Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
LC-26DA5U
LC-32DA5U
100
CABINET AND MECHANICAL PARTS
(LC-32DA5U)
1 CCABAB082WJ01 X Front Cabinet Ass'y BP
1-1
Not Available
–Front Cabinet —
1-2 HBDGBA015WJSA X Badge, SHARP AK
1-3 HDECQA346WJSA X R/C, LED Decoration Cover AE
1-4 PSPAHA298WJZZ X Mask Spacer, x2 AC
1-5 PSPAHA407WJZZ X Mask Spacer, x2 AD
1-6 TLABZA635WJZZ X Energy Star Label AD
1-7 TLABZB030WJSA X HDMI Label AD
2 CCABBA562WJ02 X Rear Cabinet Ass'y BQ
2-1
Not Available
– Rear Cabinet —
2-2 HiNDPB369WJSA X AV Jack Indicator B AH
2-3 HiNDPB388WJSA X AV Jack Indicator A AM
2-4 HiNDPB449WJSA X AC Input Indicator AF
2-5 LHLDWA055WJKZ X Wire Holder, x2 AC
2-6 LHLDWA057WJKZ X Wire Holder AE
3 CCOVAB143WJ01 X Top Cover Ass'y AS
3-1
Not Available
–Top Cover —
3-2 JBTN-A428WJKA X Operation Button AF
3-3 JBTN-A429WJKA X Power Button AD
3-4 MSPRCA049WJFW X Power Button Spring AD
4
Not Available
– Stand Ass'y —
4-1 CANGTA257WJ02 X Stand Bracket Ass'y BL
4-1-1
Not Available
– Stand Support —
4-1-2
Not Available
– Stand Bracket —
4-1-3
Not Available
– Screw, x4 —
4-2 CDAi-A218WJ03 X Stand Base Ass'y BL
4-2-1
Not Available
– Stand Base —
4-2-2
Not Available
– Stand Base Bracket —
4-2-3
Not Available
– LEG-Cushion-B, x2 —
4-2-4
Not Available
– LEG-Cushion-C, x4 —
4-2-5
Not Available
– LEG-Cushion-A, x2 —
4-2-6
Not Available
– Screw, x11 —
4-3 XCBS950P25000 X Screw, x5 (for STAND) AB
5 RLCUCA025WJZZ J 32" LCD Module DZ
6 DUNTKD352WE02 R AV Unit CA
7 DUNTKD353WE01 R KEY Unit AK
8 DUNTKD354WE01 R R/C, LED Unit AN
9 DUNTKD375FM02 R MAIN Unit CB
10 RDENCA139WJQZ X POWER SUPPLY Unit BX
11 GCOVAB111WJKA X Bracket Cover AP
12 GCOVAB178WJKA X Terminal Cover AY
13 GCOVAB348WJKA X Jack Cover B AG
14 GCOVAB355WJKA X Jack Cover A AK
15 GCOVAB356WJKA X Jack Cover C AK
16 HiNDPB383WJSA X Model Label AH
17 LANGTA197WJZZ X Center Angle BB
18 LHLDWA044WJKZ X Wire Holder AB
19 LHLDWA058WJKZ X
Wire Holder, x2 (FOR SLD A)
AC
20 LHLDWA096WJKZ X Edge Saddle AD
21 LHLDWA116WJZZ X Wire Clamp AD
22 NSFTZA144WJFN X PWB Shaft AD
23 PCOVUA080WJZZ X LED Shading Cover AD
24 PMLT-A240WJZZ X Absorber AM
25 PMLT-A241WJZZ X Absorber AE
26 PMLT-A242WJZZ X Absorber AD
27 PMLT-A243WJZZ X Absorber AF
28 PMLT-A244WJZZ X Absorber AE
29 PMLT-A263WJZZ X Gasket AM
30 PRDARA191WJFW X Heat Sink IC2502 AE
31 PRDARA192WJFW X Heat Sink IC3800 AE
32 PRDARA216WJFW X Heat Sink IC2502 B SIDE AF
33 PSLDMA777WJZZ X MAIN Shield A AM
34 PSLDMA778WJZZ X MAIN Shield B AM
35 PSLDMA779WJFW X MAIN Shield C AK
36 PSLDMA835WJFW X LCD Control Shield AK
37 PSLDMA838WJZZ X
Conduct Cloth MAINSLD20*40
AD
38 PSLDMA839WJZZ X
Conduct Cloth MAINSLD20*45
AE
39 PSLDMA840WJZZ X
Conduct Cloth MAINSLD10*50
AD
40 PSLDMA841WJZZ X Conduct Cloth, x3 WIRE*3 AE
41 PSPAZA635WJKZ X Cooling Sheet (for IC2502) AD
42 PSPAZA636WJKZ X Cooling Sheet (for IC3800) AD
43 PSPAZA663WJKZ X Cooling Sheet, x2 AE
(IC2502/IC3301)
44 PSPAZA939WJZZ X Gasket, x2 SPACER AC
45 QCNW-D079WJQZ X Connecting Cord AK
(SP:AV-SP)
46 QCNW-D081WJQZ X Connecting Cord AK
(RA:AV-LED)
47 QCNW-D766WJQZ X Connecting Cord AG
(FC:AV-MAIN(60p))
48 QCNW-D769WJQZ X Connecting Cord AH
(SH:MAIN-CONT)
49 QCNW-D775WJQZ X Connecting Cord BB
(LV:MAIN-CONT)
50 QCNW-D776WJQZ X Connecting Cord AH
(KM:KEY-MAIN)
51 QCNW-D779WJQZ X Connecting Cord AL
(PA:AV-POWER)
52 QCNW-D782WJQZ X Connecting Cord AL
(PG2/PG:POW-INV)
53 QCNW-D784WJQZ X Connecting Cord AH
(PG1:POW-INV)
54 QCNW-E100WJQZ X Connecting Cord AH
(FD:AV-MAIN)
55 QCNW-E165WJQZ X Connecting Cord AH
(MI:MAIN-INV)
56 QCNW-E166WJQZ X Connecting Cord AP
(PE-P/PD:MAIN-POW)
57 QEARPA172WJFW X Earth Spring C AC
58 RSP-ZA106WJZZ X Speaker-L AX
59 RSP-ZA107WJZZ X Speaker-R AX
60 XBBS740P06000 X
Screw, x7 (FOR CENTER ANG)
AA
61 XBBS930P06000 X Screw, x13 (AC-ANG HDMI) AA
62 XBBS940P10000 X
Screw, x1 (FOR STAND COV)
AB
63 XBBSN50P12JS0 X Screw, x4 (FOR STAND) AB
64 XBPS730P06WS0 X Screw, x25 (FOR PWB) AB
65 XEBS930P08000 X Screw, x7 (TANSHI YO) AA
66 XEBS940P16000 X Screw, x19 (CAB B) AA
67 XEBSN30P10000 X Screw, x11 (FOR OPE) AA
68 NSFTZ0134CEFW R Shaft Nut, x2 (for RS232C) AD
69 PSLDMA602WJFW R HDMI Shield Bottom AG
70 PSLDMA865WJFW R HDMI Shield Top_2 AE
71
Not Available
–No. Label —
72 PSPAZA660WJKZ X Cooling Sheet AC
73 PSPAZA818WJKZ X Cooling Sheet
To Next Page
