Sharp LC-32G2X/ TU-32GAX - Connecting an HDTV Tuner; Connecting a VCR

47
Using external equipment
AVC System (rear view)
HDTV tuner
AV cable
(commercially available)
Connecting an HDTV tuner
You can use the INPUT 1 terminal when connecting an HDTV tuner and other audiovisual equipment.
AVC System (rear view)
VCR
AV cable (commercially available)
Connecting a VCR
You can use the INPUT 2 terminal when connecting a VCR and other audiovisual equipment.
To watch an image from this input terminal, you
need to select the input source (see page 46)
and the input signal type (see page 52).
To watch an image from this input terminal, you
need to select the input source (see page 46)
and the input signal type (see page 52).
Component cable (commercially available)
S-video cable
(commercially available)
