Sharp LC-26DA5U Service Manual

Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
LC-26DA5U
LC-32DA5U
94
D705 VHDFFPF10U60S J FFPF10U60STU AG
D707 VHDDAN202K/-1 J DAN202K(LC-32DA5U) AB
D708 VHDDAN202K/-1 J DAN202K AB
D709 VHD1SS355//-1 J 1SS355 AB
D710 VHD1SS355//-1 J 1SS355 AB
D711 VHDRLS245//-1 J RLS245 AB
D712 VHERLZ27B//-1 J ZenerDiode, RLZ27B AC
D713 VHD1SS355//-1 J 1SS355 AB
D714 VHDDAN202K/-1 J DAN202K AB
D715 VHDDAN202K/-1 J DAN202K AB
D716 VHD1SS355//-1 J 1SS355 AB
D717 Not Available – ZenerDiode, HZU15B2 —
(LC-26DA5U)
D717 Not Available – ZenerDiode, HZU9.1B2 —
(LC-32DA5U)
D718 VHD1SS355//-1 J 1SS355 AB
D719 VHDRLS245//-1 J RLS245 AB
D720 VHD1SS355//-1 J 1SS355 AB
D721 VHD1SS355//-1 J 1SS355 AB
D722 VHD1SS355//-1 J 1SS355 AB
D723 VHDRLS245//-1 J RLS245 AB
D724 VHERLZ27B//-1 J ZenerDiode, RLZ27B AC
D725 VHDDAN202K/-1 J DAN202K AB
D726 VHDDAN202K/-1 J DAN202K AB
D727 VHD1SS355//-1 J 1SS355 AB
D728 VHDRLS245//-1 J RLS245 AB
D729 VHD1SS355//-1 J 1SS355 AB
D730 VHEHZU16B2/-1 J ZenerDiode, HZU16B2 AB
D731 VHD1SS355//-1 J 1SS355 AB
D732 VHD1SS355//-1 J 1SS355 AB
D733 VHDSFPL52V/-1 J SFPL52 AD
å D734 VHD1SR139-600 J 1SR139-600 AC
å D735 VHD1SR139-600 J 1SR139-600 AC
åD736 VHD1SR139-600 J 1SR139-600 AC
åD737 VHD1SR139-600 J 1SR139-600 AC
D738 Not Available – 1N4937 —
D739 Not Available – 1N4937 —
D740 VHERLZ8.2A/-1 J ZenerDiode, RLZ8.2A AC
D741 VHDSFPL52V/-1 J SFPL52 AD
D742 VHD1SS355//-1 J 1SS355 AB
åD801 VHD1SS355//-1 J 1SS355 AB
D802 VHDRLS245//-1 J RLS245 AB
D803 VHDRLS245//-1 J RLS245 AB
D804 VHD1SS355//-1 J 1SS355 AB
D805 VHD1SS355//-1 J 1SS355 AB
D806 VHEHZU27B//-1 J ZenerDiode, HZU27B AC
D807 VHDSFPB74//-1 J (SR24)(SFPB74) AD
D808 VHDSFPB74//-1 J (SR24)(SFPB74) AD
D809 VHEHZU5.1B2-1 J ZenerDiode, HZU5.1B2 AC
D810 VHDSFPB74//-1 J (SR24)(SFPB74) AD
D811 VHEHZU6.8B2-1 J ZenerDiode, HZU6.8B2 AC
D812 Not Available – 1SR153-400 —
D813 VHD1SS355//-1 J 1SS355 AB
D814 VHEHZU16B2/-1 J ZenerDiode, HZU16B2 AB
D815 VHEHZU30B//-1 J ZenerDiode, HZU30B AC
D816 Not Available – ZenerDiode, HZU12B2 —
D817 VHD1SS355//-1 J 1SS355 AB
D819 VHDRLS245//-1 J RLS245 AB
D820 VHD1SS355//-1 J 1SS355 AB
D821 VHD1SS355//-1 J 1SS355 AB
D822 Not Available – ZenerDiode, HZU12B2 —
D823 VHDDAN202K/-1 J DAN202K AB
D824 VHEHZU16B2/-1 J ZenerDiode, HZU16B2 AB
D825 VHDSFPB74//-1 J (SR24)(SFPB74) AD
D826 VHDSFPB74//-1 J (SR24)(SFPB74) AD
D827 VHEHZU6.8B2-1 J ZenerDiode, HZU6.8B2 AC
D828 VHDSFPB69//-1 J SFPB69 AE
D829 VHERLZ36B//-1 J ZenerDiode, RLZ36B AC
D830 VHDSFPB74//-1 J SFPB74 AD
D831 VHDSFPB74//-1 J SFPB74 AD
D832 VHERLZ8.2A/-1 J ZenerDiode, RLZ8.2A AC
