Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
LC-45GD5U
138
CABINET AND MECHANICAL PARTS
1 CCABAB120WJ02 J Front Cabinet Ass'y BW
1-1 Not Availabl e–Front Cabinet —
1-2 GCOVAA829WJKA J R/C, LED Decoration Cover AG
1-3 HBDGBA052WJSB J Badge, SHARP
1-4 PSPAHA633WJKZ J Mask Spacer, x6
1-5 TLABZA861WJSA J HDMI Label AD
1-6 TLABZA862WJSA J TV GUIDE Label
2 CCABBA684WJ01 J Rear Cabinet Ass'y
2-1 Not Availabl e–Rear Cabinet —
2-2 GCOVAA838WJKA J VESA-Hole Cover, x4 AE
2-3 GCOVAB322WJKA J Under Speaker Cover, x2 AG
2-4 GCOVAB325WJKA J PC Slot Cover AH
2-5 GCOVAB393WJKA J SUB AV Cover
2-6 HiNDP5733CESB J AQUOS Label AD
2-7 LHLDWA055WJKZ J Wire Holder AC
2-8 LHLDWA057WJKZ J Wire Holder FOR CABLE AE
2-9 LHLDWA102WJKZ J Wire Holder, x3 AB
2-10 LHLDZ0132CEZZ J Speaker Box Bush, x4 AD
2-11 LHLDZA665WJZZ J Speaker Fix Holder, x4
2-12 XEBSN30P10000 J Screw, x15 HLD-8,COV-4&3 AA
3 CCOVAB396WJ01 J Top Control Cover Ass'y AP
3-1 Not Availabl e–Top Control Cover —
3-2 JBTN-A307WJKA J Operation Button AK
3-3 JBTN-A340WJKA J Power Button AG
3-4 MSPRCA049WJFW J Spring for Power Button AC
4 CDAi-A220WJ04 J Stand Base Ass'y BK
4-1 GDAi-A220WJKB J Stand Base AZ
4-2 LANGKA564WJSA J Stand Base Angle BC
4-3 PSPAZA476WJZZ J LEG-Cushion-A, x4 AC
4-4 PSPAZA477WJZZ J LEG-Cushion-B, x4 AD
4-5 XEBS940P12000 J Screw, x10 BASE YOUAB
5 CHNG-A129WJ03 J Stand Hinge Ass'y BG
5-1 Not Availabl e–Stand Hinge —
5-2 GDAi-A221WJSB J Stand Support
5-3 GDAi-A222WJF8 J Swivel Base
5-4 LX-NZA013WJFN J Nut AE
5-5 PSPAZA773WJZZ J Spacer, x4
5-6 PSPAZA931WJZZ J Spacer, x2
5-7 XCSS750P30000 J Screw, x4
6 CANGKA450WJ01 J Fan Angle Ass'y
6-1 Not Availabl e–Fan Angle —
6-2 PSPAGA187WJ00 J Spacer, x4 AB
6-3 XBPS730P06WS0 J Screw, x2 AA
7 CANGKA450WJ02 J Fan Angle Ass'y
7-1 Not Availabl e–Fan Angle —
7-2 LHLDWA043WJKZ J Wire Holder, x2 AB
7-3 PSPAGA187WJ00 J Spacer, x4 AB
7-4 XBPS730P06WS0 J Screw, x2 AA
8 CANGKA452WJ01 J Center Angle Ass'y
8-1 Not Availabl e–Center Angle —
8-2 LANGKA466WJFW J Support Angle, x4
8-3 LHLDWA055WJKZ J Wire Holder AC
8-4 PSPAGA187WJ00 J Spacer, x4 AB
8-5 XBPS730P06WS0 J Screw, x2 AA
9 CSLDMA823WJ01 J Wire Shield Ass'y
9-1 Not Availabl e–Wire Shield —
9-2 PSLDMA878WJZZ J Sheet(210x35)
9-3 PSLDMA879WJZZ J Sheet(90x20)
9-4 PSLDMA880WJZZ J Sheet(20x20)
9-5 PSPAHA652WJZZ J Himeron A, x2
10 CCHSMA246WJ01 J Tray Chassis Ass'y
10-1 Not Availabl e–Tray Chassis —
10-2 PSPAHA652WJZZ J Speaker A
11-1 CSLDMA802WJ01 J Digital PWB Shield Ass'y
11-2
Not Availabl e–Digital PWB Shield Ass'y —
11-3 PSPAHA653WJZZ J Speaker B
12 CPNLSA056WJ01 J Speaker Panel Ass'y (L) BN
12-1 Not Availabl e–Speaker Panel (L) —
