Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
66
LC-32AX3H/M/X
LC-37AX3H/M/X
DUNTKD515DE01 (LC-32AX3M) DUNTKD515DE04 (LC-37AX3M)
DUNTKD515DE02 (LC-32AX3H) DUNTKD515DE05 (LC-37AX3H)
DUNTKD515DE03 (LC-32AX3X) DUNTKD515DE06 (LC-37AX3X)
R/C, LED Unit
INTEGRATED CIRCUITS
IC101 VHiTPS850++-1Y J TPS850 AG
TRANSISTORS
Q102 VS2SC3928AR-1Y J 2SC3928AR AB
Q103 VS2SC3928AR-1Y J 2SC3928AR AB
Q106 VS2SC3928AR-1Y J 2SC3928AR AB
Q107 VS2SC3928AR-1Y J 2SC3928AR AB
DIODES
D101 RH-EXA092WJZZY J Zener Diode, 12V AB
D102 RH-PX0202TAZZY J OPC Indicator AC
D103 RH-PX0210TAZZY J POWER Indicator AC
D104 RH-PX0200TAZZY J SLEEP Timer Indicator AC
CAPACITOR
C101 VCERMZ1CN107MY J 100 16V Electrolytic AD
C102 VCKYTV1CF225ZY J 2.2 16V Ceramic AB
C104 VCERML1CN106MY J 10 16V Electrolytic AC
C105 VCKYCY1HF103ZY J 0.01 50V Ceramic AA
RESISTORS
R101 VRS-CY1JF101FY J 100 1/16W Metal Oxide AA
R104 VRS-CY1JF101FY J 100 1/16W Metal Oxide AA
R107 VRS-CY1JF223FY J 22k 1/16W Metal Oxide AA
R108 VRS-CY1JF271FY J 270 1/16W Metal Oxide AA
R109 VRS-CY1JF122FY J 1.2k 1/16W Metal Oxide AA
R110 VRS-CY1JF223FY J 22k 1/16W Metal Oxide AA
R111 VRS-CY1JF101FY J 100 1/16W Metal Oxide AA
R112 VRS-CY1JF471FY J 470 1/16W Metal Oxide AA
R113 VRS-CJ1JF103JY J 10k 1/16W Metal Oxide AA
R114 VRS-CY1JF272FY J 2.7k 1/16W Metal Oxide AA
R115 VRS-CJ1JF103JY J 10k 1/16W Metal Oxide AA
MISCELLANEOUS PARTS
P101 QPLGNA344WJZZY J Plug, 10-pin(RA) AD
RMC101 RRMCUA025WJZZ J Remote Control Sensor AF
SLD101 PSLDM4646CEFW J Shield AD
DUNTKD558FE01 (LC-32AX3M) DUNTKD558FE04 (LC-37AX3M)
DUNTKD558FE02 (LC-32AX3H) DUNTKD558FE05 (LC-37AX3H)
DUNTKD558FE03 (LC-32AX3X) DUNTKD558FE06 (LC-37AX3X)
MAIN Unit
INTEGRATED CIRCUITS
IC1001 RH-iXB427WJZZQ J M30626µHP258GP AX
IC1002 VHiBD5224G+-1Y J BD5224G-TR AD
IC1003 VHiBR24L64F-1Y J BR24L64F-WE2 AK
IC1004 RH-iXB683WJZZQ J I.C. AN
IC1014 RH-iXB496WJQZQ J LC4128V-75TN10 AQ
IC1503 RH-iXB497WJQ1Q J LC4256V-75TN10 AW
IC1801 VHiPQ1CX12H-1Y J PQ1CX12H2ZP AK
IC1803 VHiPQ1CZ41H-1Y J PQ1CZ41H2ZP AG
IC1804 VHiPQ1X331M-1Y J PQ1X331M2ZP AD
IC1805 VHiPQ050DNA-1Y J PQ050DNA1ZPH AE
IC1806 VHiTPS54350-1Y J TPS54350PWPR AN
