Sharp LC-30HV4E - Parts List (Continued); Integrated Circuits (LCD CONTROL Unit); Transistors (LCD CONTROL Unit)

Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
226
LC-30HV4E
CPCi-A005WJ51
PC I/F Unit (AVC System) (Continued)
R11035 9DK001-50212 J 100k 1/16W Chip1608 AA
R11036 9DK001-50177 J 1k 1/16W Chip1608 AA
R11037 9DK001-50186 J 22k 1/16W Chip1608 AA
R11038 9DK001-50212 J 100k 1/16W Chip1608 AA
R11042 9DK001-50177 J 1k 1/16W Chip1608 AA
R11043 9DK001-50177 J 1k 1/16W Chip1608 AA
R11044 9DK001-50177 J 1k 1/16W Chip1608 AA
R11045 9DK001-50174 J 560 1/16W Chip1608 AA
R11048 9DK001-50161 J 47 1/16W Chip1608 AA
R11049 9DK001-50161 J 47 1/16W Chip1608 AA
R11050 9DK001-50161 J 47 1/16W Chip1608 AA
R11051 9DK001-50183 J 4.7k 1/16W Chip1608 AA
R11052 9DK001-50183 J 4.7k 1/16W Chip1608 AA
R11053 9DK001-50183 J 4.7k 1/16W Chip1608 AA
R11054 9DK001-50183 J 4.7k 1/16W Chip1608 AA
R11055 9DK001-50183 J 4.7k 1/16W Chip1608 AA
R11056 9DK001-50183 J 4.7k 1/16W Chip1608 AA
R11058 9DK001-50183 J 4.7k 1/16W Chip1608 AA
R11059 9DK001-50183 J 4.7k 1/16W Chip1608 AA
R11060 9DK001-50183 J 4.7k 1/16W Chip1608 AA
R11061 9DK001-50183 J 4.7k 1/16W Chip1608 AA
R11062 9DK001-50183 J 4.7k 1/16W Chip1608 AA
R11076 9DK001-51030 J 10k 1/16W
Resistor Array AD
R11077 9DK001-50282 J 220 1/16W Chip1608 AA
R11077 9DK001-50177 J 1k 1/16W Chip1608 AA
R11079 9DK001-51039 J 56 1/16W Resistor Array AD
R11080 9DK001-50149 J 0 1/16W Chip1608 AB
R11081 9DK001-50149 J 0 1/16W Chip1608 AB
R11081 9DK001-50149 J 0 1/16W Chip1608 AB
R11082 9DK001-50159 J 22 1/16W Chip1608 AA
R11083 9DK001-50177 J 1k 1/16W Chip1608 AA
R11084 9DK001-50185 J 10k 1/16W Chip1608 AA
R11085 9DK001-50185 J 10k 1/16W Chip1608 AA
R11089 9DK001-50165 J 100 1/16W Chip1608 AA
R11099 9DK001-50149 J 0 1/16W Chip1608 AB
R11101 9DK001-51039 J 56 1/16W Resistor Array AD
R11102 9DK001-51039 J 56 1/16W Resistor Array AD
R11104 9DK001-50165 J 100 1/16W Chip1608 AA
R11106 9DK001-50185 J 10k 1/16W Chip1608 AA
R11109 9DK001-50149 J 0 1/16W Chip1608 AB
R11110 9DK001-50183 J 4.7k 1/16W Chip1608 AA
R11126 9DK001-50088 J 10 1/4W Chip1608 AB
R11127 9DK001-50185 J 10k 1/16W Chip1608 AA
R11128 9DK001-50161 J 47 1/16W Chip1608 AA
R11129 9DK001-50185 J 10k 1/16W Chip1608 AA
R11130 9DK001-50185 J 10k 1/16W Chip1608 AA
R11131 9DK001-50185 J 10k 1/16W Chip1608 AA
R11132 9DK001-50165 J 100 1/16W Chip1608 AA
R11134 9DK001-50161 J 47 1/16W Chip1608 AA
R11135 9DK001-50185 J 10k 1/16W Chip1608 AA
R11201 9DK001-50165 J 100 1/16W Chip1608 AA
R11202 9DK001-50149 J 0 1/16W Chip1608 AB
MISCELLANEOUS PARTS
FB10016 9DK001-50110 J 0 1/10W Chip2125 AB
FB10018 9DK001-50110 J 0 1/10W Chip2125 AB
FB10019 9DK001-50110 J 0 1/10W Chip2125 AB
FB10050 9DK001-81060 J Ferrite Bead AF
FB10051 9DK001-81060 J Ferrite Bead AF
