Sharp LC-26DA5U Service Manual

Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
LC-26DA5U
LC-32DA5U
96
R714 VRS-TS2AD100J J 10 Resistor(CHIP) AA
(LC-32DA5U)
R715 VRS-TP2BD120J J 12 Resistor(CHIP) AA
(LC-32DA5U)
R716 VRS-TS2AD183J J 18k Resistor(CHIP) AA
(LC-32DA5U)
R717 VRS-TS2AD101J J 100 Resistor(CHIP) AA
(LC-32DA5U)
R718 RR-HRNMR15J2C J 0.15 2W Resistor AD
R719 RR-HRNMR15J2C J 0.15 2W Resistor AD
R720 VRS-TS2AD183J J 18k Resistor(CHIP) AA
R721 VRS-TS2AD100J J 10 Resistor(CHIP) AA
R722 VRS-TP2BD120J J 12
Resistor(CHIP) AA
R723 VRS-TS2AD101J J 100 Resistor(CHIP) AA
R724 VRS-TS2AD103J J 10k Resistor(CHIP) AA
R725 VRS-TS2AD510J J 51 Resistor(CHIP) AA
R726 VRS-TS2AD102J J 1k Resistor(CHIP) AA
R727 VRS-TS2AD101J J 100 Resistor(CHIP) AA
R728 VRS-TS2AD202J J 2k Resistor(CHIP) AB
R729 RR-RVC32754F1 J 750kF400V Resistor(CHIP) AC
R730 RR-RVC32824F1 J 820kF400V Resistor(CHIP) AC
R731 VRS-TS2AD103F J 10kF Resistor(CHIP) AA
R732 RR-RVC32824F1 J 820kF400V Resistor(CHIP) AC
R733 RR-RVC32105F1 J 1MF 400V Resistor(CHIP) AC
R734 VRS-TS2AD103F J 10kF Resistor(CHIP) AA
R735 VRS-TS2AD103J J 10k Resistor(CHIP) AA
R736 VRS-TP2BD331J J 330 Resistor(CHIP) AA
R737 RR-HRSM1R5J3W J 1.5 3W Resistor(CHIP) AD
(LC-32DA5U)
R738 VRS-TS2AD333J J 33k Resistor(CHIP) AB
R739 VRS-TS2AD223J J 22k Resistor(CHIP) AA
R740 VRS-TS2AD122J J 1.2k Resistor(CHIP) AA
R741 VRS-TS2AD102J J 1k Resistor(CHIP) AA
R742 VRS-TP2BD334J J 330k Resistor(CHIP) AA
R743 VRS-TP2BD334J J 330k Resistor(CHIP) AA
R744 VRS-TP2BD334J J 330k Resistor(CHIP) AA
R745 VRS-TS2AD102J J 1k Resistor(CHIP) AA
R746 VRS-TP2BD184J J 180k Resistor(CHIP) AA
R747 VRS-TP2BD184J J 180k Resistor(CHIP) AA
R748 VRS-TP2BD184J J 180k Resistor(CHIP) AA
R749 VRS-TP2BD221J J 220 Resistor(CHIP) AA
R750 VRS-TP2BD221J J 220 Resistor(CHIP) AA
R751 VRS-TP2BD102J J 1k Resistor(CHIP) AA
R752 VRS-TP2BD272J J 2.7k Resistor(CHIP) AA
(LC-26DA5U)
R752 VRS-TP2BD182J J 1.8k Resistor(CHIP) AA
(LC-32DA5U)
R753 VRS-TS2AD101J J 100 Resistor(CHIP) AA
R754 VRS-TS2AD151J J 150 Resistor(CHIP) AA
R755 VRS-TS2AD223J J 22k Resistor(CHIP) AA
R756 VRS-TS2AD101J J 100 Resistor(CHIP) AA
R757 VRS-TS2AD101J J 100 Resistor(CHIP) AA
R758 VRS-TS2AD221J J 220 Resistor(CHIP) AA
R759 VRS-TS2AD104J J 100k Resistor(CHIP) AA
R760 VRS-TS2AD223J J 22k Resistor(CHIP) AA
R761 VRS-TS2AD562J J 5.6k Resistor(CHIP) AA
R762 VRS-TS2AD223J J 22k Resistor(CHIP) AA
R763 VRS-TS2AD101J J 100 Resistor(CHIP) AA
R764 VRS-TS2AD103J J 10k Resistor(CHIP) AA
R765 VRS-TP2BD331J J 330 Resistor(CHIP) AA
R766 VRS-TP2BD334J J 330k Resistor(CHIP) AA
R767 VRS-TP2BD334J J 330k Resistor(CHIP) AA
R768 VRS-TP2BD334J J 330k Resistor(CHIP) AA
R769 VRS-TP2BD184J J 180k Resistor(CHIP) AA
R770 VRS-TP2BD184J J 180k Resistor(CHIP) AA
R771 VRS-TP2BD184J J 180k Resistor(CHIP) AA
R772 RR-HRSM1R5J3W J 1.5 3W Resistor AD
R773 VRS-TS2AD102J J 1k Resistor(CHIP) AA
R774 VRS-TS2AD223J J 22k Resistor(CHIP) AA
R775 VRS-TS2AD102J J 1k Resistor(CHIP) AA
R776 VRS-TS2AD181J J 180 Resistor(CHIP) AA
R777 VRS-TS2AD333J J 33k
Resistor(CHIP) AB
R778 VRS-TP2BD221J J 220 Resistor(CHIP) AA
R779 VRS-TP2BD221J J 220 Resistor(CHIP) AA
R780 VRS-TP2BD821J J 820 Resistor(CHIP) AA
R781 VRS-TP2BD102J J 1k Resistor(CHIP) AA
