Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
245
LC-30HV4E
CABINET AND MECHANICAL PARTS
(Display)
1 CCABAA214WJ01 J Front Cabinet Ass’yBE
1-1 Not Available – Front Cabinet —
1-2 GCOVA2064CESA J RC/LED Cover AF
1-3 HBDGBA015WJSA J Badge, "SHARP" AH
1-4 PSPAG0432CEUZ J Spacer, x2 AA
1-5 PSPAHA088WJZZ J Spacer, x2
1-6 PSPAHA089WJZZ J Spacer, x2 AD
2 CCABBA145WJ01 J Rear Cabinet Ass’yBM
(LC-30HV4E/E(K))
2 CCABB2357CE02 J Rear Cabinet Ass’yBM
(LC-30HV4E(R))
2-1 Not Available – Rear Cabinet —
2-2 HiNDP5733CESA J "AQUOS" Label AD
2-3 HiNDP5971CESA J Speaker Label, x2 AC
2-4 HiNDPA289WJSA J Model Label AH
2-5 PSPAZA043WJZZ J Coin Cover, x2 AB
2-6 TCAUZA008WJZZ J Caution Label AK
3 CCOVA2113CE02 J Top Cover Ass’yAS
3-1
Not Available – Top Cover —
3-2 GCOVAA259WJKA J Button Cover AE
3-3 JBTN-A097WJKA J Operation Button AL
3-4 XEBSD30P08000 J Screw, x2 AA
4 CDAi-0105WJ03 J Stand Ass’yBV
4-1 Not Available – Stand, Base —
4-2 GDAi-3056CESA J Stand, Joint AT
4-3 GDAi-A049WJSA J Stand, Pillar AU
4-4 LANGK0797CESA J Base Angle BB
4-5 LX-BZ3441CEFN J Screw, x1 AD
4-6 MHNG-3048CESA J Hinge Ass’yBR
4-7 PSPAZ0448CEZZ J Leg Cushion, x4 AD
4-8 PSPAZ0475CEZZ J Leg Cushion-A, x1 AE
4-9 PSPAZ0476CEZZ J Leg Cushion-B, x2 AD
4-10 TLABZ0793CESA J Identification Label AC
4-11 XCBSF50P25000 J Screw, x4 AC
4-12 XCSSN50P25000 J Screw, x4 AB
4-13 XEBSF40P10000 J Screw, x12 AB
4-14 XWHSF50-16120 J Washer, x4 AB
5 Not Available – 30" LCD Panel Unit Ass’y —
5-1 RLCDTA020WJZZ J 30" LCD Panel Unit FY
5-2 Not Available – Back Shield Ass’y —
5-2-1 PSLDMA126WJFW J Back Shield BC
5-2-2 PSPAZA003WJZZ J Spacer AC
5-2-3 PSPAZA045WJZZ J Spacer AB
5-2-4 PSPAZA110WJZZ J Spacer
5-2-5 PZETEA004WJKZ J Insulating Sheet
å 5-3 KLMP-0128CEZZ J Lamp Unit AZ
5-4 LHLDZA083WJKZ J Lamp Holder, x2 AM
5-5 LHLDZA084WJKZ J Lamp Holder, x2 AL
5-6 LHLDZA085WJZZ J Lamp Clip, x4 AE
5-7 MSPRP1220CEFW J ITO Earth Spring, x2 AC
5-8 PCOVU0109CEZZ J Diffusion Panel BA
5-9 PSHEP0298CEZZ J Deflection Sheet BY
5-10 PSHEP0299CEZZ J Prism Sheet BM
5-11 PSHEP0300CEZZ J Diffusion Sheet AS
5-12 PSHEP0301CEZZ J ITO Sheet BD
5-13 PSHEPA043WJZZ J Reflection Sheet-1 AX
5-14 PSHEPA044WJZZ J Reflection Sheet-2 AL
5-15 PSLDMA018WJZZ J Shield Tape AX
5-16 PSPAZ0462CEZZ J Insulating Spacer, x2 AC
5-17 QCNW-A480WJZZ J Connecting Cord, x2 AM
5-18 QCNW-A481WJZZ J Connecting Cord, x2 AM
5-19 QCNW-B287WJZZ J Connecting Cord AM
