Sharp LC-26DA5U

Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
LC-26DA5U
LC-32DA5U
88
INTEGRATED CIRCUITS
IC1001 RH-iXB427WJZZQ R M30626MHP258GP AX
IC1002 VHiBD5224G+-1Y R BD5224G-TR AD
IC1003 VHiBR24L64F-1Y R BR24L64F-WE2 AK
IC1004 RH-iXB645WJQZQ R SST39VF1682-70 AS
IC1014 RH-iXB496WJQZQ R LC4128V-75TN10 AQ
IC1015 VHiTC7W66U/-1Y R TC7W66FU AE
IC1503 RH-iXB497WJQ1Q R LC4256V-75TN10 AW
IC1801 VHiPQ1CX12H-1Y R PQ1CX12H2ZP AK
IC1803 VHiPQ1CZ41H-1Y R PQ1CZ41H2ZP AG
IC1804 VHiPQ1X331M-1Y R PQ1X331M2ZP AD
IC1805 VHiPQ050DNA-1Y R PQ050DNA1ZPH AE
IC1806 VHiTPS54350-1Y R TPS54350PWPR AN
IC1807 VHiPQ1MX55M-1Y R PQ1MX55M2SP AD
IC1808 VHiPQ1KA903-1Y R PQ1KA903MZPH AD
IC1809 VHiPQ1R50//-1Y R PQ1R50 AF
IC1810 VHiBD5224G+-1Y R BD5224G-TR AD
IC1811 VHiBD5224G+-1Y R BD5224G-TR AD
IC3201 VHiDS90C386-1Y R DS90CF386MTDX AP
IC3202 VHiD90C385A-1Y R DS90C385AMTX AN
IC3203 VHiTCLCX08F-1Y R TC74LCX08F AF
IC3204 VHiiCS570B+-1Y R ICS570BT AQ
IC3301 RH-iXB405WJZZQ R SVP-EX59 BK
IC3302 RH-iXB375WJZZQ R K4D263238G-VC3 BA
IC3303 RH-iXA361WJZZY R LP2995MX AM
IC3701 VHiTCVT244AFTY R TC74VHCT244AFT AG
IC3702 VHiLVC244T+-1Y R SN74LVC244APWR AF
IC3703 VHiTCVHC02T-1Y R I.C. AB
IC3707 VHiPQ1X331M-1Y R PQ1X331M2ZP AD
TRANSISTORS
Q1803 VSRTQ045N03-1Y R RTQ045N03 AE
Q3701 VSUM6K1NTN+-1Y R UM6K1NTN+ AC
Q3705 VS2SC3928AR-1Y R 2SC3928AR AB
Q3706 VS2SC3928AR-1Y R 2SC3928AR AB
Q3707 VS2SC3928AR-1Y R 2SC3928AR AB
Q3708 VS2SC3928AR-1Y R 2SC3928AR AB
Q3709 VS2SC3928AR-1Y R 2SC3928AR AB
Q3710 VS2SA1530AR-1Y R 2SA1530AR AB
Q3712 VS2SA1530AR-1Y R 2SA1530AR AB
DIODES AND LED'S
D1001 RH-PXA018WJZZY R GM1HD55200A AC
D1002 RH-EX1234CEZZY R Zener Diode, 3.6V AE
D1004 RH-EXA092WJZZY R Zener Diode, 12V AB
D1005 RH-EX1234CEZZY R Zener Diode, 3.6V AE
D1006 RH-EX1234CEZZY R Zener Diode, 3.6V AE
D1801 VHDLi124+++-1Y R Li124 AC
D1802 VHDDG1M3+++-1Y R DG1M3 AC
D1805 VHD1SS355//-1Y R 1SS355 AB
D1806 VHDDG1M3+++-1Y R DG1M3 AC
D3301 RH-EX1234CEZZY R Zener Diode, 3.6V AE
PACKAGED CIRCUITS
TH1002 VHHM1103J03-1Y R Thermistor AC
X1001 RCRSCA117WJZZY R Crystal AG
X3301 RCRSC0170TAZZY R Crystal AG
COILS
L1801 RCiLCA039WJZZY R Coil AF
L1802 RCiLCA039WJZZY R Coil AF
L1803 RCiLCA031WJZZY R Coil AD
L3201 VPD9M100KR86NY R Peaking, 10µ HAC
L3202 VPD9M100KR86NY R Peaking, 10µ HAC
L3203 RCiLFA071WJZZY R Coil AD
L3204 RCiLFA071WJZZY R Coil AD
L3205 RCiLFA071WJZZY R Coil AD
L3206 RCiLFA071WJZZY R Coil AD
L3207 RCiLFA071WJZZY R Coil AD
L3301 VPD9M2R2JR96NY R Peaking, 2.2µHAC
L3302 VPD9M2R2JR96NY R Peaking, 2.2µHAC
DUNTKD375FM01 (LC-26DA5U)
DUNTKD375FM02 (LC-32DA5U)
MAIN Unit
L3303 VPD9M2R2JR96NY R Peaking, 2.2µHAC
L3304 RCiLFA071WJZZY R Coil AD
L3305 RCiLFA071WJZZY R Coil AD
L3306 RCiLFA071WJZZY R Coil AD
L3307 RCiLFA071WJZZY R Coil AD
L3308 RCiLFA071WJZZY R Coil AD
L3701 VPD9M220J2R7NY R Peaking, 22µHAC
L3702 VPD9M220J2R7NY R Peaking, 22µHAC
