Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
LC-45GD5U
115
E9204 QEARBA005WJFMY J Ground-Part AD
FB8001 RBLN-0253TAZZY J Ferrite Beads AA
FB8501 RBLN-0237TAZZY J Ferrite Beads AB
FB8601 RBLN-0253TAZZY J Ferrite Beads AA
FB8602 RBLN-0253TAZZY J Ferrite Beads AA
FB8603 RBLN-0253TAZZY J Ferrite Beads AA
FB8604 RBLN-0253TAZZY J Ferrite Beads AA
FB8605 RBLN-0253TAZZY J Ferrite Beads AA
FB8606 RBLN-0253TAZZY J Ferrite Beads AA
FB8607 RBLN-0253TAZZY J Ferrite Beads AA
FB8608 RBLN-0253TAZZY J Ferrite Beads AA
FB8609 RBLN-0253TAZZY J Ferrite Beads AA
FB8610 RBLN-0253TAZZY J Ferrite Beads AA
FB8701 RBLN-0254TAZZY J Ferrite Beads AB
FB8801 RBLN-0237TAZZY J Ferrite Beads AB
FB8802 RBLN-0083GEZZY J Ferrite Beads AB
FB8803 RBLN-0083GEZZY J Ferrite Beads AB
FB8804 RBLN-0083GEZZY J Ferrite Beads AB
FB8805 RBLN-0083GEZZY J Ferrite Beads AB
FB8806 RBLN-0083GEZZY J Ferrite Beads AB
FB8901 RBLN-0067TAZZY J Ferrite Beads AC
FB8902 RBLN-0067TAZZY J Ferrite Beads AC
FB8903 RBLN-0067TAZZY J Ferrite Beads AC
FB8904 RBLN-0067TAZZY J Ferrite Beads AC
FB8905 RBLN-0067TAZZY J Ferrite Beads AC
FB9001 RBLN-0077TAZZY J Ferrite Beads AB
FB9002 RBLN-0067TAZZY J Ferrite Beads AC
FB9003 RBLN-0067TAZZY J Ferrite Beads AC
FB9401 RBLN-0254TAZZY J Ferrite Beads AB
FB9402 RBLN-0252TAZZY J Ferrite Beads AA
FB9403 RBLN-0209TAZZY J Ferrite Beads AB
FB9501 RBLN-0254TAZZY J Ferrite Beads AB
FB9502 RBLN-0254TAZZY J Ferrite Beads AB
FB9601 RBLN-0253TAZZY J Ferrite Beads AA
FB9602 RBLN-0254TAZZY J Ferrite Beads AB
FB9701 RBLN-0253TAZZY J Ferrite Beads AA
J8052 QJAKEA042WJZZ J Jack, 4Pin AE
J8501 QJAKZ1055CEZZ J Jack, 4Pin, IEEE1394_JACK_1 AF
J8502 QJAKZ1055CEZZ J Jack, 4Pin, IEEE1394_JACK_2 AF
J9001 QJAKEA055WJZZ J Jack, 4Pin, AV OUT (DA) AD
P8901 QPLGNA335WJZZY J Plug, 15Pin, PROGRAM PORT AD
P9101 QPLGN0056CEZZY J Plug, 6Pin AD
P9201 QCNCMA193WJZZY J Connector, 142Pin (DM) TO MAIN AN
P9601 QPLGNA162WJZZY J Plug, 6Pin (DP) AE
SC8701 QSOCZA050WJZZY J Socket, 12Pin, SD CARD SOCKET AH
SC9401 QSOCN0477FJZZ J Socket, 68Pin AS
SC9501 QPLGN0060CEZZY J Plug, 10Pin, ACTIVE SERIAL AE
LUG9401 QLUGHA007WJZZY J Lug AC
LUG9402 QLUGHA007WJZZY J Lug AC
LUG9601 QLUGHA006WJZZY J Lug AC
LUG9602 QLUGHA006WJZZY J Lug AC
LUG9603 QLUGHA006WJZZY J Lug AC
LUG9604 QLUGHA006WJZZY J Lug AC
LUG9605 QLUGHA006WJZZY J Lug AC
LUG9606 QLUGHA006WJZZY J Lug AC
LUG9607 QLUGHA006WJZZY J Lug AC
LUG9608 QLUGHA006WJZZY J Lug AC
LUG9609 QLUGHA006WJZZY J Lug AC
LUG9610 QLUGHA006WJZZY J Lug AC
LUG9611 QLUGHA006WJZZY J Lug AC
LUG9612 QLUGHA006WJZZY J Lug AC
XBPSN20P12JS0 J Screw AB
DKEYDD392VJ12
DIGITAL TUNER Unit (Continued)
