Sharp LC-32LE40E - Page 37

LC-32LE40E-LC-42LE40E
37
The Writing EDID
Take LC-32LE40E for example
1. Materials list
ISP JIG: 715GT080- A VGA cable PC
Monitor USB cable Tool New F/W
TPV P/N: 089G1758 X
2. Connection
3. FW upgrade
1. It needs following file to run RW_EEPROM_by_FactoryCommand program:
1. RW_EEPROM_by_FactoryCommand.exe Program
2. RW_EEPROM_by_FactoryCommand.ini Config saved file
Connect to PC
USB port by USB
cable.
Connect to TV
VGA port by
VGA cable.
