Sharp LC-37X20E Service Manual

LC-32X20E/S/RU, LC-37X20E/S/RU
26
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
R1480 VRS-CY1JF223JY AA J Resistor 22k 1/16W Metal Oxide
R1481 VRS-CY1JF473JY AA J Resistor 47k 1/16W Metal Oxide
R1482 VRS-CY1JF223JY AA J Resistor 22k 1/16W Metal Oxide
R1483 VRS-CY1JF473JY AA J Resistor 47k 1/16W Metal Oxide
R7501 VRS-CY1JF103JY AA J Resistor 10k 1/16W Metal Oxide
R7502 VRS-CY1JF681JY AA J Resistor 680 1/16W Metal Oxide
R7503 VRS-CY1JF000JY AA J Resistor 0 1/16W Metal Oxide
R7504 VRS-CY1JF393JY AA J Resistor 39k 1/16W Metal Oxide
R7505 VRS-CY1JF333JY AA J Resistor 33k 1/16W Metal Oxide
R7506 VRS-CY1JF680JY AA J Resistor 68 1/16W Metal Oxide
R7508 VRS-CY1JF103JY AA J Resistor 10k 1/16W Metal Oxide
R7509 VRS-CY1JF822JY AA J Resistor 8.2k 1/16W Metal Oxide
R7512 VRS-CY1JF330JY AA J Resistor 33 1/16W Metal Oxide
R7516 VRS-CY1JF102JY AA J Resistor 1k 1/16W Metal Oxide
R7517 VRS-CY1JF222JY AA J Resistor 2.2k 1/16W Metal Oxide
R7518 VRS-CY1JF562JY AA J Resistor 5.6k 1/16W Metal Oxide
R7519 VRS-CY1JF562JY AA J Resistor 5.6k 1/16W Metal Oxide
R7520 VRS-CY1JF103JY AA J Resistor 10k 1/16W Metal Oxide
R7521 VRS-CY1JF103JY AA J Resistor 10k 1/16W Metal Oxide
R7524 VRS-CY1JF562JY AA J Resistor 5.6k 1/16W Metal Oxide
R7525 VRS-TQ2BD330JY AA J Resistor 33 1/8W Metal Oxide
R7526 VRS-CY1JF331JY AA J Resistor 330 1/16W Metal Oxide
R7527 VRS-CJ1JF472JY AA J Resistor 4.7k 1/16W Metal Oxide
R7528 VRS-CJ1JF101JY AA J Resistor 100 1/16W Metal Oxide
R7529 VRS-CY1JF471JY AA J Resistor 470 1/16W Metal Oxide
R7530 VRS-CY1JF000JY AA J Resistor 0 1/16W Metal Oxide
R7533 VRS-CY1JF392JY AA J Resistor 3.9k 1/16W Metal Oxide
R7534 VRS-CY1JF271JY AA J Resistor 270 1/16W Metal Oxide
R7535 VRS-CY1JF821JY AA J Resistor 820 1/16W Metal Oxide
R7536 VRS-CY1JF151JY AA J Resistor 0 1/16W Metal Oxide
R7537 VRS-CY1JF272JY AA J Resistor 2.7k 1/16W Metal Oxide
R7538 VRS-CY1JF101JY AA J Resistor 100 1/16W Metal Oxide
R7539 VRS-CY1JF103JY AA J Resistor 10k 1/16W Metal Oxide
R7540 VRS-CY1JF331JY AA J
Resistor 330 1/16W Metal Oxide
R7541 VRS-CY1JF221JY AA J Resistor 220 1/16W Metal Oxide
R7545 VRS-CY1JF000JY AA J Resistor 0 1/16W Metal Oxide
R7547 VRS-CY1JF102JY AA J Resistor 1k 1/16W Metal Oxide
R7549 VRS-CY1JF102JY AA J Resistor 1k 1/16W Metal Oxide
R7550 VRS-CY1JF101JY AA J Resistor 100 1/16W Metal Oxide
