Using external equipment
DVD player/Digital TV STB
Connecting a DVD player or Digital TV STB
You can use the INPUT 1 to INPUT 4 terminals when connecting to a DVD player, Digital TV STB and other
audiovisual equipment.
NOTE
• For connecting a DVD player or Digital TV STB to HDMI ter minal.
AV cable
(commercially
available)
DVD player/Digital TV STB
When using component cable. (INPUT 1 or 2) When using composite cable. (INPUT 1, 2 or 3)
Component
video cable
(commercially
available)
Audio cable
(commercially
available)
VCR/Game console/
Camcorder
AV cable
(commercially
available)
Connecting a VCR, game console or camcorder
A VCR, game console, camcorder and some other audiovisual equipment are conveniently connected using
the INPUT 1 to 3 terminals.
S-video cable
(commercially
available)
NOTE
• The S-video terminal has priority over the video terminals. (INPUT 3 only)
NOTE
•When attempting to record copy protected material on a VCR or other recording device, the copy protection will activate
and the protected material will not be recorded correctly. In addition, attempting to display copy protected material on a
monitor connected via a VCR, whether for the purpose of viewing or not, will cause an inferior quality picture to be
displayed. This is not a fault of the equipment. Please view copy protected material by connecting the product directly to
the monitor.
Using external equipment
Connecting HDMI equipment
You can use the INPUT 4 terminal when connecting an HDMI equipment.
HDMI equipment
HDMI cable (commercially available)
Displaying an image from HDMI equipment
To watch an HDMI equipment image, select
“INPUT4” from “INPUT SOURCE” menu
using INPUT on the remote control unit or
on the TV.
INPUT SOURCE
TV
INPUT1
INPUT2
INPUT3
INPUT4
1
Press MENU and the MENU screen displays.
2
3
Press '/" to select “HDMI Setup”, and then
press ENTER.
4
Press \ /| to select “Option”.
MENU
[
Option
...
HDMI Setup
]
Option
Digital Noise Reduction
Output Select
Audio Only
Quick Shoot
[Fixed]
HDMI Setup
[Low]
[Off]
5
Press '/" to select the desired item and
press ENTER.
Press '/"/\ /| to select the desired setting
and press ENTER.
6
NOTE
•Refer to your external equipment operation manual for
the signal type.
Selectable items
RGB/YCbCr 4:4:4/
YCbCr 4:2:2
ITU601/ITU709
Standard/
Out of standard
Enable/Disable
Digital/Analog
HDMI Setup
items
Signal
Type
Color
Matrix
Dynamic
Range
Auto View
Audio
Select
Description
Select the video signal
type from the HDMI
terminal.
Select the internal color
space conversion method
when an RGB signal is
input.
Select the signal amplitude
range. Usually, select
“Standard”.
Set whether or not to use
VIEW MODE based on
signal recognition,
including an HDMI signal.
Select “Digital” for audio
signal via the HDMI
terminal. Select “Analog”
for audio signal via the R-
AUDIO -L terminal.
When using an HDMI-DVI
conversion cable, input the
audio signal to AUDIO
terminal of INPUT4.
To Next Page
