Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
LC-45GD5U
134
MISCELLANEOUS PARTS
FB253 RBLN-0210TAZZY J Ferrite Beads AB
FB254 RBLN-0210TAZZY J Ferrite Beads AB
J252 QTANAA008WJZZ J Terminal, 2Pin AD
P252 QPLGNA158WJZZY J Plug, 2Pin TO AV(SP) AD
DUNTKD408UJ02
SPEAKER TERMINAL-L Unit
DUNTKD409UJ02
SPEAKER TERMINAL-R Unit
MISCELLANEOUS PARTS
FB251 RBLN-0210TAZZY J Ferrite Beads AB
FB252 RBLN-0210TAZZY J Ferrite Beads AB
LUG251 QLUGHA006WJZZY J Lug AC
J251 QTANAA008WJZZ J Terminal, 2Pin AD
P251 QPLGNA158WJZZY J Plug, 2Pin TO AV(SP) AD
DUNTKD410UJ02
BUS CONNECT Unit
INTEGRATED CIRCUITS
IC6151 95CH10Q3AQ001 J IC, TA76431 0.01 AL
IC6351 95CH10Q3AQ001 J IC, TA76431 AL
IC6361 95CH2200AL001 J IC, BD9702T AU
IC6371 95CH2200AL001 J IC, BD9702T AU
IC6381 95CH10Q3AQ001 J IC, TA76431 AL
IC6391 95CH1031KQ999 J IC, PQ30RV31 3A
IC7101 95CH3151AC001 J IC, FA5502M AZ
IC7901 95CH3193AL003 J IC, MIP2E3DMY 20W
IC7951 95CH10Q3AQ001 J IC, TA76431 AL
IC7971 95CH2201AL001 J IC, BA00CC0WT AQ
TRANSISTORS
Q6101 95CT3683KL001 J 2SK3683 AW
Q6102 95CT4097CC002 J 2SC4097 AE
Q6110 95CT4097CC002 J 2SC4097 AE
Q6112 95CT4097CC002 J 2SC4097 AE
Q6120 95CT3683KL001 J 2SK3683 AW
Q6122 95CT4097CC002 J 2SC4097 AE
Q6301 95CT3561KL001 J 2SK3561 AN
Q6302 95CT4097CC002 J 2SC4097 AE
Q6310 95CT4097CC002 J 2SC4097 AE
Q6312 95CT4097CC002 J 2SC4097 AE
Q6320 95CT3561KL001 J 2SK3561 AN
Q6322 95CT4097CC002 J 2SC4097 AE
Q6361 95CT4081CC002 J 2SC4081 AD
Q6362 95CT4081CC002 J 2SC4081 AD
Q6371 95CT4081CC002 J 2SC4081 AD
Q6372 95CT4081CC002 J 2SC4081 AD
Q6391 95CT4081CC002 J 2SC4081 AD
Q7101 95CT3528KL001 J 2SK3528 AZ
Q7102 95CT3528KL001 J 2SK3528 AZ
Q7103 95CT1858DR001 J 2SD1858 AH
Q7104 95CT1237BR001 J 2SB1237 AH
Q7901 95CT4097CC002 J 2SC4097 AE
Q7902 95CT4097CC002 J 2SC4097 AE
Q7903 95CT1576AC002 J 2SA1576A AD
Q7904 95CT4097CC002 J 2SC4097 AE
Q7905 95CT4097CC002 J 2SC4097 AE
Q7906 95CT4097CC002 J 2SC4097 AE
Q7961 95CT4081CC002 J 2SC4081 AD
Q7962 95CT1577AC002 J 2SA1577 AE
Q7963 95CT4097CC002 J 2SC4097 AE
DIODES
D6102 95CD2095AQ008 J 1SS355 AD
D6103 95CD2095AQ008 J 1SS355 AD
D6104 95CD2095AQ008 J 1SS355 AD
D6106 95CD2095AQ008 J 1SS355 AD
D6107 95CD2095AQ008 J 1SS355 AD
D6110 95CD2095AQ008 J 1SS355 AD
D6112 95CD4103AC008 J Zener Diode, MA8068-M AD
D6113 95CD2095AQ008 J 1SS355 AD
D6121 95CD4103AC008 J Zener Diode, MA8068-M AD
D6122 95CD2095AQ008 J 1SS355 AD
D6123 95CD4103AC010 J Zener Diode, MA8075-M AD
D6130 95CD2095AQ008 J 1SS355 AD
D6131 95CD2095AQ008 J 1SS355 AD
D6151 95CD3142AL001 J YG862C15R AN
D6152 95CD3142AL001 J YG862C15R AN
D6153 95CD3142AL001 J YG862C15R AN
D6154 95CD4103AC024 J Zener Diode, MA8270-H AD
D6155 95CD2095AQ008 J 1SS355 AD
D6302 95CD2095AQ008 J 1SS355 AD
D6303 95CD2095AQ008 J 1SS355 AD
D6304 95CD2095AQ008 J 1SS355 AD
D6306 95CD2095AQ008 J 1SS355 AD
D6307 95CD2095AQ008 J 1SS355 AD
D6310 95CD2095AQ008 J 1SS355 AD
D6312 95CD4103AC008 J Zener Diode, MA8068-M AD
D6313 95CD2095AQ008 J 1SS355 AD
D6321 95CD4103AC008 J Zener Diode, MA8068-M AD
DIODES
D5001 RH-EX1315CEZZY J Zener Diode AC
D5002 RH-EX1315CEZZY J Zener Diode AC
D5003 RH-EX1315CEZZY J Zener Diode AC
D5004 RH-EX1315CEZZY J Zener Diode AC
RESISTORS
R5001 VRS-CH1JF101JY J 100 1/16W Metal Oxide AA
R5002 VRS-CH1JF101JY J 100 1/16W Metal Oxide AA
R5003 VRS-CH1JF104JY J 100k 1/16W Metal Oxide AA
R5004 VRS-CH1JF104JY J 100k 1/16W Metal Oxide AA
R5006 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
MISCELLANEOUS PARTS
P5001 QPLGNA412WJZZY J Plug, 20Pin TO BUS CONNECT AG
P5003 QPLGNA334WJZZY J Plug, TO AV AD
LUG5001 QLUGHA006WJZZY J Lug AC
LCHSMA246WJFW J Chassis AT
PSPAHA652WJZZ J Spacer
RDENCA142WJQZ
POWER SUPPLY Unit
