Sharp LC-19D1E/S-BK/WH User Manual

LC-19D1E/S-BK/WH
19
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
[7] KEY Unit (DUNTKE249WE01)
D151 RH-EX0269TAZZY AB V Zener Diode PDZ15B,115
D152 RH-EX0269TAZZY AB V Zener Diode PDZ15B,115
D155 RH-EX0269TAZZY AB V Zener Diode PDZ15B,115
P151 QPLGNA324WJZZY AC J Plug 4pin (LF)
R151 VRS-CY1JF822JY AA J Resistor 8.2k 1/16W Metal Oxide
R152 VRS-CY1JF123JY AA J Resistor 12k 1/16W Metal Oxide
R153 VRS-CY1JF822JY AA J Resistor 8.2k 1/16W Metal Oxide
R154 VRS-CY1JF123JY AA J Resistor 12k 1/16W Metal Oxide
S151 QSW-KA029WJZZY AD J Switch CH UP
S152 QSW-KA029WJZZY AD J Switch CH DOWN
S153 QSW-KA029WJZZY AD J Switch INPUT
S154 QSW-KA029WJZZY AD J Switch VOL UP
S155 QSW-KA029WJZZY AD J Switch VOL DOWN
S156 QSW-KA029WJZZY AD J Switch MENU
S157 QSW-KA029WJZZY AD J Switch POWER

Sharp LC-19D1E/S-BK/WH Specifications

General

Brand	Sharp
Model	LC-19D1E/S-BK/WH
Category	LCD TV
Language	English
