4
5 AFT CSYNCTIME 50 Channel preset time adjustment 5
6SYNC ON 10
Channel preset Synchronous judgment Count of a continuation
accordance
7 SYNC WIDTH 1 Channel preset Synchronous judgment Threhold level
8 AFT 2 Changeover of operation when AFT at the time of 1channel tuning
9MUTE OFF TIMING 0
Video mute reset, Sound mute reset timing at the time of RF tun-
ing,
10 COLOR SYSTEM SEMI-AUTO 0 Oeration of the color system AUTO at the time of RF tuning
D-1 DVP1
1 TAMP1 L 101 TAMP adjustment (for DVP-M2) Y lower level setting
2 YDATA 103 (variable) TAMP adjustment (for DVP-M2) data READ level
3 TAMP1 H 105 TAMP adjustment (for DVP-M2) Y upper level setting
4 TAMP ALL OFF TAMP adjustment (for DVP-M2/X/BE) set to ON when adjustting.
5 NTSC TAMP1 89 TAMP adjustment (for DVP-M2) (It is automatically set.)
6 PAL TAMP1 96 TAMP adjustment (for DVP-M2) setting
7 SECAM TAMP1 96 TAMP adjustment (for DVP-M2) (It is automatically set.)
D2-1 DVP2-1
1 IN1 0 Standard value 1
2 IN2 0 Standard value 2
3 IN3 0 Standard value 3
4 IN4 0 Standard value 4
5 IN5 102 Standard value 5
6 IN6 204 Standard value 6
Page Line Item Description Remarks (adjustment detail, etc.)
