52
LC-30HV4E
Pin No.
Pin Name
T
ype
Description
139
R/CrIN1
I
R/Cr signal input 1
140
A
VCCAMPR
––
R/Cr amplifier power supply
141
R/CrIN2
I
R/Cr signal input 2
142
A
GNDAMPR
––
R/Cr amplifier GND
143
G/Y
OUT
O
Amplifier output signal monitor
144
D
ACTEST
O
Input for testing amplifier control resistor D
A
C
14, 102, 122,
OUTDPGND
––
GND
131, 138
51
53
