Sharp LC-37X20E Service Manual

LC-32X20E/S/RU, LC-37X20E/S/RU
27
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
SLD101 PSLDPA076WJFW AD J Shield
[6] DUNTKE266FM01 (KEY Unit)
D151 RH-EX0646GEZZY AA J Zener Diode MTZJT-7215B
D152 RH-EX0646GEZZY AA J Zener Diode MTZJT-7215B
D155 RH-EX0646GEZZY AA J Zener Diode MTZJT-7215B
P151 QPLGNA059WJZZ AC J Plug 5Pin(KM)
R151 VRD-RA2BE822JY AA J Resistor 8.2k 1/8W Carbon
R152 VRD-RA2BE123JY AA J Resistor 12k 1/8W Carbon
R153 VRD-RA2BE822JY AA J Resistor 8.2k 1/8W Carbon
R154 VRD-RA2BE123JY AA J Resistor 12k 1/8W Carbon
S151 QSW-K0003AJZZ+ AA J Switch CH UP
S152 QSW-K0003AJZZ+ AA J Switch CH DOWN
S153 QSW-K0003AJZZ+ AA J Switch CH INPUT
S154 QSW-K0003AJZZ+ AA J Switch VOL UP
S155 QSW-K0003AJZZ+ AA J Switch VOL DOWN
S156 QSW-K0003AJZZ+ AA J Switch CH MENU
S157 QSW-K0003AJZZ+ AA J Switch CH POWER
[7] DUNTKE306FM01 (MINI AV UNIT)
C801 RC-KZA067WJZZY AB J Capacitor 4.7 10V Ceramic
C804 RC-KZA237WJZZY AB J Capacitor 10 16V Ceramic
C816 VCKYCY1HB223KY AA J Capacitor 0.022 50V Ceramic
C827 VCKYCY1HB223KY AA J Capacitor 0.022 50V Ceramic
C828 VCKYCY1HB223KY AA J Capacitor 0.022 50V Ceramic
C830 VCKYCY1CB104KY AB J Capacitor 0.1 16V Ceramic
C831 VCKYCY1HB102KY AA J Capacitor 1000p 50V Ceramic
C832 VCKYCY1HB102KY AA J Capacitor 1000p 50V Ceramic
C903 VCKYCY1HB472KY AA J Capacitor 4700p 50V Ceramic
C904 VCKYCY1HB472KY AA J Capacitor 4700p 50V Ceramic
D806 VHD1PS226++-1Y AB J Diode 1PS226,115
D903 RH-EX0265TAZZY AB J Zener Diode PDZ10B,115
D904 RH-EX0265TAZZY AB J Zener Diode PDZ10B,115
D905 RH-EX0265TAZZY AB J Zener Diode PDZ10B,115
FB805 RBLN-A206WJZZY AA J Balun BLN-A206WJ
FB902 RBLN-0077TAZZY AB J Balun BLN-0077TA
FB903 RBLN-0077TAZZY AB J Balun BLN-0077TA
FL901 RFILN0017TAZZY AC J Filter
FL902 RFILN0017TAZZY AC J Filter
FL903 RFILN0017TAZZY AC J Filter
IC801 VHIR5523N1B-1Y AE J IC R5523N001B-TR-F
J801 QSOCZA151WJQZ AF J Socket 4Pin(USB)
J802 QJAKJ0047CEZZ AD J Jack
J901 QJAKGA079WJZZ AD J Jack
J902 QSOCD0456CEZZ AE J Socket
LUG901 QLUGHA006WJZZY AC J Lug
LUG902 QLUGHA006WJZZY AC J Lug
P801 QPLGNA334WJZZY AD J Plug 14Pin(US)
P901 QPLGNA335WJZZY AD J Plug 15Pin(RA)
R809 VRS-CY1JF103JY AA J Resistor 10k 1/16W Metal Oxide
R819 VRS-CY1JF102JY AA J Resistor 1k 1/16W Metal Oxide
R820 VRS-TW2ED100JY AA J Resistor 10 1/4W Metal Oxide
R821 VRS-CY1JF104JY AA J Resistor 100k 1/16W Metal Oxide
R822 VRS-TW2ED100JY AA J
Resistor 10 1/4W Metal Oxide
R823 VRS-CY1JF104JY AA J Resistor 100k 1/16W Metal Oxide
R839 VRS-CY1JF101JY AA J Resistor 100 1/16W Metal Oxide
R907 VRS-CY1JF104JY AA J Resistor 100k 1/16W Metal Oxide
R908 VRS-CY1JF104JY AA J Resistor 100k 1/16W Metal Oxide
R909 VRS-CY1JF000JY AA J Resistor 0 1/16W Metal Oxide
R910 VRS-CY1JF000JY AA J Resistor 0 1/16W Metal Oxide
R914 VRS-CY1JF000JY AA J Resistor 0 1/16W Metal Oxide
R915 VRS-CY1JF000JY AA J Resistor 0 1/16W Metal Oxide
VA801 RH-VXA194WJZZY AC N R Varistor AVRL161A1R1NTB
VA802 RH-VXA194WJZZY AC N R Varistor AVRL161A1R1NTB
[5] DUNTKE264FM01 (R/C, LED Unit)
