Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
206
LC-30HV4E
DUNTKB401FE05
MAIN Unit (AVC System) (Continued)
Q830 VS2SC3928AR-1Y J 2SC3928AR AB
Q837 VS2SC3928AR-1Y J 2SC3928AR AB
Q838 VS2SA1530AR-1Y J 2SA1530AR AB
Q839 VS2SC2735//1EY J 2SC2735 AC
Q840 VS2SC2735//1EY J 2SC2735 AC
Q841 VS2SC2735//1EY J 2SC2735 AC
Q842 VS2SC3928AR-1Y J 2SC3928AR AB
Q844 VS2SC3928AR-1Y J 2SC3928AR AB
Q901 VS2SA1530AR-1Y J 2SA1530AR AB
Q902 VS2SA1530AR-1Y J 2SA1530AR AB
Q903 VS2SA1530AR-1Y J 2SA1530AR AB
Q904 VS2SA1530AR-1Y J 2SA1530AR AB
Q905 VS2SA1530AR-1Y J 2SA1530AR AB
Q906 VS2SA1530AR-1Y J 2SA1530AR AB
Q1502 VSDTC144EE/-1Y J DTC144EE AA
Q1503 VS2SB1132Q/-1Y J 2SB1132Q AC
Q1504 VS2SC3928AR-1Y J 2SC3928AR AB
Q1507 VSDTC144EE/-1Y J DTC144EE AA
Q1508 VSiMD2A////-1Y J IMD2A//// AC
Q1512 VSiMD2A////-1Y J IMD2A//// AC
Q1801 VS2SB1132Q/-1Y J 2SB1132Q AC
Q1802 VSDTC124EKA-1Y J DTC124EKA AB
Q7201 VS2SC3928AR-1Y J 2SC3928AR AB
Q7206 VS2SC3928AR-1Y J 2SC3928AR AB
DIODES
D801 VHDDAN222//-1Y J Diode AA
D1502 VHDDAN222//-1Y J Diode AA
D1503 VHDDAN222//-1Y J Diode AA
D1505 VHD1SS355//-1Y J Diode AB
D1802 VHDHSU119//-1Y J Diode AB
D7201 VHD1SS355//-1Y J Diode AB
D7202 VHD1SS355//-1Y J Diode AB
PACKAGED CIRCUITS
X601 RFiLA0034CEZZ J Filter AD
X801 RCRSB0244CEZZ+ J Crystal AF
X802 RCRSB0244CEZZ+ J Crystal AF
X1901 RCRSZ0093CEZZY J Crystal AM
FILTERS AND COILS
CF7201 RFiLA0098CEZZ+ J Ceramic Filter AD
FL810 RFiLZA005WJZZQ J Filter AT
L403 VPD9M4R7MR53NY J Peaking 4.7µH AB
L404 VPD9M220J2R7NY J Peaking 22µH AC
L406 VPD9M4R7MR53NY J Peaking 4.7µH AB
L407 VPD9M220J2R7NY J Peaking 22µH AC
L408 VPD9M270J3R2NY J Peaking 27µH AB
L410 VPD9M4R7MR53NY J Peaking 4.7µH AB
L603 VPD9M470J6R6NY J Peaking 47µH AC
L604 VPD9M6R8J1R8NY J Peaking 6.8µH AC
L605 VPD9M5R6J1R6NY J Peaking 5.6µH AB
L606 VPD9M8R2J2R0NY J Peaking 8.2µH AC
L607 VPD9M470J6R6NY J Peaking 47µH AC
L608 VPD9M3R9J1R3NY J Peaking 3.9µH AB
L609 VPD9M1R8JR84NY J Peaking 1.8µH AC
L610 VPD9M3R9J1R3NY J Peaking 3.9µH AB
L805 VPD9M2R2MR32NY J Peaking 2.2µH AB
L808 VPD9M220J2R7NY J Peaking 22µH AC
L809 VPD9M220J2R7NY J Peaking 22µH AC
L810 VPD9M220J2R7NY J Peaking 22µH AC
L901 VPD9M270J3R2NY J Peaking 27µH AB
CAPACITORS
C401 VCCCCY1HH120JY J 12p 50V Ceramic AA
C402 VCCCCY1HH100DY J 10p 50V Ceramic AA
C403 VCCCCY1HH120JY J 12p 50V Ceramic AA
C404 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C405 VCKYCY1HB103KY J 0.01 50V Ceramic AA
C406 VCKYCY1HB103KY J 0.01 50V Ceramic AA
C407 VCKYCY1HB103KY J 0.01 50V Ceramic AA
C408 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C409 VCKYCY1HB103KY J 0.01 50V Ceramic AA
C410 VCKYTV1CB474KY J 0.47 16V Ceramic AC
C411 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C412 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C413 VCKYCY1HB103KY J 0.01 50V Ceramic AA
C414 VCEAPF1CN107MY J 100 16V Electrolytic AD
C415 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C416 VCEAPF1CN476MY J 47 16V Electrolytic AD
C417 VCKYCY1HB103KY J 0.01 50V Ceramic AA
C418 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C419 VCKYCY1HB681KY J 680p 50V Ceramic AA
