Sharp LC-32AX3H - Page 53

Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
65
LC-32AX3H/M/X
LC-37AX3H/M/X
DUNTKD513DE01 (LC-32AX3M) DUNTKD513DE04 (LC-37AX3M)
DUNTKD513DE02 (LC-32AX3H) DUNTKD513DE05 (LC-37AX3H)
DUNTKD513DE03 (LC-32AX3X) DUNTKD513DE06 (LC-37AX3X)
AV Unit (Continued)
R5715 VRS-CY1JF103FY J 10k 1/16W Metal Oxide AA
R5720 VRS-TV1JD000JY J 0 1/10W Metal Oxide AA
R5721 VRS-TV1JD000JY J 0 1/10W Metal Oxide AA
R5722 VRS-CY1JF223FY J 22k 1/16W Metal Oxide AA
R5774 VRS-CY1JF223FY J 22k 1/16W Metal Oxide AA
SWITCH
S1200 QSW-KA028WJZZ J RESET/SYSTEM RESET AD
MISCELLANEOUS PARTS
FB1100 RBLN-0210TAZZY J Ferrite Bead AB
FB1101 RBLN-0065CEZZY J Ferrite Bead AC
FB1200 RBLN-0051TAZZY J Ferrite Bead AC
FB1201 RBLN-0051TAZZY J Ferrite Bead AC
FB1202 RBLN-0051TAZZY J Ferrite Bead AC
FB1203 RBLN-0051TAZZY J Ferrite Bead AC
FB1204 RBLN-0051TAZZY J Ferrite Bead AC
FB1205 RBLN-0062TAZZY J Ferrite Bead AB
FB1206 RBLN-0051TAZZY J Ferrite Bead AC
FB1207 RBLN-0062TAZZY J Ferrite Bead AB
FB1212 RBLN-0210TAZZY J Ferrite Bead AB
FB1218 RBLN-0061TAZZY J Ferrite Bead AD
FB1219 RBLN-0061TAZZY J Ferrite Bead AD
FB1900 RBLN-0060TAZZY J Ferrite Bead AB
FB1903 RBLN-0060TAZZY J Ferrite Bead AB
FB1904 RBLN-0060TAZZY J Ferrite Bead AB
FB1906 RBLN-0062TAZZY J Ferrite Bead AB
FB1907 RBLN-0062TAZZY J Ferrite Bead AB
FB2500 RBLN-0061TAZZY J Ferrite Bead AD
FB2501 RBLN-0065CEZZY J Ferrite Bead AC
FB2502 RBLN-0062TAZZY J Ferrite Bead AB
FB2503 RBLN-0062TAZZY J Ferrite Bead AB
FB2504 RBLN-0210TAZZY J Ferrite Bead AB
FB2505 RBLN-0210TAZZY J Ferrite Bead AB
FB2700 RBLN-0250TAZZY J Ferrite Bead AC
FB2701 RBLN-0210TAZZY J Ferrite Bead AB
FB2702 RBLN-0210TAZZY J Ferrite Bead AB
FB2703 RBLN-0210TAZZY J Ferrite Bead AB
FB2704 RBLN-0059TAZZY J Ferrite Bead AB
FB2705 RBLN-0210TAZZY J Ferrite Bead AB
FB2706 RBLN-0210TAZZY J Ferrite Bead AB
FB2707 RBLN-0210TAZZY J Ferrite Bead AB
FB2708 RBLN-0210TAZZY J Ferrite Bead AB
J1200 QSOCD0456CEZZ J S-VIDEO(INPUT3) AE
J1201 QJAKLA018WJZZ J INPUT1 Terminal AF
J1202 QJAKLA018WJZZ J INPUT2 Terminal AF
J1203 QTANJA074WJZZ J INPUT3/AV OUTPUT AG
Terminal
J1900 QJAKFA033WJZZ J AUDIO(L/R)(INPUT4) AD
J2500 QJAKJA007WJZZ J Headphone Jack AD
P1200 QPLGNA339WJZZY J Plug, 5-pin(KM) AD
P1201 QPLGNA344WJZZY J Plug, 10-pin(RA) AD
P1202 QPLGNA347WJZZY J Plug, 13-pin(TO) AD
P2700 QPLGNA173WJZZY J Plug, 4-pin(SP) AD
P5703 QPLGNA181WJZZY J Plug, 12-pin(PA) AF
P5705 QPLGNA144WJZZY J Plug, 20-pin(FD) AF
SC1204 QSOCNA542WJPZY J Socket, 50-pin(FC) AF
SC1900 QSOCZA072WJZZQ J HDMI(INPUT4) AH
LUG5700 QLUGHA006WJZZY J Lug AC
LUG5701 QLUGHA006WJZZY J Lug AC
LUG5702 QLUGHA006WJZZY J Lug AC
LUG5704 QLUGHA006WJZZY J Lug AC
LUG5705 QLUGHA006WJZZY J Lug AC
SLD1100 PSLDMA212WJFW J IF Shield AE
PRDARA263WJFW J Heat Sink AE
PSLDMA710WJFW J HDMI Shield(Top) AD
PSLDMA711WJFW J HDMI Shield(Bottom) AD
PSPAZA958WJKZ J Spacer AD
XBPS730P06WS0 J Screw, x2 AA
DUNTKD514DE01 (LC-32AX3M) DUNTKD514DE04 (LC-37AX3M)
DUNTKD514DE02 (LC-32AX3H) DUNTKD514DE05 (LC-37AX3H)
DUNTKD514DE03 (LC-32AX3X) DUNTKD514DE06 (LC-37AX3X)
KEY Unit
DIODES
D151 RH-EXA092WJZZY J Zener Diode, 12V AB
D152 RH-EXA092WJZZY J Zener Diode, 12V AB
RESISTORS
R151 VRS-CY1JF822FY J 8.2k 1/16W Metal Oxide AA
R152 VRS-CY1JF123FY J 12k 1/16W Metal Oxide AA
R153 VRS-CY1JF822FY J 8.2k 1/16W Metal Oxide AA
R154 VRS-CY1JF223FY J 22k 1/16W Metal Oxide AA
SWITCHES
S151 QSW-K0108CEZZY J CH(Ù)AD
S152 QSW-K0108CEZZY J CH(ù)AD
S153 QSW-K0108CEZZY J TV/VIDEO AD
S154 QSW-K0108CEZZY J VOL(+) AD
S155 QSW-K0108CEZZY J VOL(–) AD
S156 QSW-P0035GEZZ J POWER AF
MISCELLANEOUS PARTS
P151 QPLGNA161WJZZY J Plug, 5-pin AE
