Sharp LC-26DA5U Service Manual

Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
LC-26DA5U
LC-32DA5U
82
C1151 RC-KZA113WJZZY R 4.7 16V Ceramic AB
C1152 RC-KZA109WJZZY R 10 16V Ceramic AC
C1153 VCCCCY1HH330JY R 33p 50V Ceramic AA
C1154 VCCCCY1HH330JY R 33p 50V Ceramic AA
C1155 RC-KZA109WJZZY R 10 16V Ceramic AC
C1156 RC-KZA109WJZZY R 10 16V Ceramic AC
C1157 RC-KZA109WJZZY R 10 16V Ceramic AC
C1158 RC-KZA109WJZZY R 10 16V Ceramic AC
C1159 VCKYCY1EF104ZY R 0.1 25V Ceramic AA
C1160 RC-KZA109WJZZY R 10 16V Ceramic AC
C1161 RC-KZA109WJZZY R 10 16V Ceramic AC
C1162 VCKYTV1CB105KY R 1 16V Ceramic AC
C1163 VCKYTV1CB105KY R 1 16V Ceramic AC
C1164 VCKYTV1CB105KY R 1 16V Ceramic AC
C1165 VCKYTV1CB105KY R 1 16V Ceramic AC
C1166 VCKYCY1EF104ZY R 0.1 25V Ceramic AA
C1170 VCKYCY1EF104ZY R 0.1 25V Ceramic AA
C1171 VCKYCY1HB103KY R 0.01 50V Ceramic AA
C1173 VCKYCY1HB103KY R 0.01 50V Ceramic AA
C1174 VCKYCY1HB103KY R 0.01 50V Ceramic AA
C1175 VCKYCY1HB103KY R 0.01 50V Ceramic AA
C1179 RC-KZA109WJZZY R 10 16V Ceramic AC
C1180 VCERML1CN106MY R 10 16V AC
C1181 VCKYCY1EF104ZY R 0.1 25V Ceramic AA
C1182 VCKYCY1EF104ZY R 0.1 25V Ceramic AA
C1193 VCERML1CN476MY R 47 16V AC
C1195 VCKYCY1HB103KY R 0.01 50V Ceramic AA
C1196 RC-KZA109WJZZY R 10 16V Ceramic AC
C1200 VCKYCY1EF104ZY R 0.1 25V Ceramic AA
C1209 VCEASY1HN226MY R 22 50V Electrolytic AC
C1226 VCKYCY1HB102KY R 1000p 50V Ceramic AA
C1227 VCKYCY1HB182KY R 1800p 50V Ceramic AA
C1228 VCKYCY1HB152KY R 1500p 50V Ceramic AA
C1229 VCKYCY1HB103KY R 0.01 50V Ceramic AA
C1230 VCKYCY1HB822KY R 8200p 50V Ceramic AB
C1900 VCAAPE0JJ227MY R 220 6.3V Electrolytic AE
C1901 VCKYCY1EF104ZY R 0.1 25V Ceramic AA
C1902 VCKYCY1HB102KY R 1000p 50V Ceramic AA
C1903 VCKYCY1EF104ZY R 0.1 25V Ceramic AA
C1904 VCKYCY1HB102KY R 1000p 50V Ceramic AA
C1905 VCKYCY1EF104ZY R 0.1 25V Ceramic AA
C1906 VCKYCY1HB102KY R 1000p 50V Ceramic AA
C1907 VCKYCY1EF104ZY R 0.1 25V Ceramic AA
C1908 VCKYCY1HB102KY R 1000p 50V Ceramic AA
C1909 VCKYCY1HB102KY R 1000p 50V Ceramic AA
C1910 VCKYCY1HB102KY R 1000p 50V Ceramic AA
C1911 VCKYCY1HB102KY R 1000p 50V Ceramic AA
