Sharp LC-19D1E/S-BK/WH User Manual

LC-19D1E/S-BK/WH
3 – 22
D5 DVP5(M2-PC)
1 AUTO GAIN-OFFSET OFF DVP-M2 (PC) GAIN and offset auto adjustment OFF/RUN
2 AD R GAIN 24 DVP-M2 (PC) input Red GAIN adjustment
3 AD G GAIN 24 DVP-M2 (PC) input Green GAIN adjustment
4 AD B GAIN 24 DVP-M2 (PC) input Blue GAIN adjustment
5 AD R OFFSET 0 DVP-M2 (PC) input Red offset adjustment
6 AD G OFFSET 0 DVP-M2 (PC) input Green offset adjustment
7 AD B OFFSET 0 DVP-M2 (PC) input Blue offset adjustment
8 RGTAR GGTAR BGTAR B6 B6 B6 DVP-M2 (PC) input Red/Green Blue GAIN adjustment target level
9 RGCAL GGCAL BGCAL 80 00 80 Display for Y level, Chroma calculation level
10 ROCAL GOCAL BOCAL 00 00 00 Display for Y level of clamping area, white level calculated level
11 RHPOS GHPOS BHPOS 03EB 02E8 0468 Data acquisition Point H coordinates (Cr)(Y)(Cb)
12 RVPOS GVPOS BVPOS 00C8 00C8 00C8 Data acquisition Point H coordinates (Cr)(Y)(Cb)
M2-1 DVP-M2 1
1 DVP-DATA 0000 00 ----- (----) Adjustable setting item in general for a DVP examination.
2 DVP TEST PATTERN 0 Test pattern selection. Adjustable setting item in general
3 VCDOFFSET 15 The minimum oscillation cycle of verticality countdown
4 VCDWINDOW 30 The cycle range of verticality countdown
5 ENDPOINT 0 ENDPOINT setting
6 STARTPOINT 25 STARTPOINT setting
M2-2 DVP-M2 2
1 N358 AV CONT 158 N358 CONTRAST setting (Composite, S video)
2 N358 AV BRIGHT 528 N358 BRIGHT setting (Composite, S video)
3 N358 AV COLOR 150 N358 COLOR setting (Composite, S video)
4 N358 AV TINT 128 N358 TINT setting (Composite, S video)
5 N358 AV SHARP V OVER 200 N358 V picture quality setting (Composite, S video)
6 N358 AV SHARP V UNDER 300 N358 V picture quality setting (Composite, S video)
7 N358 AV SHARP H1 OVER 200 N358 H picture quality setting 1(Composite, S video)
8 N358 AV SHARP H1 UNDER 200 N358 H picture quality setting 1(Composite, S video)
9 N358 AV SHARP H2 OVER 200 N358 H picture quality setting 2(Composite, S video)
10 N358 AV SHARP H2 UNDER 200 N358 H picture quality setting 2(Composite, S video)
M2-3 DVP-M2 3
2 N443 AV CONT 158 N443 CONTRAST setting (Composite, S video)
4 N443 AV BRIGHT 528 N443 BRIGHT setting (Composite, S video)
6 N443 AV COLOR 139 N443 COLOR setting (Composite, S video)
8 N443 AV TINT 128 N443 TINT setting (Composite, S video)
10 N443 AV SHARP V OVER 200 N443 V picture quality setting (Composite, S video)
12 N443 AV SHARP V UNDER 300 N443 V picture quality setting (Composite, S video)
14 N443 AV SHARP H1 OVER 200 N443 H picture quality setting 1(Composite, S video)
16 N443 AV SHARP H1 UNDER 200 N443 H picture quality setting 1(Composite, S video)
18 N443 AV SHARP H2 OVER 200 N443 H picture quality setting 2(Composite, S video)
20 N443 AV SHARP H2 UNDER 200 N443 H picture quality setting 2(Composite, S video)
M2-4 DVP-M2 4
1 PAL TV CONT 180 PAL CONTRAST setting (TV)
2 PAL AV CONT 176 PAL CONTRAST setting (Composite, S video)
3 PAL TV BRIGHT 528 PAL BRIGHT setting (TV)
4 PAL AV BRIGHT 528 PAL BRIGHT setting (Composite, S video)
5 PAL TV COLOR 155 PAL COLOR setting (TV)
6 PAL AV COLOR 155 PAL COLOR setting (Composite, S video)
7 PAL TV TINT 128 PAL TINT setting (TV)
8 PAL AV TINT 128 PAL TINT setting (Composite, S video)
9 PAL TV SHARP V OVER 100 PAL V picture quality setting (TV)
10 PAL AV SHARP V OVER 200 PAL V picture quality setting (Composite, S video)
11 PAL TV SHARP V UNDER 150 PAL V picture quality setting (TV)
12 PAL AV SHARP V UNDER 300 PAL V picture quality setting (Composite, S video)
13 PAL TV SHARP H1 OVER 100 PAL H picture quality setting 1 (TV)
14 PAL AV SHARP H1 OVER 200 PAL H picture quality setting 1(Composite, S video)
15 PAL TV SHARP H1 UNDER 100 PAL H picture quality setting 1 (TV)
16 PAL AV SHARP H1 UNDER 200 PAL H picture quality setting 1(Composite, S video)
17 PAL TV SHARP H2 OVER 100 PAL H picture quality setting 2 (TV)
18 PAL AV SHARP H2 OVER 200 PAL H picture quality setting 2(Composite, S video)
19 PAL TV SHARP H2 UNDER 100 PAL H picture quality setting 2 (TV)
20 PAL AV SHARP H2 UNDER 200 PAL H picture quality setting 2(Composite, S video)
Page Line Item Description Remarks (adjustment detail, etc.)
