Sharp LC-19D1E/S-BK/WH User Manual

LC-19D1E/S-BK/WH
9
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
R8709 VRS-CZ1JF470JY AA J Resistor 47 1/16W Metal Oxide
R8717 VRS-CZ1JF3R9JY AA J Resistor 3.9 1/16W Metal Oxide
R8718 VRS-CZ1JF3R9JY AA J Resistor 3.9 1/16W Metal Oxide
R8719 VRS-CZ1JF3R9JY AA J Resistor 3.9 1/16W Metal Oxide
R8720 VRS-CK1JF101JY AA J Resistor 100 1/16W Metal Oxide
R8721 VRS-CZ1JF3R9JY AA J Resistor 3.9 1/16W Metal Oxide
R8722 VRS-CZ1JF3R9JY AA J Resistor 3.9 1/16W Metal Oxide
R8723 VRS-CZ1JF3R9JY AA J Resistor 3.9 1/16W Metal Oxide
R8724 VRS-CZ1JF3R9JY AA J Resistor 3.9 1/16W Metal Oxide
R8725 VRS-CZ1JF3R9JY AA J Resistor 3.9 1/16W Metal Oxide
R8726 VRS-CZ1JF391FY AA J Resistor 390 1/16W Metal Oxide
R8727 VRS-CK1JF101JY AA J Resistor 100 1/16W Metal Oxide
R8728 VRS-CJ1JF101JY AA J Resistor 100 1/16W Metal Oxide
R8730 VRS-CJ1JF220JY AA J Resistor 22 1/16W Metal Oxide
R8732 VRS-CZ1JF103JY AA J Resistor 10k 1/16W Metal Oxide
R8733 VRS-CZ1JF103JY AA J Resistor 10k 1/16W Metal Oxide
R8738 VRS-CJ1JF103JY AA J Resistor 10k 1/16W Metal Oxide
R8740 VRS-CZ1JF332JY AA J Resistor 3.3k 1/16W Metal Oxide
R9221 VRS-TV1JD101JY AA J Resistor 100 1/10W Metal Oxide
R9302 VRS-CZ1JF000JY AA J Resistor 0 1/16W Metal Oxide
R9303 VRS-CZ1JF101JY AA J Resistor 100 1/16W Metal Oxide
R9304 VRS-CZ1JF512FY AA J Resistor 5.1k 1/16W Metal Oxide
R9305 VRS-CZ1JF101JY AA J Resistor 100 1/16W Metal Oxide
R9306 VRS-CZ1JF000JY AA J Resistor 0 1/16W Metal Oxide
R9308 VRS-CZ1JF000JY AA J Resistor 0 1/16W Metal Oxide
R9311 VRS-CZ1JF000JY AA J Resistor 0 1/16W Metal Oxide
R9313 VRS-CZ1JF000JY AA J Resistor 0 1/16W Metal Oxide
R9314 VRS-CZ1JF000JY AA J Resistor 0 1/16W Metal Oxide
R9316 VRS-CZ1JF000JY AA J Resistor 0 1/16W Metal Oxide
R9318 VRS-CZ1JF000JY AA J Resistor 0 1/16W Metal Oxide
R9320 VRS-CZ1JF000JY AA J Resistor 0 1/16W Metal Oxide
R9321 VRS-CZ1JF000JY AA J Resistor 0 1/16W Metal Oxide
R9322 VRS-CZ1JF101JY AA J Resistor 100 1/16W Metal Oxide
R9323 VRS-CZ1JF101JY AA J
Resistor 100 1/16W Metal Oxide
R9324 VRS-CZ1JF101JY AA J Resistor 100 1/16W Metal Oxide
R9361 VRS-CZ1JF223JY AA J Resistor 22k 1/16W Metal Oxide
R9362 VRS-CZ1JF472JY AA J Resistor 4.7k 1/16W Metal Oxide
R9363 VRS-CZ1JF473JY AA J Resistor 47k 1/16W Metal Oxide
