Sharp LC-45GD5U User Manual

Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
LC-45GD5U
139
CABINET AND MECHANICAL PARTS
(Continued)
66 PSPAZA812WJZZ J PWB_Suppport AD
67 PSPAZA872WJKZ J Cooling Sheet (IC3300 TOP)AN
68 PSPAZA879WJKZ J Cooling Sheet
(IC8451/8454 EMI)
69 PSPAZA880WJKZ J Cooling Sheet (IC3800 BTM)AC
70 PSPAZA881WJKZ J Cooling Sheet
(IC3401+3403)
71 PSPAZA882WJKZ J Cooling Sheet
(IC1806+08+Q1812)
72 PSPAZA883WJKZ J Cooling Sheet (IC8601 TOP)AC
73 PSPAZA884WJKZ J Cooling Sheet AE
(TU8001 TOP)
74 PSPAZA886WJKZ J Cooling Sheet (IC9603TOP) AB
75 PSPAZA887WJKZ J Cooling Sheet AE
(SC9401SOLDRSIDE)
76 PZETKA165WJZZ J Barrier sheet (Insulator)
77 QCNW-D998WJQZ J Connecting Cord AT
(DA:AV-DIGITAL)
78 QCNW-E003WJQZ J Connecting Cord AL
(DC:AV-BUSCONNE)
79 QCNW-D872WJQZ J Connecting Cord
(KM:KEY-MAIN)
80 QCNW-E001WJQZ J Connecting Cord
(RA:LED-AV)
81 QCNCMA201WJZZ J Connector AH
(FC SOKET YOU)
82 QCNW-D498WJQZ J Connecting Cord AN
(DP+PD:MN,DIG-PW)
83 QCNW-D952WJQZ J Connecting Cord
(RFSW-TUNER(BLAK))
84 QCNW-D953WJQZ J Connecting Cord
(RFSW-JACK(RED))
85 QEARPA203WJFW J Conductor
86 QCNW-D495WJQZ J Connecting Cord AG
(AC:POW-AC_IN)
87 QCNW-D497WJQZ J Connecting Cord AM
(PA:AV-POW)
88 QCNW-D873WJQZ J Connecting Cord
(MN:MAIN-INV)
89 QCNW-D874WJQZ J Connecting Cord AP
(PG:POW-INV)
90 QCNW-D999WJQZ J Connecting Cord
(SP:AV-SP_L,R)
91 QCNW-E002WJQZ J Connecting Cord
(FD:AV-POW)
92 QCNW-E004WJQZ J Connecting Cord
(PO:POW-LCD_CONT)
93 QCNW-E065WJQZ J Connecting Cord
(LV:MAIN-LCD_CNT)
94 QEARZA091WJZZ J Ground-Part (AL TAPE)
95 RCORF0107CEZZ J Core (MAIN-POW) AM
96 RCORFA034WJZZ J Core (MAIN-AV)
97 XBBS740P06000 J Screw, x11 (C-ANG/CAB-A) AA
98 XBBS830P06000 J Screw, x14 AA
(COVER,JACK5/COV5,AC2,C-ANG2)
99 XBBS940P08000 J Screw, x2 AB
(FOR HINJI COVER)
100 XBBSN50P12JS0 J Screw, x4 (STAND/SET) AF
101 XBPS730P06WS0 J Screw, x59 (CAP BISS) AA
102 XBPS830P04WS0 J Screw, x4 AA
(FOR LEAK OF LIG)
103 XBPSN20P12JS0 J Screw, x2 AB
(PCCARDSOKET_BIS(PC))
104 XBPSN30P20XS0 J Screw, x6 (FAN/ANG) AB
105 XEBS930P08000 J Screw, x2 AA
(FOR POWER PWB)
106 XEBS930P10000 J Screw, x31 AA
(COVER,JACK4/COV3,SP2,T-COV1)
107 XEBS940P20000 J Screw, x13 (FOR CAB-B) AB
108 XJBS850P25000 J Screw, x4 (STAND YO) AC
109 Not Availabl e–No. Label —
