Sharp LC-19D1E/S-BK/WH User Manual

LC-19D1E/S-BK/WH
3 – 29
M2-26 DVP-M2 26
1AV TH A 27
Polygonal line adjustment For AV
2 AV TH B 236
Polygonal line adjustment For AV
3 AV CONT A 95
Polygonal line adjustment For AV
4 AV CONT B 140
Polygonal line adjustment For AV
5 AV CONT C 43
Polygonal line adjustment For AV
6 PC TH A 255
Polygonal line adjustment For PC
7 PC TH B 255
Polygonal line adjustment For PC
8 PC CONT A 128
Polygonal line adjustment For PC
9 PC CONT B 128
Polygonal line adjustment For PC
10 PC CONT C 128
Polygonal line adjustment For PC
M2-27 DVP-M2 27
1 AUTO GAIN OK
2 AD R GAIN -16 SCART input Red GAIN adjustment
3 AD G GAIN 0 SCART input Green GAIN adjustment
4 AD B GAIN 16 SCART input Blue GAIN adjustment
5 AD R OFFSET +1 SCART input Red OFFSET adjustment
6 AD G OFFSET 0 SCART input Green OFFSET adjustment
7 AD B OFFSET -1 SCART input Blue OFFSET adjustment
8 SCART CONT 196 SCART CONTRAST setting
9 SCART BRIGHT 540 SCART BRIGHT setting
10 SCART COLOR 170 SCART COLOR setting
11 SCART TINT 128 SCART TINT setting
12 SCART SHARP V OVER 200 SCART V picture quality setting
13 SCART SHARP V UNDER 300 SCART V picture quality setting
14 SCART SHARP H1 OVER 200 SCART H picture quality setting 1
15 SCART SHARP H1 UNDER 200 SCART H picture quality setting 1
16 SCART SHARP H2 OVER 200 SCART H picture quality setting 2
17 SCART SHARP H2 UNDER 300 SCART H picture quality setting 2
18 RGTAR GGTAR BGTAR 40 40 40 SCART input Red/Green/Blue GAIN adjustment target level
19 RGCAL GGCAL BGCAL 00 00 00 Display for Y level, Chroma calculation level
20 ROCAL GOCAL BOCAL 00 00 00 Display for Y level of clamping area, white level calculated level
21 RHPOS GHPOS BHPOS 0000 0000 0000 Data acquisition Point H coordinates (Cr)(Y)(Cb)
22 RVPOS GVPOS BVPOS 0000 0000 0000 Data acquisition Point H coordinates (Cr)(Y)(Cb)
OH OTHERS1
1 L ERROR WAIT 15s Lamp error detection WAIT time
2 L ERROR H TIME 1.0s Lamp error detection time
3 TV AUTO GAIN OFF Auto Gain setting when TV mode
4 PWM FREQ 160 Dimming control frequency setting (Hz)
5 PWM DUTY 100 Dimming duty setting (Hz)
6 OPC THRESHOLD 24
Brightness sensor shutdown mode → Input level threshold when
operation mode shifts
7 COMP SYSTEM AUTO The component-signal selecting within an adjustment process
8 COM BIAS 126 Common bias adjustment
9 REMOCON CODE 000 Remocon code SHARP
Page Line Item Description Remarks (adjustment detail, etc.)
