Sharp LC-30HV4E - Cabinet and Mechanical Parts (Continued); (Display) Parts List

Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
243
LC-30HV4E
CABINET AND MECHANICAL PARTS
(AVC System)
1 Not Available – Rear Panel Ass’y —
1-1 LANGTA037WJFW J Rear Panel AM
1-2 HiNDPA279WJSA J Indication Label AP
2 CCABAA289WJ01 J Chassis Flame Ass’yBB
2-1 Not Available – Chassis Flame —
2-2 LANGTA027WJFW J Stand Angle AG
2-3 LHLDW1021GE00 J Wire Holder, x2 AB
2-4 LHLDW1139CEZZ J Wire Holder, x1 AA
2-5 PZETZA008WJZZ J Insulating Sheet AK
2-6 QEARZA020WJFW J Earth Spring, x2 AC
2-7 XJPSN30P08XS0 J Screw, x2 AA
3 CCABBA111WJ01 J Bottom Cabinet Ass’yAY
3-1 Not Available – Bottom Cabinet —
3-2 GLEGGA012WJZZ J Leg, x4 AD
4 CCABBA170WJ01 J Top Cabinet Ass’yAY
4-1
Not Available – Top Cabinet —
4-2 TCAUHA049WJZZ J Caution Label AD
5 Not Available – PC I/F Bottom Shield Ass’y —
5-1 LANGTA023WJFW J PC I/F Bottom Shield AP
5-2 LHLDW1021GE00 J Wire Holder, x1 AB
5-3 PFLT-A004WJZZ J Spacer, x1 AE
6 CPNLCA066WJ01 J Front Panel Ass’yBG
6-1 Not Available – Front Panel —
6-2 GCOVAA288WJSA J Door Cover AW
6-3 GDORFA018WJSA J Door AN
6-4 HBDGBA013WJSA J Badge, "SHARP" AK
6-5 HDECQA166WJSA J LED Cover AF
6-6 HiNDPA290WJSA J Indication Label AH
6-7 JBTN-2074CEKB J Power Button AG
6-8 LANGF9552CESA J Angle, for Door AC
6-9 LANGTA024WJFW J Angle, for Damper AE
6-10 LANGTA047WJFW J Angle AC
6-11 LHLDZ3057GEZZ J Magnet Holder AE
6-12 LHLDZA138WJZZ J Button Holder AE
6-13 LX-BZ3434CEFN J Screw, x2 AB
6-14 MSPRC0210CEFW J Spring, for Power Button AB
6-15 PCOVPA014WJSA J Door Cover AK
6-16 PDMPFA001WJZZ J Damper AG
6-17 PSPAZ0457CESA J Spacer, for Door, x2 AA
6-18 XBPSD20P05000 J Screw, x2 AA
6-19 XEBSD30P08000 J Screw, x4 AA
7 Not Available – PC I/F Top Shield Ass’y —
7-1 PSLDMA157WJFW J PC I/F Top Shield AS
7-2 PSPAKA019WJZZ J Spacer AF
8 GCOVAA243WJSA J Side Cover(L) AN
9 GCOVAA244WJSA J Side Cover(R) AN
10 LANGTA022WJFW J PWB Angle, for MAIN Unit AN
11 LANGTA028WJFW J Inlet Angle AH
12 LANGTA039WJFW J PWB Angle, for AV Unit AP
13 LHLDW1009CEZZ J Wire Holder, x1 AA
14 LHLDW1033CEKZ J Wire Holder, x1 AA
15 LHLDW1060CEZZ J Wire Holder, x2 AB
16 LHLDW1121GEZZ J Wire Holder, x1 AB
17 LHLDZ2156CEN2 J Fan Holder AH
18 LX-BZ3434CEFN J Screw, x2 AB
19 NFANR0120CEZZ J Cooling Fan AU
20 NSFTZ0134CEFW J Shaft Screw, x8 AD
21 PSLDM4715CEFW J Earth Shield AD
22 PSLDMA144WJFW J Front Shield AQ
23 PSPAZA121WJKZ J Radiating Sheet AT
24 PSPAZA122WJKZ J Radiating Sheet AK
25 DUNTKB401FE05 – MAIN Unit —
26 DUNTKB493DE05 – POWER Unit —
27 DUNTKB592DE02 – AV Unit —
28 DUNTKB593DE22 – FRONT Unit —
29 DUNTKB594DE22 – SR Unit —
30 CPCi-A005WJ51 – PC I/F Unit —
31 QCNW-A847WJZZ J Connecting Cord(Main-AV) AD
32 QCNW-A848WJZZ J Connecting Cord AD
(Main-PC I/F)
33 QCNW-A849WJZZ J Connecting Cord AC
(Main-PC I/F)
34 QCNW-A833WJZZ J Connecting Cord(Front-AV) AE
35 QCNW-A838WJZZ J Connecting Cord AK
(Front-PC I/F)
36 QCNW-A828WJZZ J Connecting Cord(AV-SR) AK
37 QCNW-A844WJZZ J Connecting Cord AM
(PC I/F-SR)
38 QCNW-A825WJZZ J Connecting Cord AK
(Main-Power)
39 QCNW-A826WJZZ J Connecting Cord AG
(Main-Power)
40 QCNW-A846WJZZ J Connecting Cord AH
(Power-PC I/F)
41 QCNW-A822WJZZ J Connecting Cord(Main-AV) AF
42 QCNW-A823WJZZ J Connecting Cord(Main-AV) AM
43 QCNW-A824WJZZ J Connecting Cord(Main-AV) AQ
44 QEARZ0056CEFW J Earth Angle, x4 AC
45 QEARZ0057CEFW J Earth Angle, x1 AB
46 CEARZA023WJ01 J Earth Angle, x1
47 CEARZA024WJ01 J Earth Angle, x1
48 Not Available – Serial No. Label —
49 XBBSN30P06000 J Screw, x2 AA
50 XBPSN30P06000 J Screw, x6 AA
51 XEBSF30P08000 J Screw, x6 AA
52 XJPSN30P08XS0 J Screw, x53 AA
