Sharp LC-32LE240EV User Manual

80
LC-32LE240
LC-40LE240
REF No.
PARTS DESCRIPTION *
PRICE
CODE
F259 30020530 FERRIT SMD 600R/100MHz 0.5R M 0.2A 603Ro G --
F270 30001734 RES SMD 1/10W 0R 0805 ROHS G --
F271 30019087 FERRIT SMD 60R/100MHz 0.025 M 3A 0805Roh G --
F272 30019087 FERRIT SMD 60R/100MHz 0.025 M 3A 0805Roh G --
F273 30001734 RES SMD 1/10W 0R 0805 ROHS G --
F274 30019087 FERRIT SMD 60R/100MHz 0.025 M 3A 0805Roh G --
F277 30019087 FERRIT SMD 60R/100MHz 0.025 M 3A 0805Roh G --
F281 30019087 FERRIT SMD 60R/100MHz 0.025 M 3A 0805Roh G --
F282 30019087 FERRIT SMD 60R/100MHz 0.025 M 3A 0805Roh G --
F283 30001734 RES SMD 1/10W 0R 0805 ROHS G --
F290 30019087 FERRIT SMD 60R/100MHz 0.025 M 3A 0805Roh G --
F291 30019087 FERRIT SMD 60R/100MHz 0.025 M 3A 0805Roh G --
F295 30063648 FERRIT SMD 120/100MHz 0.09R M1.2A 0402Ro G --
F300 30019087 FERRIT SMD 60R/100MHz 0.025 M 3A 0805Roh G --
F301 30020530 FERRIT SMD 600R/100MHz 0.5R M 0.2A 603Ro G --
F303 30019087 FERRIT SMD 60R/100MHz 0.025 M 3A 0805Roh G --
F305 30063648 FERRIT SMD 120/100MHz 0.09R M1.2A 0402Ro G --
F306 30063648 FERRIT SMD 120/100MHz 0.09R M1.2A 0402Ro G --
F307 30063648 FERRIT SMD 120/100MHz 0.09R M1.2A 0402Ro G --
F308 30063648 FERRIT SMD 120/100MHz 0.09R M1.2A 0402Ro G --
F5 30020530 FERRIT SMD 600R/100MHz 0.5R M 0.2A 603Ro G --
F8 30019087 FERRIT SMD 60R/100MHz 0.025 M 3A 0805Roh G --
L116 30058702 COIL SMD 10uH 2.5A M 0R4 7x7(SHL)Ro G --
L117 30058702 COIL SMD 10uH 2.5A M 0R4 7x7(SHL)Ro G --
L119 30025158 COIL SMD 4.7uH 0.03A M 1R 805 Ro G --
L120 30025158 COIL SMD 4.7uH 0.03A M 1R 805 Ro G --
L124 30072017 COIL SMD 10uH 2A5 M 0R06 6X6X4.5 (SHL)Ro G --
L125 30072017 COIL SMD 10uH 2A5 M 0R06 6X6X4.5 (SHL)Ro G --
L126 30072017 COIL SMD 10uH 2A5 M 0R06 6X6X4.5 (SHL)Ro G --
L127 30072017 COIL SMD 10uH 2A5 M 0R06 6X6X4.5 (SHL)Ro G --
TU3 30070628 TUNER SILICAN HNIM SUT-RE216 RoHS G --
C1 30050554 CAP SMD 1UF 6.3V M X5R (0402) RoHS G --
C1001 30044848 CAP SMD 100NF 16V K X7R (0402) ROHS G --
C1004 30044848 CAP SMD 100NF 16V K X7R (0402) ROHS G --
C1005 30050558 CAP SMD 100NF 16V K X5R (0402) ROHS G --
C1007 30050558 CAP SMD 100NF 16V K X5R (0402) ROHS G --
C1008 30050558 CAP SMD 100NF 16V K X5R (0402) ROHS G --
C1009 30050558 CAP SMD 100NF 16V K X5R (0402) ROHS G --
C1014 30050558 CAP SMD 100NF 16V K X5R (0402) ROHS G --
C1015 30030097 CAP SMD 100NF 10V K X5R (0402) RoHS G --
C1016 30044848 CAP SMD 100NF 16V K X7R (0402) ROHS G --
C1022 30050558 CAP SMD 100NF 16V K X5R (0402) ROHS G --
C1024 30050558 CAP SMD 100NF 16V K X5R (0402) ROHS G --
C1025 30050558 CAP SMD 100NF 16V K X5R (0402) ROHS G --
C1028 30067872 CAP SMD 10UF 10V M X5R (0805) ROHS G --
C1029 30067872 CAP SMD 10UF 10V M X5R (0805) ROHS G --
C1030 30067872 CAP SMD 10UF 10V M X5R (0805) ROHS G --
C1031 30047296 CAP SMD 22UF 6.3V M X5R (0805) ROHS G --
C1032 30064117 CAP SMD 10UF 16V K X5R (0805) RoHS G --
C1033 30047296 CAP SMD 22UF 6.3V M X5R (0805) ROHS G --
C1034 30030097 CAP SMD 100NF 10V K X5R (0402) RoHS G --
TUNER
CAPACITORS
REF No.
