Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
LC-26DA5U
LC-32DA5U
98
CABINET AND MECHANICAL PARTS
(LC-26DA5U)
1 CCABAB081WJ01 X Front Cabinet Ass'y BM
1-1
Not Availabl
e–Front Cabinet —
1-2 HBDGBA015WJSA X Badge, SHARP AK
1-3 HDECQA346WJSA X LED Decoration Cover AE
1-4 PSPAHA323WJZZ X Mask Spacer, x2 AC
1-5 PSPAHA324WJZZ X Mask Spacer, x2 AC
1-6 TLABZA635WJZZ X Energy Star Label AD
1-7 TLABZB030WJSA X POP Label AD
2 CCABBA640WJ02 X Rear Cabinet Ass'y BG
2-1
Not Availabl
e–Rear Cabinet —
2-2 HiNDPB369WJSA X AV Jack Indicator A AH
2-3 HiNDPB388WJSA X AV Jack Indicator B AM
2-4 HiNDPB449WJSA X AC Input Indicator AF
2-5 LHLDWA055WJKZ X Wire Holder, x2 AC
2-6 LHLDWA057WJKZ X Wire Holder AE
3 CCOVAB143WJ01 X Top Control Cover Ass'y AS
3-1
Not Availabl
e–Top Control Cover —
3-2 JBTN-A428WJKA X Operation Button AF
3-3 JBTN-A429WJKA X Power Button AD
3-4 MSPRCA049WJFW X Spring for Power Button AD
4
Not Availabl
e–Stand Ass'y —
4-1 CDAi-A171WJKB X Stand Base Ass'y BL
4-1-1
Not Availabl
e–Stand Base —
4-1-2
Not Availabl
e–Base Bracket —
4-1-3
Not Availabl
e–LEG-Cushion-B, x4 —
4-1-4
Not Availabl
e–LEG-Cushion-C, x4 —
4-1-5
Not Availabl
e–Screw,x8 —
4-2 CHNDPA014WJKC X Handle Ass'y BF
4-2-1
Not Availabl
e–Handle —
4-2-2
Not Availabl
e–Grip —
4-2-3
Not Availabl
e–Swivel Cover —
4-2-4
Not Availabl
e–Support —
4-2-5
Not Availabl
e–Swivel Base —
4-2-6
Not Availabl
e–Stand Hinge Ass'y —
4-2-7
Not Availabl
e–Spacer, x2 —
4-2-8
Not Availabl
e–Screw,x2 —
4-2-9
Not Availabl
e–Nut,x1 —
4-2-10
Not Availabl
e–Screw,x4 —
4-2-11
Not Availabl
e–Screw,x 4 —
4-3 XCBS950P25000 X Screw for Stand, x4 AB
5 RLCUCA024WJZZ J 26” LCD Module Unit DM
6 DUNTKD352WE01 R AV Unit CA
7 DUNTKD353WE01 R KEY Unit AK
8 DUNTKD354WE01 R R/C, LED Unit AN
9 DUNTKD375FM01 R MAIN Unit CB
10 RDENCA138WJQZ X POWER SUPPLY Unit BW
11 GCOVAB162WJKA X BUS CON Cover AH
12 GCOVAB215WJKA X Terminal Cover AV
13 GCOVAB348WJKA X Jack Cover B AG
14 GCOVAB355WJKA X Jack Cover A AK
15 GCOVAB356WJKA X Jack Cover C AK
16 HiNDPB382WJSA X Model Label AH
17 LANGKA259WJFW X Angle for VESA AH
18 LANGTA146WJFW X Center Angle AW
19 LHLDW1060CEZZ X Wire Holder AB
20 LHLDWA044WJKZ X Wire Holder AB
21 LHLDWA058WJKZ X Wire Holder AC
(for Main Shield A)
22 LHLDWA096WJKZ X Edge Saddle AD
23 NSFTZA144WJFN X Shaft Nut AD
24 PCOVUA080WJZZ X LED Shading Cover AD
25 PMLT-A240WJZZ X Gasket AM
26 PMLT-A242WJZZ X Gasket, x2 AD
27 PMLT-A244WJZZ X Gasket AE
29 PMLT-A247WJZZ X Gasket AD
30 PRDARA191WJFW X Heat Sink (for IC2502) AE
31 PMLT-A248WJZZ X Gasket, x2 AG
34 PRDARA192WJFW X Heat Sink (for IC3800) AE
37 PRDARA216WJFW X Heat Sink AF
(for IC2502 Back Side)
38 PSLDMA635WJZZ X Conduct Cloth AF
39 PSLDMA777WJZZ X Main Shield A AM
40 PSLDMA778WJZZ X Main Shield B AM
41 PSLDMA779WJFW X Main Shield C AK
42 PSLDMA836WJFW X LCD Control Shield AK
43 PSLDMA838WJZZ X Conduct Cloth AD
44 PSLDMA840WJZZ X Conduct Cloth AD
45 PSPAZA635WJKZ X Cooling Sheet (for IC2502) AD
46 PSPAZA636WJKZ X Cooling Sheet (for IC3800) AD
47 PSPAZA663WJKZ X Cooling Sheet, x2 AE
(for IC2502/IC3301)
48 QCNW-D280WJQZ X Connecting Cord AK
(SP:AV-SP)
49 QCNW-D282WJQZ X Connecting Cord AK
(RA:AV-LED)
50 QCNW-D766WJQZ X Connecting Cord AG
(FC:AV-MAIN(60p))
51 QCNW-D768WJQZ X Connecting Cord AG
(SH:MAIN-CONT)
52 QCNW-D770WJQZ X Connecting Cord AG
(MI:MAIN-INV)
53 QCNW-D771WJQZ X Connecting Cord AK
(PA:AV-POWER)
54 QCNW-D774WJQZ X Connecting Cord BB
(LV:MAIN-CONT)
55 QCNW-D776WJQZ X Connecting Cord AH
(KM:KEY-MAIN)
56 QCNW-D778WJQZ X Connecting Cord AG
(PG1:POW-INV)
57 QCNW-D787WJQZ X Connecting Cord AM
(PE-P/PD:MAIN-POW)
58 QCNW-E100WJQZ X Connecting Cord AH
(FD:AV-MAIN)
59 QEARPA172WJFW X Earth Spring C AC
60 RSP-ZA106WJZZ X Speaker (L) AX
61 RSP-ZA107WJZZ X Speaker (R) AX
62 LX-BZ3442CEF9 X Screw, x4 (for Stand) AA
63 XBBS930P06000 X Screw, x10 AA
(for AC-ANG/HDMI)
64 XBPS730P06WS0 X Screw, x33 (for PWB) AB
65 XEBS930P08000 X Screw, x7 (for Terminal) AA
66 XEBS940P16000 X
Screw, x16 (for Rear Cabinet)
AA
67 XEBSN30P10000 X Screw, x7 (for Key Unit) AA
68 XEBSN40P10000 X Screw, x4 (for VESA) AA
69 NSFTZ0134CEFW R Shaft Nut, x2 (for RS232C) AD
70 PSLDMA602WJFW R HDMI Shield Bottom AG
71 PSLDMA865WJFW R HDMI Shield Top_2 AE
72
Not Availabl
e–No. Label —
73 QEARPA176WJZZ X Copper Sheet AH
74 PMLT-A261WJZZ X Gasket AC
75 PSPAZA944WJZZ X Gasket AB
76 QEARZA060WJZZ X Gasket AD
77 LHLDWA080WJKZ X Wire Holder AB
78 PSPAZA660WJKZ X Cooling Sheet AC
79 PSPAZA818WJKZ X Cooling Sheet
To Next Page