D835 VHD1SS355//-1 J 1SS355 AB
D836 VHEHZU16B2/-1 J ZenerDiode, HZU16B2 AB
D837 VHEHZU5.1B2-1 J ZenerDiode, HZU5.1B2 AC
D838 Not Available – ZenerDiode, HZU12B2 —
D839 VHD1SS355//-1 J 1SS355 AB
D840 VHD1SS355//-1 J 1SS355 AB
D841 VHEHZU2.2B/-1 J ZenerDiode, HZU2.2B AC
D842 VHDRLS245//-1 J RLS245 AB
D843 VHDRLS245//-1 J RLS245 AB
PHOTO COUPLER
åPC701 VHPPC123X2YFZ J PhotoCoupler, PC123X2YFZ AD
åPC702 VHPPC123X2YFZ J PhotoCoupler, PC123X2YFZ AD
åPC703 VHPPC123X2YFZ J PhotoCoupler, PC123X2YFZ AD
åPC704 VHPPC123X2YFZ J PhotoCoupler, PC123X2YFZ AD
åPC706 VHPPC123X2YFZ J PhotoCoupler, PC123X2YFZ AD
COILS AND FILTERS
åL701 Not Available – Filter, HF2836-123Y1R8-T01 —
(LC-26DA5U)
åL701 Not Available – Filter, HF2836-562Y2R5-T01 —
(LC-32DA5U)
åL702 Not Available – Filter, HF2836-123Y1R8-T01 —
(LC-26DA5U)
åL702 Not Available – Filter, HF2836-562Y2R5-T01 —
(LC-32DA5U)
L703 Not Available – Coil, C1293 (EE-33) —
(LC-26DA5U)
L703 Not Available – Coil, C1292 (EI-40) —
L704 RCILC1273SNEZ J Coil, TSL0709 (470uH) AE
L705 Not Available – Coil, LHL08TB471K (470uH) —
L706 Not Available –Coil, LHL13 (10mH) —
L801 RCILC1280SNEZ J Coil, A7503HY AF
L802 RCILC1281SNEZ J Coil, TSL0808 (22uH) AD
L803 Not Available – Coil, LHL08TB220K (22uH) —
L803 RCILC1281SNEZ J Coil, TSL0808 (22uH) AD
L804 RCILC1280SNEZ J Coil, A7503HY AF
L805 RCILC1262SNEZ J Coil, TSL1112 (1uH) AF
L806 Not Available – Coil, LHL10TB1R0M (1uH) —
L806 RCILC1262SNEZ J Coil, TSL1112 (1uH) AF
L807 RCILC1279SNEZ J Coil, TSL1112 (33uH) AE
L808 RCILC1281SNEZ J Coil, TSL0808 (22uH) AD
TRANSFORMERS
åT701 Not Available – EER28L (24V)P1292 —
T702 RTRNP1261SNEZ J UF1717V-282Y0R5-01 AF
åT703 Not Available – EER28L (24V)P1292 —
(LC-32DA5U)
åT704 Not Available – EER28L (10V)P1293 —
T705 RTRNP1261SNEZ J UF1717V-282Y0R5-01 AF
åT706 RTRNP1289SNPZ J EE19LP1289 AK
CAPACITORS
åC701 Not Available – 0.22 275V Film —
åC702 Not Available – 0.22 275V Film —
åC703 RC-CS222ESNEZ J 2200p 250V Ceramic AD
(LC-26DA5U)
åC703 Not Available – 3300p 250V Ceramic —
(LC-32DA5U)
åC704 RC-CS222ESNEZ J 2200p 250V Ceramic AD
(LC-26DA5U)
åC704 Not Available – 3300p 250V Ceramic —
(LC-32DA5U)
åC705 RC-CS222ESNEZ J 2200p 250V Ceramic AD
(LC-26DA5U)
åC705 Not Available – 3300p 250V Ceramic —
(LC-32DA5U)
åC706 Not Available – 0.047 275V Film —
åC707 RC-CS222ESNEZ J 2200p 250V Ceramic AD
(LC-26DA5U)
åC707 Not Available – 3300p 250V Ceramic —
(LC-32DA5U)
åC708 RC-CS222ESNEZ J 2200p 250V Ceramic AD
(LC-26DA5U)
å C708 Not Available – 3300p 250V Ceramic —
RDENCA138WJQZ (LC-26DA5U)
RDENCA139WJQZ (LC-32DA5U)
POWER SUPPLY Unit (Continued)
