Sharp LC-26DA5U Service Manual

LC-26DA5U
LC-32DA5U
ERSATZTEILLISTE
AUSTAUSCH VON TEILEN
Les pi`eces de rechange qui pr élelesentent ces caract éleristiques
sp éleciales de s élecurit éle, sont identifi élees dans ce manuel :
lespi`eces élelectriques qui pr élesentent ces particularit éles, sont
rep éler élee par la marque ået sont hachur élees dans les listes de
pi`eces et dans les diagrammes sch élematiques.
La substitution d'une pi`ece de rechange par une autre qui ne pr
éLesente pas les m éoemes caract éLeristiques de s élecurit éle
que la pi`ece recommand élee parl'usine et dans ce manuel de serv-
ice, peut provoquer une éLelectrocution, un incendie ou toutautre
sinistre.
"COMMENT COMMANDER LES PIECES DE RECHANGE"
Pour que votre commande soit rapidement et correctement remplie,
veuillez fournir les renseignements suivants.
1. NUMERO DU MODELE 2. NO. DE REF
3. NO. DE PIECE 4. DESCRIPTION
in CANADA: Contact SHARP Electronics of Canada Limited
Phone (416) 890-2100
PARTS LIST
PARTS REPLACEMENT
Replacement parts which have these special safety characteristics
identified in this manual; electrical components having such features
are identified by å and shaded areas in the Replacement Parts
Lists and Schematic Diagrams. The use of a substitute replacement
part which dose no have the same safety characteristic as the fac-
tory recommended replacement parts shown in this service manual
may create shock, fire or other hazards.
"HOW TO ORDER REPLACEMENT PARTS"
To have your order filled promptly and correctly, please furnish the
following informations.
1. MODEL NUMBER 2. REF. NO.
3. PART NO. 4. DESCRIPTION
in USA: Contact your nearest SHARP Parts Distributor to order.
For location of SHARP Parts Distributor, Please call Toll-
Free; 1-800-BE-SHARP
★ MARKIERUNG : ERSATZTEILE-LIEFERUNG★ MARK: SPARE PARTS-DELIVERY SECTION
Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
80
PRINTED WIRING BOARD ASSEMBLIES
(NOT REPLACEMENT ITEM)
LC-26DA5U
DUNTKD352WE01 R AV Unit CA
DUNTKD353WE01 R KEY Unit AK
DUNTKD354WE01 R R/C, LED Unit AN
DUNTKD375FM01 R MAIN Unit CB
RDENCA138WJQZ X POWER SUPPLY Unit BW
LC-32DA5U
DUNTKD352WE02 R AV Unit CA
DUNTKD353WE01 R KEY Unit AK
DUNTKD354WE01 R R/C, LED Unit AN
DUNTKD375FM02 R MAIN Unit CB
RDENCA139WJQZ X POWER SUPPLY Unit BX
LCD PANEL
NOTE: THE PARTS HERE SHOWN ARE SUPPLIED AS AN
ASSEMBLY BUT NOT INDEPENDENTLY.
RLCUCA024WJZZ J 26" LCD Module DM
RLCUCA025WJZZ J 32" LCD Module DZ
TUNER
NOTE: THE PARTS HERE SHOWN ARE SUPPLIED AS AN
ASSEMBLY BUT NOT INDEPENDENTLY.
TU1101 VTUATMQH2-004 R Tuner BC
INTEGRATED CIRCUITS
IC1101 VHiPQ050DZ1-1Y R PQ050DZ01Z AE
IC1102 VHiM62320FP-1Y R M62320FP AH
IC1103 VHiBA7655AF-1Y R BA7655AF AG
IC1105 VHiM62334FP-1Y R M62334FP AH
IC1907 VHiPQ018EZ5-1Y R PQ018EZ5MZP AF
IC1912 VHiSii9021+-1Q R SIL9021CTU BC
IC1913 VHi24LC2BiN9ES R 24LC02B-I/SN AH
IC2501 RH-iX3370CEN2Q R MSP3440G-QA-C1 AX
IC2502 VHiTA2024++-1Y R TA2024 AX
IC2503 VHiBD4742G+-1Y R BD4742G-TR AD
IC2504 VHiBA4560F+-1Y R BA4560F-E2 AD
IC2507 VHiBA4560F+-1Y R BA4560F-E2 AD
IC2700 VHiNJU26111-1Q R NJU26111FR1 AT
IC2702 VHiAK4586VQ-1Q R AK4586VQ AY
IC2703 RH-iXA167WJZZY R PQ025EZ01ZZ AL
IC2704 VHiN2885D03-1Y R NJM2885DL103TE AE
IC3104 VHiUPD4721G-1Y R UPD4721GS-GJG AN
IC3800 VHiMM1630EQ-1Q R MM1630EQ AT
IC3802 VHiLTC1694C-1Y R LTC1694CS5#TR AM
IC3805 VHiNJM2750M-1Y R NJM2750M(TE2) AH
IC3808 VHiM62320FP-1Y R M62320FP AH
IC5701 VHiPQ09DZ1U-1Y R PQ09DZ1U AG
IC5702 VHiBA08SFP+-1Y R BA08SFP-E2 AG
IC5705 VHiBA033FP/-1Y R BA033FP-E2 AG
IC5706 VHiPQ05DZ1U-1Y R PQ05DZ1U AG
TRANSISTORS
Q1102 VSDTC314TK/-1Y R DTC314TK AC
Q1103 VSDTC314TK/-1Y R DTC314TK AC
Q1104 VS2SA1530AR-1Y R 2SA1530AR AB
Q1105 VS2SC3928AR-1Y R 2SC3928AR AB
Q1106 VS2SC3928AR-1Y R 2SC3928AR AB
Q1111 VS2SC3928AR-1Y R 2SC3928AR AB
Q1112 VS2SA1530AR-1Y R 2SA1530AR AB
Q1113 VS2SC3928AR-1Y R 2SC3928AR AB
Q1114 VS2SC3928AR-1Y R 2SC3928AR AB
DUNTKD352WE01 (LC-26DA5U)
DUNTKD352WE02 (LC-32DA5U)
AV Unit