CAPACITORS
C1001 VCERML1CN476MY R 47 16V AC
C1002 VCKYCY1HB102KY R 1000p 50V Ceramic AA
C1003 VCKYCY1HB102KY R 1000p 50V Ceramic AA
C1004 VCKYCY1EF104ZY R 0.1 25V Ceramic AA
C1005 VCKYCY1HB103KY R 0.01 50V Ceramic AA
C1006 VCKYCY1EF104ZY R 0.1 25V Ceramic AA
C1007 VCKYCY1HB152KY R 1500p 50V Ceramic AA
C1008 VCKYCY1EF104ZY R 0.1 25V Ceramic AA
C1009 VCCCCY1HH100DY R 10p 50V Ceramic AA
C1010 VCKYCY1EF104ZY R 0.1 25V Ceramic AA
C1011 VCCCCY1HH100DY R 10p 50V Ceramic AA
C1012 VCKYCY1EF104ZY R 0.1 25V Ceramic AA
C1014 VCKYCY1HB102KY R 1000p 50V Ceramic AA
C1017 VCKYCY1EF104ZY R 0.1 25V Ceramic AA
C1018 VCKYCY1EF104ZY R 0.1 25V Ceramic AA
C1019 VCKYCY1EF104ZY R 0.1 25V Ceramic AA
C1020 VCKYCY1EF104ZY R 0.1 25V Ceramic AA
C1021 VCKYCY1HB102KY R 1000p 50V Ceramic AA
C1032 VCKYCY1EF104ZY R 0.1 25V Ceramic AA
C1033 VCKYCY1EF104ZY R 0.1 25V Ceramic AA
C1034 VCKYCY1EF104ZY R 0.1 25V Ceramic AA
C1035 VCKYCY1EF104ZY R 0.1 25V Ceramic AA
C1036 VCKYCY1EF104ZY R 0.1 25V Ceramic AA
C1037 VCKYCY1EF104ZY R 0.1 25V Ceramic AA
C1038 VCKYCY1EF104ZY R 0.1 25V Ceramic AA
C1039 VCKYCY1EF104ZY R 0.1 25V Ceramic AA
C1040 VCKYCY1EF104ZY R 0.1 25V Ceramic AA
C1041 VCKYCY1EF104ZY R 0.1 25V Ceramic AA
C1044 VCCCCY1HH470JY R 47p 50V Ceramic AA
C1045 VCCCCY1HH470JY R 47p 50V Ceramic AA
C1050 VCKYCY1EF104ZY R 0.1 25V Ceramic AA
C1503 VCKYCY1CF104ZY R 0.1 16V Ceramic AA
C1504 VCKYCY1CF104ZY R 0.1 16V Ceramic AA
C1505 VCKYCY1CF104ZY R 0.1 16V Ceramic AA
C1506 VCKYCY1CF104ZY R 0.1 16V Ceramic AA
C1801 VCKYCY1CF104ZY R 0.1 16V Ceramic AA
C1802 VCAAPE1CJ686MY R 68 16V Electrolytic AE
C1803 RC-KZA154WJZZY R 4.7 16V Ceramic AB
C1804 VCKYCY1EB103KY R 0.01 25V Ceramic AA
C1805 VCKYCY1HB221KY R 220p 50V Ceramic AA
C1806 RC-KZA154WJZZY R 4.7 16V Ceramic AB
C1807 RC-KZA185WJZZY R 10 10V Ceramic AC
C1808 VCKYCY1AB105KY R 1 10V Ceramic AB
C1809 RC-KZA154WJZZY R 4.7 16V Ceramic AB
C1810 VCKYTV1CB105KY R 1 16V Ceramic AC
C1811 RC-KZA154WJZZY R 4.7 16V Ceramic AB
C1812 RC-KZA185WJZZY R 10 10V Ceramic AC
C1813 VCKYCY1EB103KY R 0.01 25V Ceramic AA
C1814 VCAAPE1AJ127MY R 120 10V Electrolytic AE
C1815 VCKYCY1HB471KY R 470p 50V Ceramic AA
C1816 VCKYCY1EB103KY R 0.01 25V Ceramic AA
C1817 RC-KZA067WJZZY R 4.7 10V Ceramic AB
C1818 RC-KZA154WJZZY R 4.7 16V Ceramic AB
C1819 VCKYCY1HB473KY R 0.047 50V Ceramic AA
C1820 VCKYCY1HB222KY R 2200p 50V Ceramic AA
C1821 VCAAPE1AJ127MY R 120 10V Electrolytic AE
C1822 RC-KZA154WJZZY R 4.7 16V Ceramic AB
C1823 VCKYTV1CB105KY R 1 16V Ceramic AC
C1824 VCKYCY1EB104KY R 0.1 25V Ceramic AB
C1825 VCKYCY1EB103KY R 0.01 25V Ceramic AA
C1826 RC-KZA185WJZZY R 10 10V Ceramic AC
C1827 RC-KZA185WJZZY R 10 10V Ceramic AC
C1828 VCERML1CN107MY R 100 16V AC
C1830 VCKYCY1AB105KY R 1 10V Ceramic AB
C1831 RC-KZA067WJZZY R 4.7 10V Ceramic AB
C1833 VCKYCY1EB103KY R 0.01 25V Ceramic AA