IC1807 VHiPQ1MX55M-1Y J PQ1MX55M2SP AD
IC1809 VHiPQ1R50//-1Y J PQ1R50 AF
IC1810 VHiBD5224G+-1Y J BD5224G-TR AD
IC1812 VHiBD5224G+-1Y J BD5224G-TR AD
IC3201 VHiDS90C386-1Y J DS90CF386MTDX AP
IC3202 VHiD90C385A-1Y J DS90C385AMTX AN
IC3203 VHiTCLCX08F-1Y J TC74LCX08F AF
IC3204 VHiiCS570B+-1Y J ICS570BT AQ
IC3301 RH-iXB405WJZZQ J SVP-EX59 BK
IC3302 RH-iXB375WJZZQ J K4D263238G-VC3 BA
IC3303 RH-iXA361WJZZY J LP2995MX AM
TRANSISTORS
Q1001 VSRN2104///-1Y J RN2104 AB
Q1002 VSRN2104///-1Y J RN2104 AB
Q1003 VSRN2104///-1Y J RN2104 AB
Q1004 VSRN2104///-1Y J RN2104 AB
Q1005 VSUMG2N++++-1Y J UMG2N AB
Q1803 VSRTQ045N03-1Y J RTQ045N03 AE
Q3701 VS2SC3928AR-1Y J 2SC3928AR AB
Q3702 VS2SA1530AR-1Y J 2SA1530AR AB
Q3703 VS2SC3928AR-1Y J 2SC3928AR AB
Q3704 VS2SA1530AR-1Y J 2SA1530AR AB
Q3705 VS2SC3928AR-1Y J 2SC3928AR AB
Q3706 VS2SA1530AR-1Y J 2SA1530AR AB
Q3707 VS2SA1530AR-1Y J 2SA1530AR AB
Q3708 VS2SC3928AR-1Y J 2SC3928AR AB
Q3709 VS2SA1530AR-1Y J 2SA1530AR AB
Q3710 VS2SC3928AR-1Y J 2SC3928AR AB
Q3711 VS2SA1530AR-1Y J 2SA1530AR AB
Q3712 VS2SC3928AR-1Y J 2SC3928AR AB
DIODES
D1001 RH-PXA018WJZZY J GM1HD55200A AC
D1003 VHDRB521S30-1Y J Diode AC
D1801 VHDLi124+++-1Y J Diode AC
D1802 VHDDG1M3+++-1Y J Diode AC
D1805 VHD1SS355//-1Y J Diode AB
D1806 VHDDG1M3+++-1Y J Diode AC
D3301 RH-EX1234CEZZY J Zener Diode, 3.6V AE
TH1001 VHHM1103J03-1Y J Thermistor AC
PACKAGED CIRCUITS
X1001 RCRSCA117WJZZY J Crystal, 10MHz AG
X3301 RCRSC0170TAZZY J Crystal, 14.31818MHz AG
FILTER AND COILS
FL3201 RFiLNA118WJZZY J Filter (LC-32AX3X, LC-37AX3X) AC
FL3202 RFiLNA118WJZZY J Filter (LC-32AX3X, LC-37AX3X) AC
FL3203 RFiLNA118WJZZY J Filter (LC-32AX3X, LC-37AX3X) AC
FL3204 RFiLNA118WJZZY J Filter (LC-32AX3X, LC-37AX3X) AC
FL3205 RFiLNA118WJZZY J Filter (LC-32AX3X, LC-37AX3X) AC
FL3206 RFiLNA118WJZZY J Filter (LC-32AX3X, LC-37AX3X) AC
FL3208 RFiLNA118WJZZY J Filter (LC-32AX3X, LC-37AX3X) AC
FL3301 RFiLNA118WJZZY J Filter (LC-32AX3X, LC-37AX3X) AC
FL3302 RFiLNA118WJZZY J Filter (LC-32AX3X, LC-37AX3X) AC
FL3303 RFiLNA118WJZZY J Filter (LC-32AX3X, LC-37AX3X) AC
FL3304 RFiLNA118WJZZY J Filter (LC-32AX3X, LC-37AX3X) AC