C420 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C421 VCKYCY1HB103KY J 0.01 50V Ceramic AA
C422 VCKYCY1HB103KY J 0.01 50V Ceramic AA
C423 VCEAPF1CN107MY J 100 16V Electrolytic AD
C424 VCKYCY1HB103KY J 0.01 50V Ceramic AA
C425 VCCCCY1HH120JY J 12p 50V Ceramic AA
C426 VCCCCY1HH100DY J 10p 50V Ceramic AA
C427 VCCCCY1HH120JY J 12p 50V Ceramic AA
C428 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C429 VCKYCY1HB103KY J 0.01 50V Ceramic AA
C430 VCKYCY1HB103KY J 0.01 50V Ceramic AA
C431 VCKYCY1HB103KY J 0.01 50V Ceramic AA
C432 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C433 VCKYCY1HB103KY J 0.01 50V Ceramic AA
C434 VCKYTV1CB474KY J 0.47 16V Ceramic AC
C435 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C436 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C437 VCKYCY1HB103KY J 0.01 50V Ceramic AA
C438 VCEAPF1CN107MY J 100 16V Electrolytic AD
C439 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C440 VCKYCY1HB103KY J 0.01 50V Ceramic AA
C441 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C442 VCKYCY1HB681KY J 680p 50V Ceramic AA
C443 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C444 VCKYCY1HB103KY J 0.01 50V Ceramic AA
C445 VCKYCY1HB103KY J 0.01 50V Ceramic AA
C446 VCCCCY1HH101JY J 100p 50V Ceramic AA
C447 VCCCCY1HH101JY J 100p 50V Ceramic AA
C448 VCKYTV1CB105KY J 1 16V Ceramic AC
C449 VCKYTV1EB104KY J 0.1 25V Ceramic AB
C451 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C452 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C453 VCKYTV1CB105KY J 1 16V Ceramic AC
C454 VCKYTV1EB104KY J 0.1 25V Ceramic AB
C455 VCEASH1CN107MY J 100 16V Electrolytic AC
C456 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C457 VCCCCY1HH270JY J 27p 50V Ceramic AA
C458 VCCCCY1HH560JY J 56p 50V Ceramic AB
C459 VCKYCY1CB104KY J 0.1 16V Ceramic AB
C460 VCEAPF1CN476MY J 47 16V Electrolytic AD
C601 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C614 VCKYTV1CB105KY J 1 16V Ceramic AC
C615 VCKYCY1HB103KY J 0.01 50V Ceramic AA
C616 VCKYTV1CB105KY J 1 16V Ceramic AC
C617 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C618 VCEASH1CN337MY J 330 16V Electrolytic AE
C619 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C620 VCEAPF1CN476MY J 47 16V Electrolytic AD
C621 VCCCCY1HH220JY J 22p 50V Ceramic AA
C622 VCEAPF1CN476MY J 47 16V Electrolytic AD
C623 VCEAPF1CN476MY J 47 16V Electrolytic AD
C646 RC-KZA051WJZZY J 4.7 6.3V Ceramic AC
C649 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C650 VCCCCY1HH151JY J 150p 50V Ceramic AA
C651 VCCCCY1HH121JY J 120p 50V Ceramic AA
C652 VCCCCY1HH271JY J 270p 50V Ceramic AA
C653 VCKYCY1HB103KY J 0.01 50V Ceramic AA
C654 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C656 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C657 VCCCCY1HH181JY J 180p 50V Ceramic AA
C658 VCCCCY1HH221JY J 220p 50V Ceramic AA
C659 VCCCCY1HH221JY J 220p 50V Ceramic AA
C660 VCKYCY1HB103KY J 0.01 50V Ceramic AA
C661 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