12-2 HPNC-A103WJSA J Punching Net
12-3 PCUSUA001WJZZ J Speaker Port Cushion
12-4 PSPAZA871WJZZ J Speaker Panel Spacer
12-5 PSPAZA893WJZZ J Speaker Panel Spacer
12-6 RSP-ZA142WJN3 J Side Speaker (L) BK
13 CPNLSA056WJ02 J Speaker Panel Ass'y (R)
13-1 Not Availabl e–Speaker Panel (R) —
13-2 HPNC-A103WJSA J Punching Net
13-3 PCUSUA001WJZZ J Speaker Port Cushion
13-4 PSPAZA871WJZZ J Speaker Panel Spacer
13-5 PSPAZA893WJZZ J Speaker Panel Spacer
13-6 RSP-ZA142WJN4 J Side Speaker (R) BK
14 RLCUCA015WJZZ J 45V WideLCD Panel Module Unit
15 DUNTKD154VJ03 – AC INPUT Unit —
16 DKEYDD392VJ12 – DIGITAL TUNER Unit —
17 DUNTKD393VJ03 – MAIN Unit —
18 DUNTKD405UJ02 – AV Unit —
19 DUNTKD406UJ02 – KEY Unit —
20 DUNTKD407UJ02 – R/C, LED Unit —
21 DUNTKD408UJ02 –
SPEAKER TERMINAL-L Unit —
22 DUNTKD409UJ02 – SPEAKER TERMINAL-R Unit —
23 DUNTKD410UJ02 – BUS CONNECT Unit —
24 RDENCA142WJQZ – POWER SUPPLY Unit —
25 GCOVAB368WJKA J Terminal Cover (R) AN
26 GCOVAB369WJKA J Terminal Cover (TOP) AV
27 GCOVAB370WJKA J Terminal Cover (L) AS
28 GCOVAA678WJKA J SD Card Cover AE
29 GCOVAB162WJKA J BUS CONNECT Cover AD
30 GCOVAB329WJKB J Stand Cover
31 GCOVAB414WJKA J Screw Cap, x4 AD
32 GCOVHA042WJKA J PC Card Cover AE
33 GCOVAB390WJKA J AV Terminal Cover R AS
34 GCOVAB391WJKA J AV Terminal Cover B AK
35 GCOVAB392WJKA J AV Terminal Cover D AL
36 HiNDPB425WJSA J Model Label AL
37 LANGKA606WJFW J BUS CONNECT PWB Angle AE
38 LHLDWA048WJKZ J Wire Holder (BUS ANG) AB
39 LANGQA013WJFW J AC INPUT PWB Angle AH
40 LHLDWA055WJKZ J Holder AC
41 LANGKA293WJZZ J Speaker Fixing Angle (Top), x2 AH
42 LANGKA294WJZZ J Speaker Fixing Angle (Bottom), x2 AH
43 LANGKA333WJFW J Mask Angle, x2 AG
44 LANGKA614WJFW J Spacer Angle, x2
45 LX-BZA051WJF7 J Screw M4-10(EARTH LUG AB
46 LX-BZA145WJN1 J Screw, x4
M3X6+NYLON WASHR
47 LHLDWA119WJKZ J Wire Holder
48 LHLDWA080WJKZ J Wire Holder (AV) AB
49 NSFTZ0134CEFW J Screw, x4 Shaft DVI/232C (AV) AD
50 NFANR0126CEZZ J DC Fan ,x3 (80X80MM) AT
51 PSLDMA807WJFW J HDMI Shield (Bottom) (AV) AG
52 PSLDMA870WJFW J HDMI Shield (Top) (AV)
53 PMLT-A126WJZZ J Gasket
54 PMLT-A274WJZZ J Gasket, x2 (TRAYBTM)
55 PMLT-A275WJZZ J Gasket, x3 (TRAYBTM)
56 PMLT-A277WJZZ J Gasket (TRAYBTM)
57 PMLT-A279WJZZ J Gasket, x2 (MAINANGL)
58 PRDARA268WJFW J Heat Sink (AV)
59 PSLDMA744WJZZ J Conduct Cloth 20x25
60 PSLDMA801WJZZ J DIGITAL PWB Shield (TOP) AS
61 PSLDMA867WJZZ J Conducting Shield
62 PSPAZA632WJKZ J Cooling Sheet (IC8101 TOP)
63 PSPAZA635WJKZ J Cooling Sheet (IC2502 TOP)AC
64 PSPAZA700WJKZ J Cooling Sheet (IC82502 BTM) AD
65 PSPAZA701WJKZ J Cooling Sheet, x2 AD
(IC1804,3700)
