Sharp LC-19D1E/S-BK/WH User Manual

LC-19D1E/S-BK/WH
3 – 21
D2-2 DVP2-2
1 R6 816 adjustment Point 6
2 G6 816 adjustment Point 6
3 B6 816 adjustment Point 6
4 R5 408 adjustment Point 5
5 G5 408 adjustment Point 5
6 B5 408 adjustment Point 5
7 R4 0 adjustment Point 4
8 G4 0 adjustment Point 4
9 B4 0 adjustment Point 4
10 R3 0 adjustment Point 3
11 G3 0 adjustment Point 3
12 B3 0 adjustment Point 3
13 R2 0 adjustment Point 2
14 G2 0 adjustment Point 2
15 B2 0 adjustment Point 2
16 R1 0 adjustment Point 1
17 G1 0 adjustment Point 1
18 B1 0 adjustment Point 1
19 ADJ SETTING OK 0
adjusted information setting by RS232C
0: not yet adjusted 1: adjusted
D3 DVP3(M2-HD)
1 AUTO GAIN-OFFSET ALL
DVP-M2 (Component:HD) GAIN and offset auto adjustment OFF/
RUN
2 AUTO GAIN-OFFSET OFF
DVP-M2 (Component:HD) GAIN and offset auto adjustment OFF/
RUN
3 AD R GAIN 16 DVP-M2 (Component:HD) input Red GAIN adjustment
4 AD G GAIN 16 DVP-M2 (Component:HD) input Green GAIN adjustment
5 AD B GAIN 16 DVP-M2 (Component:HD) input Blue GAIN adjustment
6 AD R OFFSET 0 DVP-M2 (Component:HD) input Red offset adjustment
7 AD G OFFSET 0 DVP-M2 (Component:HD) input Green offset adjustment
8 AD B OFFSET 0 DVP-M2 (Component:HD) input Blue offset adjustment
9 RGTAR GGTAR BGTAR DA B6 DA
DVP-M2 (Component:HD) input Red/Green Blue GAIN adjust-
ment target level
10 RGCAL GGCAL BGCAL 80 00 80 Display for Y level, Chroma calculation level
11 ROCAL GOCAL BOCAL 00 00 00 Display for Y level of clamping area, white level calculated level
12 RHPOS GHPOS BHPOS 0469 0171 0501 Data acquisition Point H coordinates (Cr)(Y)(Cb)
13 RVPOS GVPOS BVPOS 00C8 00C8 00C8 Data acquisition Point H coordinates (Cr)(Y)(Cb)
D4 DVP4(M2-SD)
1 AUTO GAIN-OFFSET OFF
DVP-M2 (Component:SD) GAIN and offset auto adjustment OFF/
RUN
2 AD R GAIN 40 DVP-M2 (Component:SD) input Red GAIN adjustment
3 AD G GAIN 16 DVP-M2 (Component:SD) input Green GAIN adjustment
4 AD B GAIN 40 DVP-M2 (Component:SD) input Blue GAIN adjustment
5 AD R OFFSET 0 DVP-M2 (Component:SD) input Red offset adjustment
6 AD G OFFSET 0 DVP-M2 (Component:SD) input Green offset adjustment
7 AD B OFFSET 0 DVP-M2 (Component:SD) input Blue offset adjustment
8 RGTAR GGTAR BGTAR DA 7F DA
DVP-M2 (Component:SD) input Red/Green/Blue GAIN adjust-
ment target level
9 RGCAL GGCAL BGCAL 80 00 80 Display for Y level, Chroma calculation level
10 ROCAL GOCAL BOCAL 00 00 00 Display for Y level of clamping area, white level calculated level
11 RHPOS GHPOS BHPOS 054C 0182 060E Data acquisition Point H coordinates (Cr)(Y)(Cb)
12 RVPOS GVPOS BVPOS 0064 0064 0064 Data acquisition Point H coordinates (Cr)(Y)(Cb)
Page Line Item Description Remarks (adjustment detail, etc.)