R9364 VRS-CZ1JF101JY AA J Resistor 100 1/16W Metal Oxide
R9365 VRS-CZ1JF101JY AA J Resistor 100 1/16W Metal Oxide
R9366 VRS-CZ1JF101JY AA J Resistor 100 1/16W Metal Oxide
R9367 VRS-CZ1JF101JY AA J Resistor 100 1/16W Metal Oxide
R9368 VRS-CZ1JF101JY AA J Resistor 100 1/16W Metal Oxide
R9369 VRS-CZ1JF220JY AA J Resistor 22 1/16W Metal Oxide
R9371 VRS-CZ1JF103JY AA J Resistor 10k 1/16W Metal Oxide
R9376 VRS-CZ1JF101JY AA J Resistor 100 1/16W Metal Oxide
RDA801 PRDARA389WJFW AG J Heat Sink (FOR DVP M2)
SC401 QSOCN0344FJZZ AM J Socket (EXT 5)
SC402 QSOCZA136WJZZQ AG J Socket (EXT 4)
SC1201 QCNCWA251WJZZY AH J Connector 23pin (MA)
SC1202 QCNCWA251WJZZY AH J Connector 23pin (MB)
SC1203 QCNCWA251WJZZY AH J Connector 23pin (MC)
SC1204 QCNCWA010WJZZY AE J Connector 15pin (PA)
SC9201 QCNCW2367WJZZY AG J Socket 80pin
X301 RCRSCA161WJQZY AE J Crystal
X802 RCRSCA101WJZZY AG J Crystal
X803 RCRSCA147WJZZY AG J Crystal
X8701 RCRSCA134WJZZY AE J Crystal
N PSPAZB312WJKZ AD J Himelon (25*25_T2.0)
[4] DIGITAL TUNER Unit Unit (DUNTKE243FM02)
C204 VCEASX0JN337MY AD J Capacitor 330 6.3V Electrolytic
C205 VCKYCY1HB103KY AA J Capacitor 0.01 50V Ceramic
C207 RC-KZA237WJZZY AB J Capacitor 10 16V Ceramic
C209 VCKYCZ1AB104KY AB J Capacitor 0.1 10V Ceramic
C210 VCKYCZ1AB104KY AB J Capacitor 0.1 10V Ceramic
C211 RC-KZA237WJZZY AB J Capacitor 10 16V Ceramic
C214 RC-KZA237WJZZY AB J Capacitor 10 16V Ceramic
C215 VCKYCY1HB103KY AA J Capacitor 0.01 50V Ceramic
C216 VCKYCY1HB103KY AA J Capacitor 0.01 50V Ceramic
C217 VCEASX0JN107MY AC J Capacitor 100 6.3V Electrolytic
C218 VCKYCY1HB103KY AA J Capacitor 0.01 50V Ceramic
C219 VCEASX1AN336MY AC J Capacitor 33 10V Electrolytic
C227 VCKYCY1CB104KY AB J Capacitor 0.1 16V Ceramic
C235 RC-KZA237WJZZY AB J Capacitor 10 16V Ceramic
C238 VCKYCZ1AB104KY AB J Capacitor 0.1 10V Ceramic
C239 VCKYCZ1AB104KY AB J Capacitor 0.1 10V Ceramic
C240 VCKYCZ1HB102KY AB J Capacitor 1000p 50V Ceramic
C241 VCKYCZ1EB103KY AA J Capacitor 0.01 25V Ceramic
C242 VCKYCZ1HB102KY AB J Capacitor 1000p 50V Ceramic
C243 VCKYCZ1AB104KY AB J Capacitor 0.1 10V Ceramic
C246 RC-KZA388WJZZY AC J Capacitor 10 6.3V Ceramic
C248 RC-KZA237WJZZY AB J Capacitor 10 16V Ceramic
C249 RC-KZA237WJZZY AB J Capacitor 10 16V Ceramic
C253 VCKYCZ1AB104KY AB J Capacitor 0.1 10V Ceramic
[3] MAIN Unit (DUNTKE683FM07)
