Sharp LC-26DA5U Service Manual

Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
LC-26DA5U
LC-32DA5U
93
FB3308 RBLN-0210TAZZY R Ferrite Beads AB
FB3309 RBLN-0210TAZZY R Ferrite Beads AB
LUG1801 QLUGHA009WJZZY R Lug AC
LUG1802 QLUGHA009WJZZY R Lug AC
LUG1803 QLUGHA009WJZZY R Lug AC
LUG1804 QLUGHA009WJZZY R Lug AC
LUG1805 QLUGHA009WJZZY R Lug AC
LUG1806 QLUGHA009WJZZY R Lug AC
LUG1807 QLUGHA009WJZZY R Lug AC
LUG1808 QLUGHA009WJZZY R Lug AC
LUG1809 QLUGHA009WJZZY R Lug AC
LUG1810 QLUGHA009WJZZY R Lug AC
LUG1811 QLUGHA009WJZZY R Lug AC
LUG1812 QLUGHA009WJZZY R Lug AC
P1001 QPLGNA144WJZZY R Plug, 20Pin AF
P1002 QPLGNA339WJZZY R Plug, 5Pin (KM) TO KEY AD
P1501 QPLGN0056CEZZY R Plug, 6Pin AD
P1801 QPLGNA181WJZZY R Plug, 12Pin AF
P1802 QPLGNA177WJZZY R Plug, 8Pin AE
P3201 QPLGNA493WJZZY R Plug, 32Pin AM
P3202 QPLGNA327WJZZY R Plug, 7Pin AC
P3203 QPLGNA162WJZZY R Plug, 6Pin AE
P3702 QPLGNA346WJZZY R Plug, 12Pin (FD) TO AV AD
SC1001 QSOCNA480WJQZYR Socket, 40Pin AG
SC3701 QSOCNA478WJZZY R Socket, 60Pin (FC) TO AV AF
DUNTKD375FM01 (LC-26DA5U)
DUNTKD375FM02 (LC-32DA5U)
MAIN Unit (Continued)
RDENCA138WJQZ (LC-26DA5U)
RDENCA139WJQZ (LC-32DA5U)
POWER SUPPLY Unit
INTEGRATED CIRCUITS
IC701 VHIMC33262D-1 J IC, MC33262D AK
IC702 VHITA76431S-1 J IC, TA76431S AD
IC703 VHITNY266P/-1 J IC, TNY266P AL
IC801 VHITA76431S-1 J IC, TA76431S AD
IC802 VHIMP1580P/-1 J IC, MP1580 DIP AL
IC803 VHIMP1580P/-1 J IC, MP1580 DIP AL
IC804 VHITA76431S-1 J IC, TA76431S AD
IC805 VHIMP1583P/-1 J IC, MP1583 DIP AM
IC806 VHITA76431S-1 J IC, TA76431S AD
TRANSISTORS
Q701 VSFQPF12N60C1 J FQPF12N60C(LC-32DA5U) AL
Q702 VS2SA1213-/-1 J 2SA1213(LC-32DA5U) AE
Q703 VSFQPF12N60C1 J FQPF12N60C AL
Q704 VS2SA1213-/-1 J 2SA1213 AE
Q705 VS2SC4672Q/-1 J 2SC4672Q AE
Q706 VSDTA124EK/-1 J DTA124EKA AB
Q707 VS2SK3520-01M J 2SK3520 AK
Q708 VS2SK3520-01M J 2SK3520 AK
Q709 VS2SD1781KQ-1 J 2SD1781 AC
Q710 VSDTA143EK/-1 J DTA143EK AA
Q711 VS2SC2411KR-1 J 2SC2411KR AC
Q712 VSDTA124EK/-1 J DTA124EKA AB
Q713 VSDTA114EK/-1 J DTA114EKA AB
Q714 VSDTD114EK/-1 J DTD114EKA AC
Q715 VS2SK3520-01M J 2SK3520-01MR AK
Q716 VS2SK3520-01M J 2SK3520-01MR AK
Q717 VS2SD1781KQ-1 J 2SD1781KQ AC
Q718 VSRT1P431C/P1 J RT1P431C AB
Q719 VS2SC2411KR-1 J 2SC2411KR AC
Q720 VS2SA2048KQP1 J 2SA2048KQ AC
Q721 VSDTC124EK/-1 J DTC124EKA AB
Q801 VS2SD1781KQ-1 J 2SD1781 AC
Q802 Not Available – 2SK3645 —
Q803 Not Available – 2SK3645(LC-32DA5U) —
Q804 VS2SA1036KQRC J 2SA1036 AC
Q805 VS2SC2411KR-1 J 2SC2411KR AC
Q807 VSDTC124EK/-1 J DTC124EK AB
Q808 VSDTC124EK/-1 J DTC124EK AB
Q809 VSDTC124EK/-1 J DTC124EK AB
Q810 VS2SD1781KQ-1 J 2SD1781 AC
Q811 VS2SK3236//-1 J 2SK3236 AL
Q812 VS2SK3236//-1 J 2SK3236 AL
Q813 VS2SA1036KQRC J 2SA1036 AC
Q814 VS2SC2411KR-1 J 2SC2411KR AC
Q816 VSSP8K3////P1 J SP8K3 AF
Q817 VSDTC124EK/-1 J DTC124EK AB
Q818 VSDTC124EK/-1 J DTC124EK AB
Q819 VSDTC124EK/-1 J DTC124EK AB
Q820 VSDTC124EK/-1 J DTC124EK AB
Q821 VSDTC124EK/-1 J DTC124EK AB
Q822 VSDTC124EK/-1 J DTC124EK AB
Q823 VS2SC2411KR-1 J 2SC2411KR AC
Q824 VSDTC124EK/-1 J DTC124EK AB
Q825 VSDTC124EK/-1 J DTC124EK AB
Q826 VSDTA124EK/-1 J DTA124EK AB
Q827 VSDTC124EK/-1 J DTC124EK AB
Q828 VSDTC124EK/-1 J DTC124EK AB
Q829 VSDTC124EK/-1 J DTC124EK AB
Q830 VSDTA144EK/-1 J DTC144EK AC
Q831 VSDTA124EK/-1 J DTA124EKA AB
Q832 VSDTC124EK/-1 J DTC124EK AB
DIODES
å D701 VHDD3SB60//-1 J D3SB60 AH
å D702 VHDD3SB60//-1 J D3SB60(LC-32DA5U) AH
D703 VHERLZ39B//-1 J ZenerDiode, RLZ39B AC
D704 VHERLZ39B//-1 J ZenerDiode, RLZ39B AC