C1912 VCKYCY1HB102KY R 1000p 50V Ceramic AA
C1913 VCAAPE0JJ227MY R 220 6.3V Electrolytic AE
C1914 VCKYCY1EF104ZY R 0.1 25V Ceramic AA
C1915 VCKYCY1HB102KY R 1000p 50V Ceramic AA
C1916 VCKYCY1EF104ZY R 0.1 25V Ceramic AA
C1917 VCKYCY1HB102KY R 1000p 50V Ceramic AA
C1918 VCKYCY1HB102KY R 1000p 50V Ceramic AA
C1919 VCKYCY1EF104ZY R 0.1 25V Ceramic AA
C1920 RC-KZA109WJZZY R 10 16V Ceramic AC
C1921 VCKYCY1EF104ZY R 0.1 25V Ceramic AA
C1922 VCKYCY1HB102KY R 1000p 50V Ceramic AA
C1923 RC-KZA109WJZZY R 10 16V Ceramic AC
C1924 VCKYCY1EF104ZY R 0.1 25V Ceramic AA
C1925 VCKYCY1HB102KY R 1000p 50V Ceramic AA
C1926 VCKYCY1EF104ZY R 0.1 25V Ceramic AA
C1927 VCERML1CN476MY R 47 16V AC
C1928 VCERML1CN476MY R 47 16V AC
C1929 VCCCCY1HH220JY R 22p 50V Ceramic AA
C1930 VCCCCY1HH220JY R 22p 50V Ceramic AA
C1966 VCKYCY1HB102KY R 1000p 50V Ceramic AA
C1968 VCKYCY1EF104ZY R 0.1 25V Ceramic AA
C1969 VCKYCY1HB102KY R 1000p 50V Ceramic AA
C1970 VCKYCY1HB102KY R 1000p 50V Ceramic AA
C1971 VCKYCY1HB102KY R 1000p 50V Ceramic AA
C1972 VCKYCY1HB102KY R 1000p 50V Ceramic AA
C1973 VCAAPE0JJ107MY R 100 6.3V Electrolytic AE
C1974 VCAAPE0JJ107MY R 100 6.3V Electrolytic AE
C1978 VCCCCY1HH560JY R 56p 50V Ceramic AB
C1979 VCCCCY1HH560JY R 56p 50V Ceramic AB
C1980 VCKYCY1HB102KY R 1000p 50V Ceramic AA
C1981 VCKYCY1HB102KY R 1000p 50V Ceramic AA
C1982 VCKYTV1CB105KY R 1 16V Ceramic AC
C1983 VCKYTV1CB105KY R 1 16V Ceramic AC
C1984 VCKYCY1EF104ZY R 0.1 25V Ceramic AA
C1998 VCERML1CN476MY R 47 16V AC
C1999 VCKYCY1EF104ZY R 0.1 25V Ceramic AA
C2501 VCKYCY1EF104ZY R 0.1 25V Ceramic AA
C2502 VCERML1CN107MY R 100 16V AC
C2503 RC-KZA113WJZZY R 4.7 16V Ceramic AB
C2504 VCKYCY1EF104ZY R 0.1 25V Ceramic AA
C2505 VCKYCY1EF104ZY R 0.1 25V Ceramic AA
C2506 VCKYCY1EF104ZY R 0.1 25V Ceramic AA
C2507 VCKYTV1CB105KY R 1 16V Ceramic AC
C2508 VCKYCY1HB222KY R 2200p 50V Ceramic AA
C2510 VCCCCY1HH331JY R 330p 50V Ceramic AA
C2511 VCCCCY1HH331JY R 330p 50V Ceramic AA
C2512 VCKYCY1HB682KY R 6800p 50V Ceramic AA
C2513 VCKYCY1HB682KY R 6800p 50V Ceramic AA
C2514 VCKYTV1CB105KY R 1 16V Ceramic AC
C2515 VCKYCY1HB222KY R 2200p 50V Ceramic AA