INTEGRATED CIRCUITS
IC400 VHiPD64011B-1Q J UPD64011BGM BE
IC401 RH-iXB452WJZZQ J GLT5160AL16P-7
IC402 VHiSM5313AS-1Y J SM5313AS-G-ET AM
IC403 VHiPQ1M155M-1Y J PQ1M155M25PQ AD
IC404 VHiiCS570B+-1Y J ICS570BT AQ
IC800 RH-iXA835WJZZQ J EP1C4F400C8N BC
IC801 RH-iXB516WJQZY J EPCS1SI8N AP
IC802 VHiPQ1M155M-1Y J PQ1M155M25PQ AD
IC1502 VHiADC78H90-1Y J ADC78H90CIMTX AP
IC1801 VHiBD4746G+-1Y J BD4746G-TR AD
IC1804 VHiPQ050DNA-1Y J PQ050DNA1ZPH AE
IC1805 VHiBD4729G+-1Y J BD4729G-TR AD
IC1806 VHiTPS54350-1Y J TPS54350PWPR AN
IC1807 VHiMP1583++-1Y J MP1583DN-LF-Z AH
IC1808 VHiTPS40055-1Y J TPS40055PWPR AN
IC2100 VHiBR24L64F-1Y J BR24L64F-WE2 AK
IC2101 VHiPCA9516A-1Y J PCA9516APW,118 AP
IC2300 RH-iXB345WJZZQ J HD64F36049HV AY
IC2302 VHiBD5224G+-1Y J BD5224G-TR AD
IC2303 VHiBR24L08F-1Y J BR24L08F-WE2 AE
IC2305 VHiTCVHC32T-1Y J TC74VHC32FT AE
IC3201 VHiTLVD823+-1Q J THC63LVD823 AY
IC3203 VHi7WH157FK-1Y J TC7WH157FK AF
IC3300 RH-iXB348WJZZQ J MB87Q1120PBH-G BW
IC3401 RH-iXB375WJZZQ J K4D263238G-VC3 BA
IC3402 RH-iXA361WJZZY J LP2995MX AM
IC3403 RH-iXB375WJZZQ J K4D263238G-VC3 BA
IC3700 VHiAD9981++-1Q J AD9981KSTZ-110 BD
IC3701 VHiTB1308FG-1Q J TB1308FG(DRY) AT
IC3702 VHiSM5302AS-1Y J SM5302AS-G-ET AR
IC3703 VHi7WH126FU-1Y J TC7WH126FU AE
IC3704 VHiT7WH123U-1Y J TC7WH123FU AD
IC3705 VHiPQ1M335M-1Y J PQ1M335M2SP AD
IC3706 VHiPQ1MX55M-1Y J PQ1MX55M2SP AD
TRANSISTORS
Q403 VS2SC3928AR-1Y J 2SC3928AR AB
Q408 VS2SA1530AR-1Y J 2SA1530AR AB
Q409 VS2SA1530AR-1Y J 2SA1530AR AB
Q411 VS2SA1530AR-1Y J 2SA1530AR AB
Q412 VS2SA1530AR-1Y J 2SA1530AR AB
Q416 VSDTC144EKA-1Y J DTC144EKA AB
Q417 VS2SA1530AR-1Y J 2SA1530AR AB
Q418 VS2SA1530AR-1Y J 2SA1530AR AB
Q801 VSDTC144EE/-1Y J DTC144EE AA
Q802 VSDTC144EE/-1Y J DTC144EE AA
Q1500 VSDTC124EKA-1Y J DTC124EKA AB
Q1501 VSDTC124EKA-1Y J DTC124EKA AB
Q1502 VSDTA124EKA-1Y J DTA124EKA AB
Q1503 VSDTA124EKA-1Y J DTA124EKA AB
Q1800 VSDTC124EKA-1Y J DTC124EKA AB
Q1801 VS2SA1530AR-1Y J 2SA1530AR AB
Q1802 VSDTC124EKA-1Y J DTC124EKA AB
Q1803 VSDTA124EKA-1Y J DTA124EKA AB
Q1804 VSDTC144EE/-1Y J DTC144EE AA
Q1805 VSDTC144EE/-1Y J DTC144EE AA
Q1806 VS2SC3928AR-1Y J 2SC3928AR AB
Q1807 VS2SC3928AR-1Y J 2SC3928AR AB
Q1808 VS2SC3928AR-1Y J 2SC3928AR AB
Q1809 VS2SC3928AR-1Y J 2SC3928AR AB
Q1810 VSRTQ045N03-1Y J RTQ045N03 AE
Q1812 VSSP8K4++++-1Y J SP8K4++++ AF
Q2301 VSDTC144EE/-1Y J DTC144EE AA
Q2302 VSDTC144EE/-1Y J DTC144EE AA
Q2309 VSDTC144EE/-1Y J DTC144EE AA
DIODES
D801 RH-PXA018WJZZY J GM1HD55200A AC
D1500 RH-EX1232CEZZY J Zener Diode, 3.3V AB
D1802 RH-EX1232CEZZY J Zener Diode, 3.3V AB
D1803 VHD1SS355//-1Y J 1SS355 AB
DUNTKD393VJ03
MAIN Unit