R782 VRS-TS2AD101J J 100 Resistor(CHIP) AA
R783 VRS-TS2AD151J J 150 Resistor(CHIP) AA
R784 VRS-TS2AD223J J 22k Resistor(CHIP) AA
R785 VRS-TS2AD273J J 27k Resistor(CHIP) AA
R787 VRS-TS2AD222J J 2.2k Resistor(CHIP) AA
R789 VRS-TP2BD3R3J J 3.3 Resistor(CHIP) AA
R790 VRS-TP2BD274J J 270k Resistor(CHIP) AA
R791 VRS-TP2BD274J J 270k Resistor(CHIP) AA
R792 VRS-TS2AD223J J 22k Resistor(CHIP) AA
R793 VRS-TP2BD3R3J J 3.3 Resistor(CHIP) AA
R794 RR-HRSM1R5J3W J 1.5 3W Resistor AD
R796 VRS-RE3DA100J J 10 2W Resistor AC
R801 VRS-TP2BD332J J 3.3k Resistor(CHIP) AA
R802 VRS-TS2AD132J J 1.3k Resistor(CHIP) AA
R803 VRS-TS2AD103J J 10k Resistor(CHIP) AA
R804 VRS-TP2BD332J J 3.3k Resistor(CHIP) AA
R805 VRS-TS2AD103J J 10k Resistor(CHIP) AA
R806 VRS-TS2AD821J J 820 Resistor(CHIP) AA
R808 VRS-TS2AD222J J 2.2k Resistor(CHIP) AA
R809 VRS-TS2AD333J J 33k
Resistor(CHIP) AB
R810 VRS-TS2AD471J J 470 Resistor(CHIP) AA
R811 VRS-TS2AD103J J 10k Resistor(CHIP) AA
R812 VRS-TS2AD221J J 220 Resistor(CHIP) AA
R814 VRS-TS2AD102J J 1K Resistor(CHIP) AA
R815 VRS-TS2AD000J J 0 Resistor(CHIP) AB
R816 VRS-TS2AD123F J 12kF Resistor(CHIP) AA
R817 VRS-TS2AD391F J 390F Resistor(CHIP) AA
R818 VRS-TS2AD102F J 1kF Resistor(CHIP) AA
R819 VRS-TS2AD333J J 33k Resistor(CHIP) AB
R820 VRS-TS2AD330J J 33 Resistor(CHIP) AB
R821 VRS-TS2AD133F J 13kF Resistor(CHIP) AA
R822 VRS-TS2AD752F J 7.5kF Resistor(CHIP) AA
R823 VRS-TS2AD471J J 470 Resistor(CHIP) AA
R824 VRS-TS2AD472J J 4.7k Resistor(CHIP) AA
R825 VRS-TS2AD472J J 4.7k Resistor(CHIP) AA
R826 VRS-TS2AD333J J 33k Resistor(CHIP) AB
R827 VRS-TS2AD330J J 33 Resistor(CHIP) AB
R828 VRS-TS2AD393F J 39kF Resistor(CHIP) AA
R829 VRS-TS2AD103F J 10kF Resistor(CHIP) AA
R830 VRS-TS2AD471J J 470 Resistor(CHIP) AA
R831 VRS-TP2BD393J J 39k Resistor(CHIP) AA
R832 VRS-TP2BD393J J 39k Resistor(CHIP) AA
R833 VRS-TS2AD471J J 470 Resistor(CHIP) AA
R834 VRS-TS2AD471J J 470 Resistor(CHIP) AA
R835 VRS-TP2BD152J J 1.5k Resistor(CHIP) AA
R836 VRS-TS2AD132J J 1.3k Resistor(CHIP) AA
R837 VRS-TS2AD103J J 10k Resistor(CHIP) AA
R838 VRS-TS2AD103J J 10k Resistor(CHIP) AA
R839 VRS-TS2AD102J J 1k Resistor(CHIP) AA
R840 VRS-TS2AD821J J 820 Resistor(CHIP) AA
R841 VRS-TS2AD223J J 22k Resistor(CHIP) AA
R843 VRS-TS2AD222J J 2.2k Resistor(CHIP) AA
R844 VRS-TS2AD471J J 470 Resistor(CHIP) AA
R845 VRS-TS2AD221J J 220 Resistor(CHIP) AA
R846 VRS-TS2AD102J J 1k Resistor(CHIP) AA
R847 VRS-TS2AD101J J 100 Resistor(CHIP) AA
R848 VRS-TS2AD103J J 10k Resistor(CHIP) AA
R849 VRS-TS2AD622F J 6.2kF Resistor(CHIP) AA
R850 VRS-TS2AD000J J 0 Resistor(CHIP) AB
R851 VRS-TS2AD202F J 2KF Resistor(CHIP) AA
R852 VRS-TS2AD472J J 4.7k Resistor(CHIP) AA
R853 VRS-TS2AD472J J 4.7k Resistor(CHIP) AA
R854 VRS-TS2AD472J 4.7k Resistor(CHIP) AA
R855 VRS-TS2AD472J J 4.7k Resistor(CHIP) AA
R856 VRS-TS2AD472J 4.7k Resistor(CHIP) AA
R857 VRS-TS2AD472J J 4.7k Resistor(CHIP) AA
R858 VRS-TS2AD333J J 33k Resistor(CHIP) AB
R859 VRS-TS2AD330J J 33 Resistor(CHIP) AB
R860 VRS-TS2AD283F J 28kF Resistor(CHIP) AA
R861 VRS-TS2AD912F J 9.1kF Resistor(CHIP) AA
R862 VRS-TS2AD471J J 470 Resistor(CHIP) AA
RDENCA138WJQZ (LC-26DA5U)
RDENCA139WJQZ (LC-32DA5U)
POWER SUPPLY Unit (Continued)