C2516 VCERML1CN106MY R 10 16V AC
C2517 VCERML1CN106MY R 10 16V AC
C2518 VCKYCY1EF104ZY R 0.1 25V Ceramic AA
C2519 VCERML1CN107MY R 100 16V AC
C2521 VCEASX1HN335MY R 3.3 50V Electrolytic AB
C2522 VCKYCY1EF104ZY R 0.1 25V Ceramic AA
C2523 VCKYCY1EF104ZY R 0.1 25V Ceramic AA
C2525 VCKYTV1CB105KY R 1 16V Ceramic AC
C2526 VCKYTV1CB105KY R 1 16V Ceramic AC
C2527 VCKYCY1EF104ZY R 0.1 25V Ceramic AA
C2528 VCERML1CN106MY R 10 16V AC
C2529 VCCCCY1HH471JY R 470p 50V Ceramic AA
C2530 VCERML1CN107MY R 100 16V AC
C2531 VCCCCY1HH560JY R 56p 50V Ceramic AB
C2532 VCKYCY1HB103KY R 0.01 50V Ceramic AA
C2533 VCKYCY1EF104ZY R 0.1 25V Ceramic AA
C2534 VCCCCY1HH4R0CY R 4p 50V Ceramic AA
C2535 VCCCCY1HH4R0CY R 4p 50V Ceramic AA
C2536 VCEASY1CN477MY R 470 16V Electrolytic AD
C2537 VCKYTV1CB105KY R 1 16V Ceramic AC
C2538 VCERMZ1CN227MY R 220 16V AD
C2539 VCKYCY1EF104ZY R 0.1 25V Ceramic AA
C2542 VCKYTV1CB105KY R 1 16V Ceramic AC
C2543 VCKYTV1CB105KY R 1 16V Ceramic AC
C2544 VCKYCY1HB222KY R 2200p 50V Ceramic AA
C2545 VCKYCY1HB222KY R 2200p 50V Ceramic AA
C2546 VCKYCY1EF104ZY R 0.1 25V Ceramic AA
C2547 VCKYCY1EF104ZY R 0.1 25V Ceramic AA
C2548 VCKYCY1EF104ZY R 0.1 25V Ceramic AA
C2549 VCKYTV1CB105KY R 1 16V Ceramic AC
C2550 VCKYTV1EB474KY R 0.47 25V Ceramic AC
C2551 VCKYTV1EB474KY R 0.47 25V Ceramic AC
C2552 VCKYCY1HB103KY R 0.01 50V Ceramic AA
C2553 VCKYTV1EB474KY R 0.47 25V Ceramic AC
C2554 VCKYTV1HB104KY R 0.1 50V Ceramic AA
C2555 VCKYCY1EF104ZY R 0.1 25V Ceramic AA
C2556 VCKYTV1EB474KY R 0.47 25V Ceramic AC
C2557 VCKYTV1EB474KY R 0.47 25V Ceramic AC
C2558 VCKYTV1EB474KY R 0.47 25V Ceramic AC
C2559 VCCCCY1HH220JY R 22p 50V Ceramic AA
C2560 VCKYTV1HB104KY R 0.1 50V Ceramic AA
C2561 VCERML1CN476MY R 47 16V AC
C2562 VCKYCY1HF223ZY R 0.022 50V Ceramic AB
C2563 RC-KZA113WJZZY R 4.7 16V Ceramic AB
C2564 RC-KZA113WJZZY R 4.7 16V Ceramic AB
C2565 VCCCCY1HH151JY R 150p 50V Ceramic AA
C2566 VCCCCY1HH151JY R 150p 50V Ceramic AA
C2567 VCKYTV1CB105KY R 1 16V Ceramic AC
C2568 VCKYTV1CB105KY R 1 16V Ceramic AC
C2571 VCCCCY1HH470JY R 47p 50V Ceramic AA
DUNTKD352WE01 (LC-26DA5U)
DUNTKD352WE02 (LC-32DA5U)
AV Unit (Continued)