FB10052 9DK001-81060 J Ferrite Bead AF
FB10053 9DK001-81060 J Ferrite Bead AF
S10001 9DK001-70012 J SSSS812-B-2B AL
CN10003 9DK001-60078 J DVI Connector AQ
CN10008 9DK001-60070 J Connector, 12pin AH
CN10009 9DK001-60071 J Connector, 13pin AH
CN10001 9DK001-60074 J Connector, 15pin AL
CN10005 9DK001-60066 J D-Sub, 9pin AT
CN10006 9DK001-60067 J Connector, 30pin AK
CN10007 9DK001-60058 J Connector, 50pin AS
TP10004 9DK001-84014 J Lug AE
DKEYHB157FE14
MAIN Unit (Display)
INTEGRATED CIRCUITS
IC2001 RH-iXA541WJN2Q J M30621FCAGP BD
IC2002 VHiPST529DM-1Y J PST529DMT AE
IC2003 VHiBR24C08F-1Y J BR24C08F-E2 AF
IC2005 VHiNJM2904M-1Y J NJM2904M AE
IC2006 VHiNJM2904M-1Y J NJM2904M AE
IC2007 VHiTC4066BF1EY J TC4066BF AE
IC2101 VHiAN8005M/-1Y J AN8005M AD
IC2102 VHiPQ20WZ11-1Y J PQ20WZ1U AF
IC2104 VHiPQ1CZ21H-1Y J PQ1CZ21H2ZP AH
IC2105 VHiPQ1CZ21H-1Y J PQ1CZ21H2ZP AH
IC2203 VHiHN24128F-1Y J HN58X24128FPI AP
IC2204 VHi24LC21++8EY J 24LC21
IC2205 VHiTC7W34U/-1Y J TC7W34FU AE
Note: When replace the following parts, PWB replacement
correspondence.
IC2201 — – Receiver —
IC2202 — – HDCP KEY —
TRANSISTORS
Q2003 VS2SC3928AR-1Y J 2SC3928AR AB
Q2004 VSNDS355AN/-1Y J NDS355AN AE
Q2005 VSNDS355AN/-1Y J NDS355AN AE
Q2006 VS2SA1530AR-1Y J 2SA1530AR AB
Q2007 VSDTC114EE/-1Y J DTC114EE AB
Q2008 VSDTA114EE/-1Y J DTA114EE AB
Q2013 VSDTC114EE/-1Y J DTC114EE AB
Q2014 VSDTA114EE/-1Y J DTA114EE AB
Q2015 VSDTC114EE/-1Y J DTC114EE AB
Q2101 VSDTA114EE/-1Y J DTA114EE AB
Q2102 VSDTC114EE/-1Y J DTC114EE AB
Q2103 VSDTA114EE/-1Y J DTA114EE AB
Q2104 VSDTC114EE/-1Y J DTC114EE AB
Q2105 VS2SC3928AR-1Y J 2SC3928AR AB
Q2106 VS2SC3928AR-1Y J 2SC3928AR AB
Q2203 VSNDS355AN/-1Y J NDS355AN AE
Q2204 VSNDS355AN/-1Y J NDS355AN AE
Q2205 VSDTA114EE/-1Y J DTA114EE AB
Q2206 VSDTC114EE/-1Y J DTC114EE AB
Q2207 VS2SA1530AR-1Y J 2SA1530AR AB
Q2208 VSDTC114EE/-1Y J DTC114EE AB
Q2209 VSDTC114EE/-1Y J DTC114EE AB
Q2210 VS2SA1530AR-1Y J 2SA1530AR AB
Q2211 VSDTC114EE/-1Y J DTC114EE AB
Q2212 VSDTA114EE/-1Y J DTA114EE AB
Q2213 VSDTC114EE/-1Y J DTC114EE AB
Q2214 VSDTA114EE/-1Y J DTA114EE AB
Q2215 VSDTC114EE/-1Y J DTC114EE AB
Q2216 VSDTA114EE/-1Y J DTA114EE AB
DIODES
D2001 RH-EX1249CEZZY J Zener Diode, 6.2V AB
D2002 RH-EX1249CEZZY J Zener Diode, 6.2V AB
D2003 RH-EX1249CEZZY J Zener Diode, 6.2V AB
D2004 RH-EX1249CEZZY J Zener Diode, 6.2V AB
D2101 VHDHSU119//-1Y J Diode AB
D2103 VHDSFPB74//2EY J Diode AD
D2104 VHDSFPB74//2EY J Diode AD
D2201 VHDDA221///-1Y J Diode AB
D2202 VHDDAN222//-1Y J Diode AA
D2203 VHDDA221///-1Y J Diode AB
D2204 VHDHSU119//-1Y J Diode AB
D2210 VHDHSU119//-1Y J Diode AB
TH2001 VHHM1103J03-1Y J Thermistor AC
PACKAGED CIRCUITS
X2201 RCRSZ0093CEZZY J Crystal AM
FILTERS AND COILS
CF2001 RFiLZ0169TAZZY J Ceramic Filter AD
FL2201 RFiLNA022WJZZY J Filter AE