5-20 RCORFA007WJZZ J Core, x4 AK
5-21 XBBSD30P08000 J Screw, x6 AA
5-22 XBPSD30P08JS0 J Screw, x4 AA
5-23 XEBSD30P08000 J Screw, x2 AA
6 Not Available – Reinforcement Angle Ass’y —
6-1 LANGK0807CEFW J Reinforcement Angle AZ
6-2 PCOVNA001WJKZ J Fan Cover AF
6-3 PSPAZA062WJZZ J Spacer AD
6-4 XBPSF30P06JS0 J Screw, x4 AA
7 CPNLSA005WJ01 J Speaker Net, x2 AX
8 GCOVA2072CEKA J BAS Connector Cover AE
9 GCOVA2125CEKA J Terminal Cover AR
10 GCOVAA287WJKA J Chassis Frame AR
11 JBTN-A096WJKA J Power Button AH
12 LANGK0789CEFW J Reinforcement Angle AE
(Top), x4
13 LANGK0792CEFW J Speaker Angle, x4 AF
14 LHLDW1033CE00 J Wire Holder AA
15 LHLDWA005WJZZ J Core Holder, x1 AE
16 LHLDZ2199CEZZ J Power Button Holder AG
17 LHLDZA034WJZZ J BAS Connector Holder AF
18 LHLDZ2183CEZZ J PWB Holder, x2 AD
19 NFANR0126CEZZ J Cooling Fan AT
20 PFLT-A005WJZZ J Conductive Tape, x1 AG
21 PFLT-A006WJZZ J Conductive Spacer, x1 AK
22 PSLDMA019WJZZ J Conductive Sheet, x1 AD
23 PSPAG0234CE00 J Spacer, x4 AA
24 PSPAGA101WJZZ J Spacer, x1 AB
25 PSPAKA004WJZZ J Spacer, x2 AE
26 PSPAZA046WJZZ J Spacer, x1 AB
27 RSP-ZA031WJN1 J Speaker(L) BD
28 RSP-ZA031WJN2 J Speaker(R) BD
29 QCNW-A345WJZZ J Connecting Cord(MC) AD
30 QCNW-A353WJZZ J Connecting Cord AE
(SD-SL/SR)
31 QCNW-A354WJZZ J Connecting Cord(AA) AL
32 QCNW-A548WJZZ J Connecting Cord(GND) AH
33 QCNW-B225WJZZ J Connecting Cord AK
(PE-PG/PH)
34 QCNW-B286WJZZ J Connecting Cord(GND), x3 AH
35 QCNW-A184WJZZ J Connecting Cord(PC) AG
36 QCNW-A346WJZZ J Connecting Cord(KK) AD
37 QCNW-A347WJZZ J Connecting Cord(MD) AD
38 QCNW-A348WJZZ J Connecting Cord(PA) AG
39 QCNW-A349WJZZ J Connecting Cord(PB) AE
40 QCNW-A350WJZZ J Connecting Cord(RM) AH
41 QCNW-A351WJZZ J Connecting Cord(SA) AF
42 QCNW-A352WJZZ J Connecting Cord(SB) AH
43 QEARZA008WJZZ J Gasket, x2 AL
44 RCORFA008WJZZ J Core AH
45 RCORFA025WJZZ J Core AK
46 Not Available – Serial No. Label —
47 XBBSF30P04000 J Screw, x4 AA
48 XBBSF30P10000 J Screw, x2 AA
49 XBBSF40P14000 J Screw, x4 AB
50 XBBSF40P25000 J Screw, x4 AA
51 XBBSN40P10R00 J Screw, x6 AC
52 XBPSD30P08JS0 J Screw, x19 AA
53 XBPSD30P14JS0 J Screw, x2 AA
54 XBPSF30P06JS0 J Screw, x14 AA
55 XBPSN30P06JS0 J Screw, x4 AB
56 XBPSN30P12JS0 J Screw, x2 AB
57 XBPSN30P20XS0 J Screw, x2 AB
58 XEBSD30P06000 J Screw, x5 AA
59 XEBSD30P08000 J Screw, x24 AA
60 XEBSF30P10000 J Screw, x1 AA
61 XEBSF40P16000 J Screw, x11 AA