R7551 VRS-CY1JF332JY AA J Resistor 3.3k 1/16W Metal Oxide
R7552 VRS-CY1JF102JY AA J Resistor 1k 1/16W Metal Oxide
R7567 VRS-CY1JF822JY AA J Resistor 8.2k 1/16W Metal Oxide
R7568 VRS-CJ1JF000JY AA J Resistor 0 1/16W Metal Oxide
R7569 VRS-CY1JF820JY AA J Resistor 82 1/16W Metal Oxide
R7570 VRS-CY1JF820JY AA J Resistor 82 1/16W Metal Oxide
SC501 QCNCWA673WJZZY AF J Connector 82Pin
SC502 QSOCZA161WJZZ N R Socket 21Pin (INPUT 1)
SC503 QSOCZA161WJZZ N R Socket 21Pin (INPUT 2)
SLD7501 PSLDMB192WJ1W N R Shield
X1401 RCRSCA147WJZZY AG J Crystal
X1402 RCRSCA045WJZZY AG J Crystal 12.228MHz
X1403 RCRSCA045WJZZY AG J Crystal 12.228MHz
X7501 RCRSCA178WJZZY AG J Crystal 4MHz
X7502 RCRSCA181WJZZY AG J Crystal 20.48MHz
[5] DUNTKE264FM01 (R/C, LED Unit)
C102 VCKYTV1CF225ZY AB J Capacitor 2.2 16V Ceramic
C104 VCEASX1CN106MY AC J Capacitor 10 16V Electrolytic
C105 VCKYCY1HF103ZY AA J Capacitor 0.01 50V Ceramic
C107 VCEASY1CN107MY AC J Capacitor 100 16V Electrolytic
D101 RH-EXA092WJZZY AB J Zener Diode UDZSTE-1712B, 12V
D103 RH-PX0421CEZZY AD J Diode CL-165HR/YG-D-T, YOYAKU
D114 RH-PX0421CEZZY AD J Diode CL-165HR/YG-D-T, YOYAKU
D115 RH-PX0421CEZZY AD J Diode CL-165HR/YG-D-T, YOYAKU
IC101 VHIGA1S100W-1Y AE N J IC GA1A1S100WP
P101 QPLGNA335WJZZY AD J Plug 15Pin(RA)
P102 QPLGNA322WJZZY AC J Plug 2Pin
Q102 VS2SC3928AR-1Y AB J Transistor 2SC3928A-T112-1R
Q103 VS2SC3928AR-1Y AB J Transistor 2SC3928A-T112-1R
Q104 VS2SC3928AR-1Y AB J Transistor 2SC3928A-T112-1R
Q106 VS2SC3928AR-1Y AB J Transistor 2SC3928A-T112-1R
Q107 VS2SC3928AR-1Y AB J Transistor 2SC3928A-T112-1R
R101 VRS-CY1JF101JY AA J Resistor 100 1/16W Metal Oxide
R104 VRS-CY1JF273JY AA J Resistor 27k 1/16W Metal Oxide
R105 VRS-CY1JF393JY AA J Resistor 39k 1/16W Metal Oxide
R108 VRS-CY1JF161JY AA J Resistor 160 1/16W Metal Oxide
R109 VRS-CY1JF821JY AA J Resistor 820 1/16W Metal Oxide
R117 VRS-CY1JF103JY AA J Resistor 10k 1/16W Metal Oxide
R121 VRS-CY1JF821JY AA J Resistor 820 1/16W Metal Oxide
R122 VRS-CY1JF161JY AA J Resistor 160 1/16W Metal Oxide
R123 VRS-CJ1JF103JY AA J Resistor 10k 1/16W Metal Oxide
R124 VRS-CJ1JF103JY AA J Resistor 10k 1/16W Metal Oxide
R135 VRS-CY1JF000JY AA J Resistor 0 1/16W Metal Oxide
R140 VRS-CY1JF000JY AA J Resistor 0 1/16W Metal Oxide
RMC101 RRMCUA053WJZZ AE J Remote Receiver
[4] DUNTKE238FM01 (TERMINAL Unit)
