LC-19D1E/S-BK/WH
21
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
[8] CABINET PARTS
1 CCABAB811WJ15 AY N S CAB-A Ass'y (LC-19D1E/K/S BK)
1 CCABAB811WJ16 AY N S CAB-A Ass'y (LC-19D1E/K/S WH)
1-1 Not Available - N - CAB-A
1-2 GCOVAC325WJ4A AX J SP NET (LC-19D1E/K/S BK)
1-2 GCOVAC325WJ4B AS J SP NET (LC-19D1E/K/S WH)
1-3 HDECQA765WJ4A AD J LED DEC COVER
1-4 PSPAHB419WJ00 AB J MASK HIMELON-S, x2
1-5 PSPAHB420WJ00 AC J MASK HIMELON-L, x2
2 CCABBB152WJ01 AX N S CAB-B Ass'y (LC-19D1E/K/S BK)
2 CCABBB152WJ02 AX N S CAB-B Ass'y (LC-19D1E/K/S WH)
2-1 Not Available - N - CAB-B
2-2 PSHEZA066WJZZ BX J PROTECT SHEET
2-3 PSPAHB421WJ00 N HIMERON, x2
3 CANGTA465WJ03 AT J VESA ANG ASS'Y
3-1 LANGTA465WJ4W VESA ANG
3-2 PSPAHB418WJ00 AB N J HIMELON
3-3 PZETKA237WJKZ AE V BARRIER VESA
4 CHLDZA867WJ02 AF V SP HOLDER UNIT-R
4-1 LHLDZA867WJ4Z SP HOLDER R
4-2 PSPAGA378WJZZ AB V GOMU BUSH, x2
4-3 PSPAHB326WJ00 AC N V HIMERON
4-4 PSPAZB608WJZZ AC V SP SPACER
5 CHLDZA874WJ02 AF V SP HOLDER UNIT-L
5-1 LHLDZA874WJ4Z SP HOLDER L
5-2 PSPAGA378WJZZ AB V GOMU BUSH, x2
5-3 PSPAHB326WJ00 AC N V HIMERON
5-4 PSPAZB608WJZZ AC V SP SPACER
6 DUNTKE683FM07 CG N V MAIN Unit
7 DUNTKE523FM01 BP N V SUB Unit
8 DUNTKE248WE01 AQ N V R/C, LED Unit
9 DUNTKE249WE01 AL N V SW UNIT
10 RDENCA242WJQ1 BC N S POWER SUPPLY Unit
11 DUNTKE243FM02 BK N V DIGITAL TUNER Unit
12 GCOVAC327WJ4A AD J
BAS CONE COVER (LC-19D1E/K/S BK)
12 GCOVAC327WJ4B AD J BAS CONE COVER (LC-19D1E/K/S WH)
13 GCOVAC613WJ4A AC N S RS232C COVER (LC-19D1E/K/S BK)
13 GCOVAC613WJ4B AC N S RS232C COVER (LC-19D1E/K/S WH)
14 JBTN-A675WJ4A AG J CONTROL BTN (LC-19D1E/K/S BK)
14 JBTN-A675WJ4B AF J CONTROL BTN (LC-19D1E/K/S WH)
15 LHLDW1173CEZZ AD J Wire Holder, x6 (FOR LAMP LED SP)
16 LHLDWA092WJZZ AB J Wire Holder, x4
17 LX-BZA202WJF7 AA J Screw, x16 (PWB10 SLD3 ANG2)
18 LX-HZA011WJFN AB J Screw, x2 (FOR SP HOLDER)
19 MHNG-A166WJ4Z AS J HINJI
20 NSFTZ0134CEFW AD J Shaft, x2 (FOR PC TANSI)
21 NSFTZ0135CEFW AD J Shaft, x2 (FOR RS232)
22 PFLT-A090WJZZ AD N S 50*42 EMC SHEET
23 PSLDMB176WJ4W AN N S MAIN SHIELD
24 PSLDMB178WJ4W AG J SOURCE PBW SLD
25 PSPAGA367WJZZ AA S SPACER
26 PSPAZB626WJZZ AB J SHAKOU SPACER, x2
27 PZETKA236WJKZ AL J BARRIER POWER
28 PZETKA238WJKZ AD J BARRIER CNT PWB
29 TLABNC117WJZZ AC S MODEL LABEL
30 QCNW-H485WJQZ AH N J MAIN-LED
31 QCNW-H486WJQZ AF N J MAIN-KEY
32 QCNW-G141WJQZ AG J MAIN-SP
33 QEARZ0057CEFW AB J EARTH SPRING
34 QPWBM0242TPZZ AG V MAIN-FPC-LCD
35 LANGKB183WJ4A AF S CARD ANG (LC-19D1E/K/S BK)
35 LANGKB183WJ4B AF N S CARD ANG (LC-19D1E/K/S WH)
36 VSP7530PA128B AH N S SP(2W/75*30), x2
37 R1LK185T3GW10W CH N J 18.5" WXGA LCD Panel Module
!
38 RTUDAA019WJQZ BB S TUNER
40 XBBS940P10000 AB J Screw, x5 (FOR HINJI) (LC-19D1E/K/S BK)
40 XBBS740P10000 AA S Screw, x5 (FOR HINJI) (LC-19D1E/K/S WH)
41 XBPS830P06000 AA J Screw (FOR HDMI) (LC-19D1E/K/S BK)
41 XBPS730P06000 AA J Screw (FOR HDMI) (LC-19D1E/K/S WH)
42 XEBS930P14000 AA J Screw, x11 (CAB-A/B4 TANSI7) (LC-19D1E/K/S BK)
42 XEBSN30P14000 AA J Screw, x11 (CAB-A/B4 TANSI7) (LC-19D1E/K/S WH)
43 XEBSN30P10000 AA J Screw, x12 (SP PNL BTN LED)
44 XEBSN40P10000 AB J Screw, x3 (FOR VESA)
45 GCOVAC326WJ4A AG J STAND HINJI COVER (LC-19D1E/K/S BK)
45 GCOVAC326WJ4B AF J STAND HINJI COVER (LC-19D1E/K/S WH)
46 TLABZB921WJZZ AE N S POP LABEL