PARTS DESCRIPTION *
PRICE
CODE
C1035 30030097 CAP SMD 100NF 10V K X5R (0402) RoHS G --
C1042 30030097 CAP SMD 100NF 10V K X5R (0402) RoHS G --
C1043 30010560 CAP SMD 220NF 25V K X7R (0805) ROHS G --
C1044 30010560 CAP SMD 220NF 25V K X7R (0805) ROHS G --
C1045 30010560 CAP SMD 220NF 25V K X7R (0805) ROHS G --
C1046 30010560 CAP SMD 220NF 25V K X7R (0805) ROHS G --
C1058 30050558 CAP SMD 100NF 16V K X5R (0402) ROHS G --
C1070 30050558 CAP SMD 100NF 16V K X5R (0402) ROHS G --
C1073 30020142 CAP SMD 1UF 25V Z Y5V (0805) RoHS G --
C1074 30020142 CAP SMD 1UF 25V Z Y5V (0805) RoHS G --
C1075 30050557 CAP SMD 470NF 6.3V K X5R (0402) RoHS G --
C1076 30050557 CAP SMD 470NF 6.3V K X5R (0402) RoHS G --
C1077 30050557 CAP SMD 470NF 6.3V K X5R (0402) RoHS G --
C1078 30050557 CAP SMD 470NF 6.3V K X5R (0402) RoHS G --
C1079 30047296 CAP SMD 22UF 6.3V M X5R (0805) ROHS G --
C1080 30010594 CAP ELCH 100UF 16V M 86mA 6.3x5.4 ROHS G --
C1081 30067872 CAP SMD 10UF 10V M X5R (0805) ROHS G --
C1084 30067595 CAP SMD 22UF 16V M X5R (1206) RoHS G --
C1085 30067595 CAP SMD 22UF 16V M X5R (1206) RoHS G --
C1086 30047296 CAP SMD 22UF 6.3V M X5R (0805) ROHS G --
C1087 30047296 CAP SMD 22UF 6.3V M X5R (0805) ROHS G --
C1093 30047296 CAP SMD 22UF 6.3V M X5R (0805) ROHS G --
C1094 30047296 CAP SMD 22UF 6.3V M X5R (0805) ROHS G --
C1098 30047296 CAP SMD 22UF 6.3V M X5R (0805) ROHS G --
C1101 30047296 CAP SMD 22UF 6.3V M X5R (0805) ROHS G --
C1107 30050554 CAP SMD 1UF 6.3V M X5R (0402) RoHS G --
C1113 30022342 CAP SMD 10NF 16V J X7R (0402) ROHS G --
C1121 30064117 CAP SMD 10UF 16V K X5R (0805) RoHS G --
C1122 30064117 CAP SMD 10UF 16V K X5R (0805) RoHS G --
C1123 30020142 CAP SMD 1UF 25V Z Y5V (0805) RoHS G --
C1128 30020142 CAP SMD 1UF 25V Z Y5V (0805) RoHS G --
C1131 30022339 CAP SMD 5.6NF 50V J X7R (0402) ROHS G --
C1168 30010594 CAP ELCH 100UF 16V M 86mA 6.3x5.4 ROHS G --
C1169 30010594 CAP ELCH 100UF 16V M 86mA 6.3x5.4 ROHS G --
C1170 30067872 CAP SMD 10UF 10V M X5R (0805) ROHS G --
C1171 30067872 CAP SMD 10UF 10V M X5R (0805) ROHS G --
C1172 30022342 CAP SMD 10NF 16V J X7R (0402) ROHS G --
C1174 30044848 CAP SMD 100NF 16V K X7R (0402) ROHS G --
C1175 30030097 CAP SMD 100NF 10V K X5R (0402) RoHS G --
C1176 30030097 CAP SMD 100NF 10V K X5R (0402) RoHS G --
C1177 30050558 CAP SMD 100NF 16V K X5R (0402) ROHS G --
C1178 30022244 CAP SMD 100PF 50V J COG (0402) ROHS G --
C1179 30022244 CAP SMD 100PF 50V J COG (0402) ROHS G --
C1180 30047296 CAP SMD 22UF 6.3V M X5R (0805) ROHS G --
C1181 30047296 CAP SMD 22UF 6.3V M X5R (0805) ROHS G --
C1182 30067872 CAP SMD 10UF 10V M X5R (0805) ROHS G --
C1183 30022338 CAP SMD 4.7NF 50V J X7R (0402) RoHS G --
C1184 30022338 CAP SMD 4.7NF 50V J X7R (0402) RoHS G --
C1185 30022244 CAP SMD 100PF 50V J COG (0402) ROHS G --
C1186 30022244 CAP SMD 100PF 50V J COG (0402) ROHS G --
C1187 30022196 CAP SMD 470PF 50V J X7R (0402) ROHS G --
C1188 30022196 CAP SMD 470PF 50V J X7R (0402) ROHS G --
C1189 30022196 CAP SMD 470PF 50V J X7R (0402) ROHS G --
C1190 30022196 CAP SMD 470PF 50V J X7R (0402) ROHS G --
