LC-32X20E/S/RU, LC-37X20E/S/RU
2 – 7
9. Remove all the connectors from PWBs.
Wire "LB" to WH
Wire "LW","FR" to WH
Wire "LA"
Wire "LB"
Wire "FR"
Wire "LW"
Wire "PL"
